PREVENTIVE MAINTENANCE CLEANING, LUBRICATION AND MAINTENANCE DIAGRAMS 28.62 Technical Reference Manual Chapter Issue 5, Aug 14 Figure 28-4 Print Carriage P l an View o n M a c hine Print Carriage Linear Bearing Guides
PREVENTIVE MAINTENANCE
CLEANING, LUBRICATION AND MAINTENANCE DIAGRAMS
Chapter Issue 5, Aug 14 Technical Reference Manual 28.61
Figure 28-3 Board Opto Locations
Opto Sensor
Area to be cleaned
Diffuse OptoBoard s
(in 4 positions)
NOTE
Board at Left oard at Right, B, Left Auxiliary Rail and Right
Auxiliary Rail Optos look up. Board at Stop Opto looks down.
Plan View on Machine
Camera Board Stop
Board at Stop
DiffuseOpto
KEYENCE
PZ-42L
KEYENCE
PZ-42L
KEYENCE
PZ-42L
KEYENCE
PZ-42L
PREVENTIVE MAINTENANCE
CLEANING, LUBRICATION AND MAINTENANCE DIAGRAMS
28.62 Technical Reference Manual Chapter Issue 5, Aug 14
Figure 28-4 Print Carriage
Plan View on Machine
Print Carriage Linear Bearing Guides
PREVENTIVE MAINTENANCE
CLEANING, LUBRICATION AND MAINTENANCE DIAGRAMS
Chapter Issue 5, Aug 14 Technical Reference Manual 28.63
Figure 28-5 Camera System
Camera Y Linear Bearing Guide (left)
Camera Y Linear Bearing Guide (right)
Camera Y Encoder Strip
Camera X Encoder Strip
Camera X Linear Bearing Guide
View on Underside of Camera Mechanism
Camera
Camera Y Magnet Track
Camera X Magnet Track
