YS24 Parts List _KKE-0911 - 第24页
1 13 26 18 16 23 28 29 27 19 25 24 15 27 30 27 20 22 25 25 27 30 30 17 26 21 26 30 6 14 2 9 12 1 1 4 1 1 10 8 7 3 5 5 5 Scan Camera / Axis Head KKE-091105 No. Part No. Part Name Q'ty Remarks Compati. Revision No.-da…
1
13
14
15
17
19
19
17
16
19
19
21
21
2
6
4
3
5
5
20
22
22
18
20
20
20
20
7
8
11
12
9
12
23
23
10
5
4
Ejector / Z-axis
Head
KKE-091105
No. Part No. Part Name Q'ty Remarks
Compati. Revision No.-date
1 KHY-M7151-01 EJECTOR, RESIN 1
2 KHY-M4592-01 VAC SENSOR BRD ASSY 1
3 KHY-M71CA-00 COVER,VAC SENSOR 1
4 90563-23J060 SPACER 4
5 91312-03005 BOLT HEX. SOCKET HEAD 6 M3X5
6 KHY-M7152-01 EJECTER 1
7 KHY-M7153-00 VALVE 1
8 KHY-M7154-01 BIT 1
9 KHY-M7155-00 FILTER CAP 1
10 KHY-M7156-01 BIT CAP 1
11 K46-M8527-C0 FILTER 1
12 90990-17J010 ORING 2
13 KKE-M71G5-A0 Z UNIT ASSY. 5
14 KKE-M71G5-A5 Z UNIT ASSY. 5
15 KKE-M71G1-00 SIDE PLATE, R 1
16 KKE-M71G2-00 SIDE PLATE, L 1
17 KHY-M71G3-00 SHAFT 1 2
18 KHY-M71H3-00 TAPE, Z-UNIT 1
19 90990-28J078 WASHER, PLAIN 4
20 91312-05014 BOLT HEX. SOCKET HEAD 8 M5X14
21 99480-04008 PIN, PARALLEL: 4X8 2
22 90K41-000720 LABEL, ALERT 2
23 $TL10-01 JOINT 2
1
13
26
18
16
23
28
29
27
19
25
24
15
27
30
27
20
22
25
25
27
30
30
17
26
21
26
30
6
14
2
9
12
11
4
11
10
8
7
3
5
5
5
Scan Camera / Axis
Head
KKE-091105
No. Part No. Part Name Q'ty Remarks
Compati. Revision No.-date
1 KKD-M78C0-00 SCAN CAM. ASSY 1
2 KHY-M7A13-01 DIFFUSER, MAIN 1
3 KHY-M7554-02 OF. LIGHT BRD. ASSY. 1
4 KHY-M7A30-00 SIDE LIGHT ASSY. 1
5 KV7-M7165-00 SEAL DON'T TOUCH 1
6 90990-08J026 SCREW, PAN HEAD 4
7 90112-02J006 BOLT HEX. SOCKET HEAD 2
8 KHY-M7A31-00 BLOCK, LIGHT SIDE 1
9 KHY-M7A34-00 DIFFUSER, SIDE 1
10 KHY-M7905-02 OF. SV. LIGHT BRD ASSY 1
11 90990-08J020 SCREW, M2X5 3
12 90990-28J002 WASHER PLAIN 3
13 KKE-M7850-00 SC MOTOR ASSY 1
14 KKE-M7880-00 HNS. SCAN ASSY 1
15 KKE-M7857-00 BRACKET, DUCT 1
16 KKE-M7865-00 PLATE, CABLE 1
17 KKE-M7866-00 BRACKET, CONNECTOR 1
18 KKE-M7892-01 BRACKET, CONNECTOR 1
19 KKE-M7893-00 PLATE, CLAMP 1
20 KKE-M7894-00 CLAMP, CABLE 1
21 KKE-M7896-00 COVER, SENSOR 1
22 KKE-M7897-00 COVER, CABLE 1
23 KKE-M66JA-00 HNS, SCAN FLEX 1
24 KHY-M7A98-00 TAPE, SCAN CABLE 1
25 91312-03006 BOLT HEX. SOCKET HEAD 14
26 91312-04006 BOLT HEX. SOCKET HEAD 8
27 98902-04005 SCREW, BINDING HEAD 4
28 98902-04008 SCREW, BINDING HEAD 2
29 90172-00J040 WASHER, EXTL. TOOTHED 1
30 $NK-2N NYLON CLIP 5
1
6
Nozzle
Nozzle
KKE-1003
OLD
11
1
3
5
2
4
14
3
5
15
4
16
18
5
17
4
19
18
5
20
4
21
3
5
22
4
6
3
5
7
4
8
10
3
5
9
4
12
3
5
13
4
NOZZLE 301A ASSY. NOZZLE 302A ASSY.
NOZZLE 303A/314A ASSY.
NOZZLE 304A/315A ASSY.
NOZZLE 306A/317A ASSY.
NOZZLE 310A ASSY.
NOZZLE 311A ASSY.
NOZZLE 312A ASSY.
NOZZLE 313A ASSY.
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KHN-M7710-A2 NOZZLE 301A ASSY. 1 TYPE 301A
2 KHN-M7711-03 BODY, NOZZLE 301 1
3 KHN-M7713-00 SPRING 1
4 KHN-M7714-00 PIN 1
5 KHN-M7715-00 CLIP 1
6 KHN-M7720-A1 NOZZLE 302A ASSY. 1 TYPE 302A
7 KHN-M7721-02 BODY, NOZZLE 302 1
8 KHY-M7740-A0 NOZZLE 303A/314A ASSY. 1 TYPE 303A/314A
9 KHY-M7741-00 BODY, NOZZLE 303/314 1
10 KHY-M7750-A0 NOZZLE 304A/315A ASSY. 1 TYPE 304A/315A
11 90990-17J013 O-RING 5
12 KHY-M7770-A0 NOZZLE 306A/317A ASSY. 1 TYPE 306A/317A
13 KHY-M7771-00 BODY, NOZZLE 306/317 1
14 KHY-M77A0-A0 NOZZLE 310A ASSY. 1 TYPE 310A
15 KHY-M77A1-00 BODY, NOZZLE 310 1
16
KHY-M7710-A2 NOZZLE 311A ASSY. 1 TYPE 311A NG MFX0107-2010/1/28
KHY-M7710-A1 NOZZLE 311A ASSY. 1 TYPE 311A
17
KHY-M7711-01 BODY, NOZZLE 311 1 NG MFX0107-2010/1/28
KHY-M7711-00 BODY, NOZZLE 311 1
18 KHN-M7713-10 SPRING 1
19 KHY-M7720-A1 NOZZLE 312A ASSY. 1 TYPE 312A
20 KHY-M7721-00 BODY, NOZZLE 312 1
21 KHY-M7730-A0 NOZZLE 313A ASSY. 1 TYPE 313A
22 KHY-M7731-00 BODY, NOZZLE 313 1
