1OM-1603 3-60 6. Running-In Operation : Chap.3 1 108-001

1OM-1603

3-59

6. Running-In Operation : Chap.3

Select the pattern

Determine the pattern

Select the operation

F1C45

(5) Press the [START] button twice on the operation panel.

(The running-in operation starts.)

(6) To stop the running-in operation, press the [STOP] button on the operation

panel.

(7) To exit from the test mode, press the [Disable] and the [Apply] buttons in the

"MODE SET" window.

("TEST RUN: # (Pattern No.)" disappears from the "Status Indicator" eld

located at the upper area of the window and the normal mode resumes.)

1012-005

1OM-1603

3-60

6. Running-In Operation : Chap.3

1108-001

1OM-1603

1108-004 4-A

Chapter 4

Basic Information

This chapter describes the basic information.

 1. Specications

2. High-Speed Head Pick-up Component Size

(In the case that 15 components are to be picked up at

the same time).

3. Conditions for Component Placement

4. Fiducial Marks

5. List of Vacuum Nozzle Types

6. Measured Noise Value
