Station Software 706.1 / Installation Manual Ausgabe 11/2012 Edition
20
Name SIMATIC Box PC 827B
CPU / clock frequency Core 2 Duo T7400 / 2.16 GHz
RAM 2 GB
Harddisk Yes
External DVD drive No
Internal DVD drive No
Serial interfaces 1
USB interfaces Yes
External USB hub No
Network 2x 100 MBit
Table 4-8: Machine/Vision computer hardware SIPLACE X-series and SX4
Name SIMATIC Box PC 827C
CPU / clock frequency Intel(R) Core(TM) i3 / 2.13 GHz
RAM 2 GB
Harddisk Yes
External DVD drive Yes
Internal DVD drive No
Serial interfaces 1
USB interfaces and external USB
hub
Yes
Network 2x 100 MBit
Table 4-9: Machine/Vision computer hardware SIPLACE X-series
Station Software 706.1 / Installation Manual Ausgabe 11/2012 Edition
21
4.3 Network Configuration
Machine
computer
Vision computer
10Base-T
or 100Base-T
cross-over cable
100Base-T
cross-over cable
Private network between
machine computer and Vision
computer
SIPLACE LAN
or
customer LAN
SIPLACE Pro
Twisted pair TP
(100 Mbit/s)
Twisted pair TP
(10 or 100 Mbit/s)
Figure 4-1: Network connections between the machine and SIPLACE Pro
In two-computer operation a separate private network (100 Mbit/s) is set up between the machine
computer and the Vision computer via a subnet mask.
Fixed IP addresses for the machine computer and the Vision computer can thus be assigned for all
SIPLACE machines. These IP addresses are not known outside the private network, for instance in
the SIPLACE LAN or customer LAN.
These IP addresses need not be further configured by the operator while the station software is
being installed.
Station Software 706.1 / Installation Manual Ausgabe 11/2012 Edition
22
5 Installing the Machine Computer
5.1 Installation Sequence
Back up the machine data
Install Windows XP/Windows XP
Embedded operating system for the
machine computer
(including installation of the touchscreen)
BIOS settings on the
machine computer
Perform BIOS settings
Install SIPLACE Software
(station software incl. additional programs)
BIOS update on the
machine computer
Perform BIOS update
Finish the installation
See separate Installation Manuals for details on
installing the Windows XP, Windows XP Embedded
or Windows 7 operating system (item no. 00196151-
xx, 00196737-xx and 00197366-xx respectively)
For details on calibrating the touchscreen, see section
5.2.3.
See section 5.3.
See section 5.3.
See section 5.4.
See section 5.4.7.
Figure 5-1: Installation sequence
