1OM-1603 4-13 1.Specications:Chap.4 T1E1-13 1 108-006 It em Descriptio n 25. Power Suppl y 20 0 ± 20 V AC, 3-Phase, 50/60Hz Connected to the power supply unit (3-phase 3-wire sy stem) (The grounding cable s hould be …
1OM-1603
4-12
1.Specications:Chap.4
1012-005
Item
Description
Visual Field Approx. 12 × 12 mm
Window
Size
Max. 9.0 × 9.0 mm
Recognition
(Process)
Time
Approx. 0.06 seconds / mark
(including the time to capture an image)
19. PEC Recognition
Photo Image Front Lighting System
(Recognition of Fiducial Mark by Front Lighting)
("Normal" or "Reverse" can be selected for each mark.)
20. Fiducial Marks Refer to "Fiducial Marks" for details.
Supply
Pressure
0.45 to 0.69 MPa (4.6 to 7 kgf/cm
2
)
Set Pressure 0.45 MPa (4.6 kgf/cm
2
)
Note : Min. 0.4 MPa (4.1 kgf/cm
2
) of air is necessary for
operation.
21. Air Supply
• Use the dry and clean air as follows
Moisture : Dew Point − 17 ℃ or lower (Atmospheric Pressure)
Oil : 0.1 mg/m
3
or less (ANR)
Dust : Solid Material 0.01 µm or less
22. Air Consumption Approx. 30 L/min (during automatic operation)
Approx. 110 L/min (when one feeder base moves up and down)
Approx. 220 L/min (when two feeder bases move up and down at the same
time)
23. Vacuum Pressure −93 kPa (70 cmHg)
24. Environmental
Condition
Temperature : 20
±
10
°
C
Humidity : 30 to 80 % (Avoid dew condensation)
Note : When the ambient temperature rises more than the surface of the
machine, dew condensation might occur under the condition described
below.
Note that dew condensation may cause the machine to break down.
Condition of Dew Condensation
Dew condensation might occur when the difference (based on
"Humidity (%)") between the ambient and surface temperatures of the
machine reach the values or more in the table below.
Humidity
(%)
Differences between Ambient and Surface
Temperatures of Machine (Ambient
Temperature > Surface Temperature)
80 3 °C or more
70 6 °C or more
60 8 °C or more
50 10 °C or more
40 14 °C or more
30 18 °C or more
Altitude : 1,000 m or less above the sea level
T1E1-12
1OM-1603
4-13
1.Specications:Chap.4
T1E1-13
1108-006
Item
Description
25. Power Supply
200 ±
20 V AC, 3-Phase, 50/60Hz
Connected to the power supply unit (3-phase 3-wire system)
(The grounding cable should be connected to the PE terminal).
26. Maximum 7.4 kVA
Apparent Power
27. Power
Consumption/
Hour
Approx. 1.80 kWh
28. Dimensions
Approx. 1,280 (Width) mm (Including Input/Output Conveyor)
× 2,200 (Depth) mm
(Including Bank Feeder Change Cart)
× 1,450 (Height) mm
(1,910 mm : Including Light Tower)
29. Mass
Approx. 1,800 kg
(excluding. the Bank Feeder Change Carts and the tape feeders)
30. Environmental
Requirements for
Bank Feeder
Change Cart
Floor Gradient : 10/1000 or less
Note : The floor should be hard enough for the casters of the cart to move
smoothly.
32. Others
Standard Functions
• Component Library Teaching Function (GS-TR100)
• Placement Position Teaching Function (GS-TZ100)
• Application for BGA/CSP (GS-TB100)
• Automatic Recovery Function for Component Pickup Errors
• Component Pick-Up Position Teaching Function
• Delayed Recovery Function (Recovery Mode)
• Alternate Component Supply Function
• Pick-Up and Placement Up/Down-Axis (L-Axis) Control Function
• Pick-UP Position (X/Y) Correction Control Function
• Pocket outline recognition
• Two-stage placement Z-Axis speed reduction
• Nozzle existence check before pick-up
31. Input and Output
Conforming to the specifications of the SMEMA communications.
Interfaces
1OM-1603
4-14
1.Specications:Chap.4
1.2 Standard Accessory Parts List
No. Product Name Part No. Q'ty Remarks
1
Lens Cleaning Cloth
15 cm × 15 cm
226J1560 5
2
Glass Tube Fuse (6.3 A) 4S300023 1 • Spare
3
Glass Tube Fuse (5 A) 4S300024 1 • Spare
4
Glass Tube Fuse (3.15 A) 4V320011 1 • Spare
5
Glass Tube Fuse (10 A) 4S301007 1 • Spare
6
Fuse with an Alarm Contact (5A) 4S300006 1 • Spare
7
Flat-Type Fuse (5 A) 4S300010 1 • Spare
8
Fuse (2 A) 0916D207 1 • Spare
9
Splicing Joint Detector Cleaning Long
Stick with a Rope
0926B109 1 • For Cleaning the Splicing Joint
Detector
10
Splicing Joint Detector Cleaning
Cotton Applicator
0926B10A 1 • For Cleaning the Splicing Joint
Detector
11
Flame Leg Receiver 216R0353 4
12
Collar (BS Spacer) 216A0334 4 • Flame Leg Receiver
13
Set Screw 221CA010 4 • Flame Leg Receiver
14
Padlock 226J0574 2 • For Locking Power Breaker and Air
Source
15
QFP Glass Plate Jig (JG-0188) 211D9639 1 • For Offset Teaching
16
Nozzle (PK01) PK01---- 1 • For Support Pin Pick-up
17
PCB Support Pin 0974J00U 20 • For PCB Support Pin
18
Cable (3M) 0964B000 1
T1E2-1
