POWER SUPPLY AND DISTRIBUTION M37 POWER SUPPLY ENCLOSURE Chapter Issue 3, Nov 14 Technical Reference Manual 6.17 M37SK27 M37SK30 M37SK31 - M37SK35 Pin No. Signal Pin No. Signal 1 S ystem Button 9 Ri ght Jog Button 2 S ys…
POWER SUPPLY AND DISTRIBUTION
M37 POWER SUPPLY ENCLOSURE
6.16 Technical Reference Manual Chapter Issue 3, Nov 14
M37SK24
M37SK25
M37PL26
Pin No. Signal Pin No. Signal
1 External E Stop Link to Pin 5 4 N/C
2 External E Stop Link to Pin 3 5 External E Stop Link from Pin 1
3 External E Stop Link from Pin 2 6 N/C
1
4
6 Way Trident
Pin No. Signal Pin No. Signal
1 E Stop Loop to Pin 5 4 N/C
2 E Stop Loop to Pin 3 5 E Stop Loop from Pin 1
3 E Stop Loop from Pin 2 6 N/C
1
4
6 Way Trident
Pin No. Signal Pin No. Signal
1 N/C 6 Cover Interlock
2 Jog Left 7 E Stop Loop Supply
3 Jog Right 8 0V
4N/C 9N/C
5 Power On Monitor
1
9
9 Way D Type
Plug
POWER SUPPLY AND DISTRIBUTION
M37 POWER SUPPLY ENCLOSURE
Chapter Issue 3, Nov 14 Technical Reference Manual 6.17
M37SK27
M37SK30
M37SK31 - M37SK35
Pin No. Signal Pin No. Signal
1 System Button 9 Right Jog Button
2 System Button 10 Right Jog Button
3 System Lamp 11 Right Jog Button
4 System Lamp 12 Right Jog Button
5 Left Jog Button 13 RSVD (Cat 4)
6 Left Jog Button 14 RSVD (Cat 4)
7 Left Jog Button 15 N/C
8 Left Jog Button
1
15
15 Way D Type
Socket
Pin No. Signal Pin No. Signal
1 USB Supply 3 USB Data +ve
2 USB Data -ve 4 USB Ground
Pin No. Signal Pin No. Signal
1Live 3Earth
2Neutral
1
4
USB Type B
Socket
1
2
AC Mains
Socket
3
PNEUMATIC MODULE
ELECTRICAL SCHEMATIC
Chapter Issue 2, Aug 14 Technical Reference Manual 24.3
ELECTRICAL SCHEMATIC
M36Machine
Control Enclosure
Main Machine
I/ONode 2
N2PL7
M39PL4
16SK37
N2SK2
1
2
3
DIG IN0
Air Pressure SW
8SE11
+12V
Sig
0V
PC
USB
Motherboard
NextMove ES
(I/O Node 1
)
1
2
4
CAN_H
CAN_L
CAN GND
M36PL35
CAN Bus
CAN In
N3SK2
7
2
3
CAN In
N2SK2
7
2
3
CAN Out
N3SK3
7
2
3
Print Carriage
I/ONode 3
N3SK8
N2SK4
NOTE
The breaks
in the CAN Bus cha
in reflect that
additionalI/O Nodes
may be f
itted, refer to
Machine Contro
l chapter for the co
mplete
CAN Bus cha
in.
9SK28
Auto Drip Tray
9SOL28
DIG OUT 6
0V
4
12
+
-
9SK27
Paste Disp
.
Tilt
9SOL27
DIG OUT 5
0V
3
11
+
-
16SK22
Rail Board Stop
16SOL22
DIG OUT 12
0V
6
16
1
3
9SK26
Paste Disp
.
9SOL26
DIG OUT 4
0V
2
10
+
-
9SK25
ProFlow Paste PX
9SOL25
DIG OUT 3
0V
1
9
+
-
16SK14
Board Stop/RTC
Rail Width C
lamp
16SOL14
DIG OUT 10
0V
4
16
1
3
16SK10
Board C
lamps
16SOL10
DIG OUT 9
0V
9
16
1
3
9SK29
Screen Load
9SOL29
DIG OUT 7
0V
5
13
+
-
16SK07
Screen C
lamps
16SOL07
DIG OUT 8
0V
2
15
+
-
16SK31
Chase C
lamps
16SOL31B
DIG OUT 7
0V
1
14
+
-
16SK08
USC Squeegee
16SOL08
DIG OUT 14
0V
9
21
+
-
16SK31
16SK03
Lid Bolt
16SOL31A
Inroad Vane Lift
(RTC Machine
)
16SOL03
Venturi Vac Unit
8SOL24
Pneumatic
Dump Valve
16SOL37
DIG OUT 11
DIG OUT 15
DIG OUT 0
0V
0V
0V
5
22
1
1
14
23
2
2
+
+
+
+ve
-
-
-
-ve
Machine Rear Solenoids
Print Carriage Solenoids
M39Emergency
Machine Off
Enclosure
