Figure Description Order No.

Flux IF 2005M

1,8 % solid content

suitable for wave soldering leaded and lead-free

10 l Can

4FMJF2005-10

25 l Can

4FMJF2005-25

200 l Barrel

4FMJF2005-200

Thinner IF TT2005M

Thinner for IF 2005M

10 l Can

4HMTT2005-10

25 l Can

4HMTT2005-25

Flux IF TS15

1,5 % solid content, foamable

10 l Can

4FMJFTS15-10

25 l Can

4FMJFTS15-25

200 l Barrel

4FMJFTS15-200

Thinner E3226

Thinner for IF TS15 and IF TS18

5 l Can

4HMVER-5

20 l Can

4HMVER-20

Flux RA200 5 l Can

4,5 % solid content; halogen free

activated; no resins contained

4FMRA200-5

Flux RA201 5 l Can

2 % solid content; halogen free

activated; no resins contained

4FMRA201-5

Thinner for Flux RA201, 5 l can

4HMVER201-5

Flux IF 2005K

2,5 % solid content; suitable for wave soldering lead-free and

selective soldering leaded

1 l Bottle

4FMJF2005K-1

10 l Can

4FMJF2005K-10

25 l Can

4FMJF2005K-25

Flux IF 2005C

3,4 % solid content; suitable for selective soldering leaded

and lead-free

1 l Bottle

4FMJF2005C-1

10 l Can

4FMJF2005C-10

25 l Can

4FMJF2005C-25

Flux

Figure Description Order No.

Flux IF 2009 MLF

3,6 % solid content; ultralow solder balling; suitable for wave-

and selective soldering

1 l Can

4FMMLF2009-1

10 l Can

4FMMLF2009-10

Flux Pacific IF 2009M

3,7 % solid content; low residue high compatibility with con-

formal coating; suitable for wave- and selective soldering

1 l Bottle

4FMJF2009-1

10 l Can

4FMJF2009-10

25 l Can

4FMJF2009-25

Flux Pacific IF2009

2,5 % solid content

10 l Can

4FMJF2009-2.5-10

25 l Can

4FMJF2009-2.5-25

Flux Pacific IF 2010F

2,5 % solid content; low residue high compatibility with con-

formal coating; suitable for wave soldering and foam contract

1 l Bottle

4FMJF2010-1

10 l Can

4FMJF2010-10

Flux IF 2040

6,5 % solid content; low residue high conpatibility with con-

formal coating; suitable for selective soldering

1 l Bottle

4FMJF2040-1

10 l Can

4FMJF2040-10

25 l Can

4FMJF2040-25

Low Residue - No-Clean Flux Water Based Flux

Flux for special applications

Figure Description Order No.

Flux GR8 5 l Can

14,5 % solid content; halogen free

activated; resins contained

4FMGR8-5

Flux R8 5 l Can

15 % solid content; activated with

organic halogens; resins contained

4FMR8-5

Thinner E3226

5 l Can

4HMVER-5

20 l Can

4HMVER-20

Figure Description Order No.

High temperature cain oil

LUBCON - special oil, Turmofluid 40B,

0,4 l Spraycan

6XOEL24-0.4S

LUBCON - special oil, Turmofluid 40B,

0,5 l bottle

6XOEL24-0.5

High temperature grease UH1-96-402

delivery in tubes with 80 g

171146

OKS 250 Metal-free multi paste

250 g

210939

tube 80 g and 5 lube brushes

211218

80 ml - unsuitable by direct contact

with solder

216540

Grease TAS-WT till 1400 °C - 100 g tube

LUBCON - special lubricant, TURMO-

PAST TAS WT, paste without dropping

points. Temperature application range

-30 °C up to +1400 °C (higher tahn 200

°C: the paste turns to a dry lubrication)

28444

Spindle grease, 50 g

NBU 15 for lubrication of the shaft

from the z-axis (Flex and dipmodul)

in selective and wave soldering

machines

210860

Grease gun filled w. Isoflex NBU15

contain 50 g grease

210996

Lubrication set Isoflex NBU15

tube 50 g and lube brush

214163

Grease Klueber Microlube GL 261 40 g

Lubrication of linear track with high

stress

210862

Pencil for grease

211209

Grease gun

Pressol plunger push press with cup-

ped and pointed adapter, connection

thread M10x1 size 80 cm³ AD43 mm

L = 140 mm

92159

Lubricants & Cleaning Products

Figure Description Order No.

Klüberplex BEM 34-132

1 kg tin

343055

grease gun

empty for parker axis VF4

343049

hand lever grease gun with snout (empty)

for z-axis of the selective solder pot

343056

High temp. grease Barrierta tube 50 gr.

for filling the high temperature

bering 6LAP40-15FD-T

163081

Lubricants Lubricants

Cleaning Products

Figure Description Order No.

ESD-Cleaner 1 l

for cleaning of ESD- slices - not

suitable for acrylic slices

211125

Reinigungsset Acrylscheiben + ESD Folie

ESD - cleaner with mircofiber high

ressistance cloth

211214

cleaning cloth vermop-Softy

for cleaning of acrylic glass slices in

machine covers in conjunction with

cleaner 211125

211207

Cleaning cloth for sprayheads

cleaning clothes lint-free, 100x100

17231

Syggol Cleaner in 5 l CAN

Cleaner for high contamination espe-

cially in reflow- and wave soldering

machines.

302619

Unless specified otherwise in the product description, order numbers

refer to a packing unit (pu) of 1 piece.

Unless specified otherwise in the product description, order numbers

refer to a packing unit (pu) of 1 piece.

1514

Solderbath Maintenance Wave

Figure Description Order No.

Removing tool with interlocking

nozzle removing tool for ERSA wave

nozzles

12555

Red oxide paint 750 g/tin

for painting of moulding solder pots

to protect them from pitting because

of the lead-free soldering

4HMFARBE

Figure Description Order No.

De-Drossing Tool

„consist of:

3x Brush flat sor. 40.1”” 6ZT0073

1x Service gloves (pair), size L 6HDSGLGEW-290

1x Ladle for feeding pipe blue (100613) or green (299969)

1x Scraper flexible 100676

1x Spoon to remove dross in versflow pot 100604

blue

4SNP00-ZB0-010

green

265539

Solder Ladle

square solder pots

332154

Ladle for feeding pipe DIP

blue

253480

green

297440

Nozzle Removal Tool Version 2

for selective nozzle standard and thin

6ISK47957091

Combi tool for nozzle removal

optimal combi tool to remove the

nozzle and the gasification ring of

selective soldering machines

6ISK47957090A

Tongs for the exchange of tips

3ZT00164

Cleaning paste IF930 nozzles

for cleaning / activation of wettable selective nozzles

10 ccm

179904

30 ccm

179905

Dispenser for 10 ccm

for cartridges 179904

104118

Cleaning brush f. nozzles diameter 2,5 mm

twisted brush with stainless steel

bristles 2,5 mm bristle diameter,

borderlength: 120 mm,

total length: 300 mm

258787

Solderbath Maintenance

Solderbath Maintenance Selective

Figure Description Order No.

Brush for tube Ø=3 mm stainless tread M4

47700

Handle 2,8 - 4 mm black-synthetic

47705

Brush for tube Ø 5 mm stainless tread M6

47701

Cleaning brush f. nozzles diameter 6 mm

247811

Brush for tube Ø 8 mm stainless tread M6

47702

Brush f. tube Ø 10 mm stainless tread M6

47703

Handle M6 Dia. 23 L 60

47704

Tray for solder module

243401

Spoon to remove dross in versflow pot

100604

Needle f. dispens.Ø=1,63/1,35;l=25.4viol

for rework paste solder nozzles

Versaflow

103556

Cleaning tool for solder nozzles

Tool Set for cleaning and activation of

solder nozzles. Consisting of:

2 EA of 179904 „cleaning paste” HS

code 38109090, 5 EA of 103556 needle

HS code 73181590, 1 EA of 47703

brush for tube HS code 96035000, 1

EA of 47704 handle for tube HS code

84879090, 1 EA of 213024 cleaning

brush HS code 96039099

106249

Needle 90° LL Nr.14 Id 1,6 mm

130271

Figure Description Order No.

Service gloves (pair)

for the hot area

Size M

6HDSGLGEW-289

Size L

6HDSGLGEW-290

Mould for alloy analysis

for the tin analysis at Ersa

6ISK714-05A

Brush flat 25mmx7mm Istle green

317108

Brush flat 25mmx7mm Istle blue

317109

Brush flat 35mmx12mm Istle Green

317110

Brush flat 35mmx12mm Istle Blue

317111

Brush flat 60mmx20mm Istle Green

317113

Brush flat 60mmx20mm Istle Blue

317114

Brush flat 25mmx7mm China-bristle

317115

Brush flat 35mmx12mm China-bristle

317116

Brush flat 60mmx20mm China-bristle

317117

Solderbath Maintenance

Figure Description Order No.

Solder Scrapper blue

this tool is used together with the

tool for the remove dross. A optimal

tool to seperate the oxids from the

useful solder

6ISK714-03

Tool to remove dross blue

100692

Multigrip pliers (pair), 240 mm length

6ZT00095

Scraper flexible

100676

Brush flat sor. 40 1”

6ZT00073

Spatula b=150 mm blue

100449

Silicon brush

112539

Scraper - silicon

Small

112541

Large

112540

Wooden scraper

112537

Cover oil HAT (Pump drive) 1 l Tin

1 l - can for the cover of the pump

drive at wave soldering machines.

Prevent surface oxidation. HAT is

synthetic and oil-free

4HMHT

Solderbath Maintenance General Solderbath Maintenance Wave

Solderbath Maintenance Wave

Figure Description Order No.

De-Drossing Tool for Solder Pot

for Wave and Dip Soldering Modules

including special tool with L2C coated surfaces for lead solder

Consisting of 13 tools to maintain the solder bath

blue

123551

green

265515

Solder Laddle

suitable for removal of fluid solder

from the soldering bath. For example

for alloy analysis

6ISK714-01

Unless specified otherwise in the product description, order numbers

refer to a packing unit (pu) of 1 piece.

Unless specified otherwise in the product description, order numbers

refer to a packing unit (pu) of 1 piece.

1716

Figure Description Order No.

FC-holder(110091) repair kit, sealing

contains all installed seals

164292

Nozzle 0,3 mm Nr.210111 flood gate

fluid nozzle for 110089 with 0,3 mm

diameter

207521

Needle 0,2/0,3 mm Nr.111670 flood gate

needle for sprayhead 110089 with 0,3

mm fluid nozzle

245214

Flux head 0,5 mm

fluid nozzle with 0,5 mm for gate

sprayhead. Only usage in conjunction

with the suitable needle 235322

235321

Needle for flux head inox 1.4571

needle for gate sprayhead. Only

usage in conjunction with the fluid

nozzle 235321

235322

Spray head, flood gate jet/needle 0,5

set with needle and fluid nozzle 0,5

mm gate sprayhead. For reconstructi-

on from 0,3 mm to 0,5 mm diameter

136796

Pressure spring 0,7 x 13,5 mm 820017

for sprayhead 110089

233202

O-Ring 2,9x1,78 Viton article-no.:640026

234130

O-Ring 8,5x1,8 Viton article-no.:640366

234132

O-Ring 5x1 Viton article-no.:640077

236550

Fluxer Accessories

Fluxer Powerflow Series Fluxer Powerflow Series

Fluxer ETS, EWS and NWAVE Series

Figure Description Order No.

O-RING 18X1,5 Fa. Schütze ART. NR.640006

246024

Cap ring 23x10 mm Nr.410059 flood gate

266004

Spray nozzle air-cap 60° VA, flood gate

224571

Figure Description Order No.

Spray unit

contains all seals and needle

6ISK171009

Sprayhead-repair-kit

Enthält alle Dichtungen und die

Absperrnadel

6FLXSPR-14

Spray nozzle 2050 (stainless steel)

replacement fluid nozzle spraying

system standard

6FLXSPR-02

Spray nozzle 1650 (stainless steel)

fluid nozzle spraying systems for

lower flux quantity

6FLXSPR-02-S1

Spray nozzle 2850 (stainless steel)

fluid nozzle spraying systems for

higher flux quantity

6FLXSPR-02-S2

Air nozzle 67228- 45° V2A

6FLXSPR-03

Figure Description Order No.

Sprayhead flux jet II - 130 micrometer

6FLX-REA06

Sprayhead flux jet II 1/180 micrometer

6FLX-REA08

Sprayhead flux jet II 1/270 micrometer

6FLX-REA07

Sealing ring for Wedotec-spray head

for nozzle plate of the sprayheads

6FLX-REA06, 6FLX-REA08 and 6FLX-

REA07

82240

Spring part with sealing, Wedotec

for sprayheads 6FLX-REA06, 6FLX-

REA08 and 6FLX-REA07

156252

Wear set Flux-Jet; Wedotec

content:

2x nozzle plate sealing

2x fixing srews for nozzle plate

2x safety washer

1x spring

156183

Cleaning needle 130 - 350 micrometer

for cleaning the nozzle plate from

sprayheads of the VERSAFLOW and

ECOCELL selective soldering machine

17233

Pressure tank 2 l. V4A 1.4404 bottom

pressure tank for selective soldering

machine

234045

flux container VF4 2ltr

274239

Float switch for spray pressure tank

203148

Level sensor

capactive level sensor for older

pressure tanks

6FLX-SPR-12

Fluxer Accessories

Fluxer Selective Machines Fluxer Selective Machines

Fluxer Powerflow Series

Figure Description Order No.

Precision pres reg 0,05-2 bar

pressure regulator for pressure tank

234045

101992

Over pressure valve

for pressure tank 234045

205266

Manometer 0-2,5 bar 1/8”

for pressure tank 234045

125875

PTFE Sealing 1/4” 25% Carbon

for pressure tank 234045

259583

Needle for cleaning 130-270 micro nozzle

for sprayhead of the versaflow and

ecocell selective soldering machine

78722

Figure Description Order No.

Spray head, flood gate KA-2/SW jet

nozzle: 0,3

110089

nozzle: 0,5

184409

Quick change holder

for Sprayhead 110089 & 184409

110091

Spray head complte, flood gate

set with sprayhead and quick change

mount

110095

Spray head (110089) repair kit, sealing

contains all mounted seals, the

needle and the spring

138113

Spray head (184409) repair kit, sealing

contains all mounted seals, the

needle and the spring

138113
