9 Note: When you attach a special feeder on your main unit, remove the scr ew , t hen the safety cover guard if it is in contact w ith the safet y cover guide. Safety cover guide
8
PWB transport shutter (right side viewed from the front)
PWB transport shutter (left side viewed from the front)
Note: When you set the switch to “AUTO”, the shutter automatically opens/closes
while the system is transporting a board. When you set it to “OPEN”, the
shutter opens.
Mounter main unit
PWB transport cover
Mounter side
Outer side
Mounter main unit
PWB transport cover
Mounter side Outer side
9
Note: When you attach a special feeder on your main unit, remove the screw, then
the safety cover guard if it is in contact with the safety cover guide.
Safety cover guide
KE-2010/2020/2030/2040
