PREVENTIVE MAINTENANCE DAILY MAINTENANCE Chapter Issue 5, Aug 14 Technical Reference Manual 28.9 NOTE Any items heavily cont aminated requiring thorough cleaning must b e re-lubri- cated in accordance with the appropriat…
PREVENTIVE MAINTENANCE
DAILY MAINTENANCE
28.8 Technical Reference Manual Chapter Issue 5, Aug 14
4 Screen Change Mechanism:
a. Auto Drip Tray
b. Auto Drip Tray Actuator Pistons
Remove any debris and clean.
Spatula,
IPA Impreg-
nated Wipes
Screen Change Mechanism
5 Adjustable Screen Mount (ASM):
a. ASM Assembly
b. Pulley Assemblies
c. Stencil Guide Strips
Remove any debris and clean.
Spatula,
IPA Impreg-
nated Wipes
Adjustable Screen Mount
(ASM)
6 Camera:
a. Up and down camera lens
b. Board at stop opto
Remove any debris and clean.
Spatula,
IPA Impreg-
nated Wipes
Board Opto Locations
7 Underscreen Cleaner:
a. Linear Bearings
b. Magnet Assemblies
Remove any debris and clean.
Spatula,
IPA Impreg-
nated Wipes
Underscreen Cleaner
8 Board Optos:
Clean the top of the board at left,
board at right, left auxiliary conveyor
and the right auxiliary conveyor sen-
sors.
Spatula,
IPA Impreg-
nated Wipes
Board Opto Locations
9 Tooling:
Remove any debris and clean.
Spatula,
IPA Impreg-
nated Wipes
Rising Table
10 Rising Table:
a. Manual tooling plate of the rising
table
b. Clatter bars
c. LED stencil backlight panel
Remove any debris and clean.
Spatula,
IPA Impreg-
nated Wipes
Lint-free cloth
Rising Table
Rail System
11 Machine Covers:
Remove any debris and clean.
NOTE
1. Use only soap and water on the
machine viewing panels.
2. If the front left hand corner panel
has been removed for cleaning,
carry out an EMO functional check
on completion of the daily mainte-
nance.
Spatula,
IPA Impreg-
nated Wipes
Machine Covers
SEMI Level No Task Tools Completed Reference Figure
SEMI1
SEMI1
SEMI1
SEMI1
SEMI1
SEMI1
SEMI1
SEMI1
PREVENTIVE MAINTENANCE
DAILY MAINTENANCE
Chapter Issue 5, Aug 14 Technical Reference Manual 28.9
NOTE
Any items heavily contaminated requiring thorough cleaning must be re-lubri-
cated in accordance with the appropriate monthly maintenance task, where
appropriate.
12 HTC Flat Belt Option:
a. Remove debris.
b. Check for any wear of belt coating or
damage.
c. If contaminated with flux, replace
belts.
Spatula
13 TRS Option:
a) Remove debris
b) Clean surfaces; Rail Cap; Active
Surround; Tooling Caps; TRP; Vacuum
Chamber and area beneath the rails;
Contact points under the TRP.
DO NOT IMMERSE TOOLING
Spatula
Lint Free Cloth
De-ionized
water
Estimated time required for daily tasks 15.0 mins
SEMI Level No Task Tools Completed Reference Figure
SEMI1
SEMI1
Summary/Remarks
Signed: Date:
PREVENTIVE MAINTENANCE
DESCRIPTION OF THE MONTHLY MAINTENANCE SCHEDULE
28.10 Technical Reference Manual Chapter Issue 5, Aug 14
DESCRIPTION OF THE MONTHLY MAINTENANCE SCHEDULE
Introduction Two modules form the basis of the monthly schedule. The process requires that
each month a machine repeatability check is performed on Squeegee Pressure
and the X, Y and Theta axes. This is done using the Statistical Process Control
(SPC) data collection program (where available).
Module 1 The first module comprises the following elements:
• SPC Alignment Check - used to set a benchmark each month, the hard-
ware is checked to give a snapshot of the machine condition, performance
is monitored to predict failure before it has an affect on production.
• Machine Cycle Count - machine usage is logged in the table.
• A Software Check is carried out, if a newer version is available this may
contain known defect fixes or equipment enhancements. The service
engineer can recommend an upgrade for the equipment in service. In
addition, the machine event log is checked to identify any re-occurring
errors which if not inspected/diagnosed may lead to unplanned downtime.
• A standard Monthly Maintenance Check consists of a series of mainte-
nance tasks which are performed every month.
Machine safety checks are carried out on a basis as laid down in the monthly
schedule. In addition, the engineer performs maintenance on set machine
modules, checks software version and records the cycle count.
Module 2 In this module, over the course of a year, the following assemblies are checked.
• Printhead
• All Electrical Enclosures
• Camera System
• Squeegee Mechanism
• Rising Table
• Paste Dispenser
• ProFlow
• Temperature Control Module (TCM)
• Screen Alignment
• DC Supplies
• Vacuum Filtration Unit
• Pneumatic System
• Safety System
• Rail System
• Print Carriage
• Machine Level
• Screen Change
• Adjustable Screen Mount (ASM)
• Topside Referencing System (TRS) Option
