1OM-1603 Glos-6 Glossary 1 108-003 Component Library The component library is a database used to manage the specic information (data) on components required for operations of the component placement machine. Auxiliary L…
1OM-1603
Glos-5
Glossary
1108-003
[EMERGENCY STOP] Switches
These switches are used to stop the machine immediately in an emergency.
When one of these switches is pressed, the power to the machine is
intercepted and the machine stops immediately.
Alternate Feeder Function (Mode)
When component shortage is occurred or a feeder has trouble and the
components cannot be picked up subsequently, the alternative spare feeder
(prepared in advance for frequently used component types) selected to
continue the automatic operation. In this case, another slot No. across the
front and rear beams can be selected.
Feeder Ready Switches
These switches are used to indicate that the feeder bases are set ready and
each switch is employed in four feeder blocks.
The feeder bases are provided with "Clamp Lock Mechanism". This
mechanism physically prohibits any attachment or detachment of a feeder
while the machine is running in order to avoid any collision (crash accident)
of the machine that might be caused when a feeder (used for automatic
operation) is detached inadvertently while the machine is running (the beams
are moving).
When one of these switches is pressed, the LED turns green, indicating that
the feeder is set ready, and the feeder clamp holding bar (swinging type
driven by the cylinder) is driven and locked.
Component Carriage Data Edit Function
The function enables the operator to easily change the component carriage
data in the current pattern program. This can be used when the packaged
posture of the supplied component differs from that of the component being
used so far due to unavailability, etc.
Only the limited data for the packaged posture can be changed.
Component Recognition Sections
Each beam has a component recognition camera and a light source for
illumination within its coverage area. The camera and the light source are
used to inspect (recognize) the component picked up by a vacuum nozzle.
These sections are provided with front and back lighting systems. In the front
lighting system, the bottom surface of a component is illuminated directly
from under the component and the reected image is captured. In the back
lighting system (ring lamps), the diffusion plate is illuminated from under
the plate and the penetrated image of a component is captured.
1OM-1603
Glos-6
Glossary
1108-003
Component Library
The component library is a database used to manage the specic information
(data) on components required for operations of the component placement
machine.
Auxiliary Lamps
An auxiliary lamp is installed on each block.
The auxiliary lamps indicate in which block the machine status (indicated by
the tower lamp) is generated.
1OM-1603
0908-002 Inde-A
Index
