1514
Solderbath Maintenance Wave
Figure Description Order No.
Removing tool with interlocking
nozzle removing tool for ERSA wave
nozzles
12555
Red oxide paint 750 g/tin
for painting of moulding solder pots
to protect them from pitting because
of the lead-free soldering
4HMFARBE
Figure Description Order No.
De-Drossing Tool
„consist of:
3x Brush flat sor. 40.1”” 6ZT0073
1x Service gloves (pair), size L 6HDSGLGEW-290
1x Ladle for feeding pipe blue (100613) or green (299969)
1x Scraper flexible 100676
1x Spoon to remove dross in versflow pot 100604
blue
4SNP00-ZB0-010
green
265539
Solder Ladle
square solder pots
332154
Ladle for feeding pipe DIP
blue
253480
green
297440
Nozzle Removal Tool Version 2
for selective nozzle standard and thin
6ISK47957091
Combi tool for nozzle removal
optimal combi tool to remove the
nozzle and the gasification ring of
selective soldering machines
6ISK47957090A
Tongs for the exchange of tips
3ZT00164
Cleaning paste IF930 nozzles
for cleaning / activation of wettable selective nozzles
10 ccm
179904
30 ccm
179905
Dispenser for 10 ccm
for cartridges 179904
104118
Cleaning brush f. nozzles diameter 2,5 mm
twisted brush with stainless steel
bristles 2,5 mm bristle diameter,
borderlength: 120 mm,
total length: 300 mm
258787
Solderbath Maintenance
Solderbath Maintenance Selective
Solderbath Maintenance Selective
Figure Description Order No.
Brush for tube Ø=3 mm stainless tread M4
47700
Handle 2,8 - 4 mm black-synthetic
47705
Brush for tube Ø 5 mm stainless tread M6
47701
Cleaning brush f. nozzles diameter 6 mm
247811
Brush for tube Ø 8 mm stainless tread M6
47702
Brush f. tube Ø 10 mm stainless tread M6
47703
Handle M6 Dia. 23 L 60
47704
Tray for solder module
243401
Spoon to remove dross in versflow pot
100604
Needle f. dispens.Ø=1,63/1,35;l=25.4viol
for rework paste solder nozzles
Versaflow
103556
Cleaning tool for solder nozzles
Tool Set for cleaning and activation of
solder nozzles. Consisting of:
2 EA of 179904 „cleaning paste” HS
code 38109090, 5 EA of 103556 needle
HS code 73181590, 1 EA of 47703
brush for tube HS code 96035000, 1
EA of 47704 handle for tube HS code
84879090, 1 EA of 213024 cleaning
brush HS code 96039099
106249
Needle 90° LL Nr.14 Id 1,6 mm
130271
Figure Description Order No.
Service gloves (pair)
for the hot area
Size M
6HDSGLGEW-289
Size L
6HDSGLGEW-290
Mould for alloy analysis
for the tin analysis at Ersa
6ISK714-05A
Brush flat 25mmx7mm Istle green
317108
Brush flat 25mmx7mm Istle blue
317109
Brush flat 35mmx12mm Istle Green
317110
Brush flat 35mmx12mm Istle Blue
317111
Brush flat 60mmx20mm Istle Green
317113
Brush flat 60mmx20mm Istle Blue
317114
Brush flat 25mmx7mm China-bristle
317115
Brush flat 35mmx12mm China-bristle
317116
Brush flat 60mmx20mm China-bristle
317117
Solderbath Maintenance
Figure Description Order No.
Solder Scrapper blue
this tool is used together with the
tool for the remove dross. A optimal
tool to seperate the oxids from the
useful solder
6ISK714-03
Tool to remove dross blue
100692
Multigrip pliers (pair), 240 mm length
6ZT00095
Scraper flexible
100676
Brush flat sor. 40 1”
6ZT00073
Spatula b=150 mm blue
100449
Silicon brush
112539
Scraper - silicon
Small
112541
Large
112540
Wooden scraper
112537
Cover oil HAT (Pump drive) 1 l Tin
1 l - can for the cover of the pump
drive at wave soldering machines.
Prevent surface oxidation. HAT is
synthetic and oil-free
4HMHT
Solderbath Maintenance General Solderbath Maintenance Wave
Solderbath Maintenance Wave
Figure Description Order No.
De-Drossing Tool for Solder Pot
for Wave and Dip Soldering Modules
including special tool with L2C coated surfaces for lead solder
Consisting of 13 tools to maintain the solder bath
blue
123551
green
265515
Solder Laddle
suitable for removal of fluid solder
from the soldering bath. For example
for alloy analysis
6ISK714-01
Unless specified otherwise in the product description, order numbers
refer to a packing unit (pu) of 1 piece.
Unless specified otherwise in the product description, order numbers
refer to a packing unit (pu) of 1 piece.
1716
Figure Description Order No.
FC-holder(110091) repair kit, sealing
contains all installed seals
164292
Nozzle 0,3 mm Nr.210111 flood gate
fluid nozzle for 110089 with 0,3 mm
diameter
207521
Needle 0,2/0,3 mm Nr.111670 flood gate
needle for sprayhead 110089 with 0,3
mm fluid nozzle
245214
Flux head 0,5 mm
fluid nozzle with 0,5 mm for gate
sprayhead. Only usage in conjunction
with the suitable needle 235322
235321
Needle for flux head inox 1.4571
needle for gate sprayhead. Only
usage in conjunction with the fluid
nozzle 235321
235322
Spray head, flood gate jet/needle 0,5
set with needle and fluid nozzle 0,5
mm gate sprayhead. For reconstructi-
on from 0,3 mm to 0,5 mm diameter
136796
Pressure spring 0,7 x 13,5 mm 820017
for sprayhead 110089
233202
O-Ring 2,9x1,78 Viton article-no.:640026
234130
O-Ring 8,5x1,8 Viton article-no.:640366
234132
O-Ring 5x1 Viton article-no.:640077
236550
Fluxer Accessories
Fluxer Powerflow Series Fluxer Powerflow Series
Fluxer ETS, EWS and NWAVE Series
Figure Description Order No.
O-RING 18X1,5 Fa. Schütze ART. NR.640006
246024
Cap ring 23x10 mm Nr.410059 flood gate
266004
Spray nozzle air-cap 60° VA, flood gate
224571
Figure Description Order No.
Spray unit
contains all seals and needle
6ISK171009
Sprayhead-repair-kit
Enthält alle Dichtungen und die
Absperrnadel
6FLXSPR-14
Spray nozzle 2050 (stainless steel)
replacement fluid nozzle spraying
system standard
6FLXSPR-02
Spray nozzle 1650 (stainless steel)
fluid nozzle spraying systems for
lower flux quantity
6FLXSPR-02-S1
Spray nozzle 2850 (stainless steel)
fluid nozzle spraying systems for
higher flux quantity
6FLXSPR-02-S2
Air nozzle 67228- 45° V2A
6FLXSPR-03
Figure Description Order No.
Sprayhead flux jet II - 130 micrometer
6FLX-REA06
Sprayhead flux jet II 1/180 micrometer
6FLX-REA08
Sprayhead flux jet II 1/270 micrometer
6FLX-REA07
Sealing ring for Wedotec-spray head
for nozzle plate of the sprayheads
6FLX-REA06, 6FLX-REA08 and 6FLX-
REA07
82240
Spring part with sealing, Wedotec
for sprayheads 6FLX-REA06, 6FLX-
REA08 and 6FLX-REA07
156252
Wear set Flux-Jet; Wedotec
content:
2x nozzle plate sealing
2x fixing srews for nozzle plate
2x safety washer
1x spring
156183
Cleaning needle 130 - 350 micrometer
for cleaning the nozzle plate from
sprayheads of the VERSAFLOW and
ECOCELL selective soldering machine
17233
Pressure tank 2 l. V4A 1.4404 bottom
pressure tank for selective soldering
machine
234045
flux container VF4 2ltr
274239
Float switch for spray pressure tank
203148
Level sensor
capactive level sensor for older
pressure tanks
6FLX-SPR-12
Fluxer Accessories
Fluxer Selective Machines Fluxer Selective Machines
Fluxer Powerflow Series
Figure Description Order No.
Precision pres reg 0,05-2 bar
pressure regulator for pressure tank
234045
101992
Over pressure valve
for pressure tank 234045
205266
Manometer 0-2,5 bar 1/8”
for pressure tank 234045
125875
PTFE Sealing 1/4” 25% Carbon
for pressure tank 234045
259583
Needle for cleaning 130-270 micro nozzle
for sprayhead of the versaflow and
ecocell selective soldering machine
78722
Figure Description Order No.
Spray head, flood gate KA-2/SW jet
nozzle: 0,3
110089
nozzle: 0,5
184409
Quick change holder
for Sprayhead 110089 & 184409
110091
Spray head complte, flood gate
set with sprayhead and quick change
mount
110095
Spray head (110089) repair kit, sealing
contains all mounted seals, the
needle and the spring
138113
Spray head (184409) repair kit, sealing
contains all mounted seals, the
needle and the spring
138113
Unless specified otherwise in the product description, order numbers
refer to a packing unit (pu) of 1 piece.
Unless specified otherwise in the product description, order numbers
refer to a packing unit (pu) of 1 piece.
1918
Figure Description Order No.
Solder pallet
solder pallet for Ersa soldering machines with working width
of 330 mm. Not suitable for ETS 330 soldering machine with
only one conveyor drive chain.
length 360 mm
4LRM360-3SC-F
length 420 mm
4LRM420-3SC-F
length 500 mm
4LRM500-3SC-F
length 600 mm
4LRM600-3SC-F
Soldering frame Transport
Soldering frame for Ersa Powerflow with separated conveyor
and 330 mm working width.
length 420 mm
4LRM420-3SC-FL
length 500 mm
4LRM500-3SC-FL
length 600 mm
4LRM600-3SC-FL
Solder Frames
Wave Soldering Machines, 330 mm working width
Wave Soldering Machines, 500 mm working width
Wave Soldering Machines, 400 mm working width
Figure Description Order No.
Solder pallet
Solder pallet for Ersa soldering machine with a working width
of 400 mm.
length 420 mm
4LRM420-4SC-F
length 500 mm
4LRM500-4SC-F
length 600 mm
4LRM600-4SC-F
Soldering frame Transp.
Soldering frame for Ersa Powerflow with separated conveyor
and 400 mm working width.
length 420 mm
4LRM420-4SC-FL
length 500 mm
4LRM500-4SC-FL
length 600 mm
4LRM600-4SC-FL
Figure Description Order No.
Solder pallet
Solder pallet for Ersa soldering machine with a working width
of 500 mm.
length 420 mm
4LRM420-5SC-F
length 500 mm
4LRM500-5SC-F
length 600 mm
4LRM600-5SC-F
Soldering frame Transp.
Soldering frame for ERSA Powerflow with separated conveyor
and 500mm working width.
length 420 mm
4LRM420-5SC-FL
length 500 mm
4LRM500-5SC-FL
length 600 mm
4LRM600-5SC-FL
Figure Description Bestell-Nr.
Solder pallet ETS 250
length 360 mm
4LRM360-250
length 420 mm
4LRM420-250
length 500 mm
4LRM500-250
Solder pallet ETS 250A
length 360 mm, VA
4LRM360-250A
length 500 mm, VA
4LRM500-250A
length 600 mm, VA
4LRM600-250A
Wave Soldering Machines, 250 mm working width
Spare Parts, 250 mm working width
Abbildung Bezeichnung Bestell-Nr.
Sidebar ETS 250
length 360 mm
4KLE25-360-000
length 420 mm
4KLE25-420-000
length 500 mm
4KLE25-500-000
length 600 mm
4KLE25-600-000
Center bar ETS 250
length 360 mm
4DKLE2-360-000
length 420 mm
4DKLE2-420-000
length 500 mm
4DKLE2-500-000
length 600 mm
4DKLE0-600-000
Figure Description Order No.
Foam tube 250 mm, Dia. 41 mm
separately packed! Dust protection
6IN131
Foam tube 330 mm, Dia. 41 mm
middle pore side 10 µm; foam tube
packed separately because of dust
protection
6IN045-1
Foam Fluxer/Sensor Shuttle
Foam Fluxer
PTP Messboards
Figure Description Order No.
Foam tube 400 mm, Dia. 41 mm
middle pore side 10 µm; foam tube
packed separately because of dust
protection
6IN045-2
Foam tube 450mm, Dia. 41 mm
middle pore side 10 µm; foam tube
packed separately because of dust
protection
6IN045-3
Figure Description Order No.
PTP
®
Electronics + Softwareplus
8 Channels, Real-Time-Data,
for Reflow-Convection, Wave,
Selective, Temp.-Time-Profiles
Measuring Range 150 to 1,350 °C
1x PTP
®
electronics + software
1x calibration PTP
®
electronics
(incl. certificate with DKD reference)
1x aluminium case with insert for
electronics and Shuttle
8x thermo couples
K-Type Sensor l= 300mm
1x USB Stick, 4GB
0GP-ME001
Measuring Board Reflow V5
Standard 300x390 mm [WxL]
8 Sensors Oven Check-up in
Accordance with ISO900x
0GP-RE001
Shuttle carrier
The PTP - Shuttle is designed for the
reflow measurement board as well
as for the location behind the PCB
and realizes the thermal protection
for the PTP electronics, which is
particularly necessary during the
reflow process.
0GP-SH001
Measuring Board WAVE V6
Standard 300x330 mm [WxL]
8 Sensors Profile optimization
0GP-WE001
Thermocouple Ni/CrNi with plug
thermal element with the adapter for
ERSA sensor shuttle 500mm length
6ETHE2x0.20/500
Thermocouple comp. cable Ni/CrNi
yard goods
6ETHE2x0.20NI
Thermo element compensation cable
yard goods
6ETHE2x0.50NI
Figure Description Order No.
Thermo plug „K” Jumo, male
for connection of the thermal sensor
cable at the ERSA sensor shuttle
6ETHE-NI-ST
Thermo coupling „K” Jumo, female
opposite of the thermal plug
6ETH-NI-ST
6ETHE-NI-KU
Kapton Adhesive tape
10 mm
25 mm
6ZT00160
3RRKAPTON
high temperature tape for fixing of the thermal sensors on
the temporary measurement board
Service gloves (pair)
for the hot area
size M
6HDSGLGEW-289
size L
6HDSGLGEW-290
K-Type Thermocouple
PFA Isolation (+260°C) 2x0,03mm /
L=300 mm
339701
Fibreglass Isolation (+320°C)
2x0,2mm / L=300 mm
339702
Fibreglass Isolation (+320°C)
2x0,2mm / L=400 mm
339703
Fibreglass Isolation (+320°C)
2x0,2mm / L=500 mm
340109
5 K-Type-Sheathed Thermocouple
Inconel® (+320°C) D=0,5 / L=150 mm
340082
Inconel® (+320°C) D=0,5 / L=200 mm
340083
Inconel® (+320°C) D=0,5 / L=250 mm
340085
Inconel® (+320°C) D=0,5 / L=300 mm
340086
Inconel® (+320°C) D=0,5 / L=400 mm
340000
Inconel® (+320°C) D=0,5 / L=500 mm
340087
1 Set, 8 K-Type Thermo-cable Fibreglass
Isolation (M-F +320°C)
L=different length
(2x120,2x150,2x180,2x220 mm)
340393
length ( 4 x 150, 4x200 mm)
341242
L=different length ( 220 – 350 mm)
340149
L= 400 mm, Numbering 1-8
341245
L= 400 mm
341247
Abbildung Bezeichnung Bestell-Nr.
1 Set, 8 K-Type Thermo-cables
PTFE Isolation (M-F, +260°C)
L= 250 mm, Numbering 1 - 8
340160
L= 350 mm, Numbering 1 - 8
339318
Accessoirs
Antenna 50R/SMA-M RX, knuckle
(+80°C)
223683
Antenna 50R/SMA-M TX, Stub (+80°C)
201950
Data cable USB2.0 (A to Mini B) 1,8m
341288
On/Off Switch ( Miniature Plug M,
+320°C, shortcut)
341289
USB Charging Adapter
( USB A – Miniature Plug F) 1,8 m
341290
Antenna SMA-Cable 50R
341729
Li-Ion-Battery
212495
PTP Messboards
