No. Part No. Part Name Q'ty Remarks KW1-M12DA-10 TENSION LEVER ASSY 1 KJK-M14D0-00 REEL PLA TE ALL ASSY 1 Can not sell KJK-M14D1-00 REEL PLA TE ASSY 1 1 KW1-M12DL-00 SPRING 1 2 TENSION LEVER 1 3 LEVER MET AL 1 4 15I…
No. Part No. Part Name Q'ty Remarks
KJW-M116D-00
TENSION LEVER ASSY
1
KJK-M119L-00
IDLE ROLLER ASSY
1
KJW-M1192-00
INDENTATION LEVER ASSY
1
KJK-M119F-01 DRIVE ROLLER ASSY
1
KJW-M119A-00
I. ROLLER ALL ASSY
1
KJW-M1191-00
D. ROLLER ALL ASSY
1
1 KJW-M116J-00
METAL SHAFT
1
2
LEVER METAL
1
3
INDENTATION LEVER
1
4
ARM STUD
1
5
KJK-M119K-00 SPRING
1
6
LG4-M1A85-00 ROLLER
1
7 KJW-M116F-00 TENSION LEVER AXIS PIN
1
8
TENSION LEVER
1
9 KW1-M119P-00
SPRING
1
10
ROLLER AXIS
1
11
KJK-M11A1-00 LOWER GUIDE PLATE,R
1
12
KJW-M11A3-00 LOWER GUIDE PLATE,L
1
13
KJW-M119C-00 PLANE WASHER
2
14
K87-M111C-00 PLANE WASHER 1
15
K87-M111P-00 SCREW, FLAT HEAD +
1
16
K87-M11BB-00 SCREW, FLAT HEAD + 2
17
LG4-M1ADC-00 SCREW, PAN HEAD +
1
18
K87-M111N-00 SCREW, PAN HEAD +
1
19 K87-M53BS-00
SCREW, PAN HEAD +
2
20 LG4-M1AD1-00
CIRCULAR RIVET
1
*Attention
21 KJK-M119W-00
WASHER
2
KJW-M119A-00
Continued from
Page 2-1
KJW-M116D-00
KJK-M119L-00
KJW-M1192-00
KJK-M119F-01
KJW-M1191-00
KJK-FS2-0911
2
5
ROLLER UP Unit 25-A (15in)
FT/FS2/FSI-84,82(A type)8mm
*Attention: This parts need press t and training.
*Attention:
圧入部品のため修理依頼を推奨します。
No. Part No. Part Name Q'ty Remarks
KW1-M12DA-10 TENSION LEVER ASSY 1
KJK-M14D0-00 REEL PLATE ALL ASSY 1 Can not sell
KJK-M14D1-00 REEL PLATE ASSY 1
1 KW1-M12DL-00
SPRING
1
2
TENSION LEVER
1
3
LEVER METAL
1
4
15INCH REEL PLATE
1
5
METAL AXIS
1
6
REEL AXIS
1
7
K87-M55BN-00 SCREW, FLAT HEAD +
2
8 KW1-M45BG-00
SCREW, FLAT HEAD +
1
9 K87-M11D7-20 CIRCLIP C 1
10 S027-M0489-Y0
SERIAL NO. STICKER (FS2-82-15") 1
Shipment history conrmation and
user identication are necessary.
SERIAL NO. STICKER (FS2-84-7") 1
11 KW1-M11AA-00
ROHS STICKER
1
KJK-M14D0-00
KJK-M14D1-00
KW1-M12DA-10
KJK-FS2-1101
2
6
15inch REEL HOLDER Unit 25-A (15in)
FS2-84,82(A type)8mm-15Inch
No. Part No. Part Name Q'ty Remarks
KJW-M1110-00
BODY ASSY
1
KJW-M122A-00
RACKING LEVER ASSY
1
KJK-M1220-00
SPROCKET ASSY
1
1
BODY
1
2 KJK-M1112-01
KNOCK PIN (FRONT)
1
3 KW1-M1113-000
KNOCK PIN (REAR)
1 *Attention
4 METAL
1
5
RIVET
3
6
SPROCKET
1
7
RATCHET
1
8
RACKING LEVER
1
9
KJK-M121E-00 SPRING
1
10
RACKING POLE
1
11
POLE AXIS
1
12
MAIN ARM
1
13
MAIN ARM AXIS
1
14
KJW-M112P-00 RATCHET AXIS
1
15
KJK-M112D-00 COIL SPRING
1
16
SPRING HOOK PIN
2
17
KJK-M111H-00 BACK STOPPER 1
18
KJK-M111A-00 SPRING
1
19
KJK-M111B-00 BACK STOPPER AXIS
1
20
KJK-M111F-00 STOPPER PIN 1
21
KJK-M114V-00 GUIDE PLATE 1 1
22
K87-M111G-00 PUSH PIN
2
23 K87-M111T-00
SCREW, SET
1
24 K87-M111X-00
SCREW, SET
2
25 K87-M111R-00
SCREW, SET 5
26 K87-M11BB-00
SCREW, FLAT HEAD + 1
27 LG4-M1AD1-000
CIRCULAR RIVET 2 *Attention
28
STRAIGHT PIN
1
29
DU BUSH
1
30
SERIAL NO. STICKER (FT-84)
1
SERIAL NO. STICKER (FS2-84-7")
1
SERIAL NO. STICKER (FS2-84-15")
1
KJW-M1110-00
Continued on
Page 3-4,3-5
KJW-M122A-00
KJK-M1220-00
KJK-FS2-0911
3
1
BODY & RACHET Unit 47-A(7in)
FT/FS2-84(A type)8mm-4P
*Attention: This parts need press t and training.
*Attention:
圧入部品のため修理依頼を推奨します。
