PARTS LIST
KMH-1806(PL)
Auto Tray Sequencer
sATS 30NS
KMH-1806
1 / 3
Contents
1 Base Section
2 Cover Section
3 AZ-Axis Section
1-1 Valve / Contactor 1-2 Board / Duct
1-4 Base Sub
1-3 Table / Shutter
2-1 Frame Assy 2-2 Cover 2-3 Door
3-1 AZ-Axis
4 Rack Section
4-1 Rack Assy 1 4-2 Rack Assy 2
5 Pallet Section
5-1 Pallet
KMH-1806
2 / 3
Contents
7 Hook Section
6 Magazine Section
6-1 Shutter / Duct 6-2 Rack Lock 6-3
Supply Shutter Cylinder
6-4 Bottom Plate
7-1 Hook sub 7-2 Hook guide 7-3 Hook drive
8 Table Section
8-1 Duct 8-2 Drive
7-4 Guide 7-5 Base / Spring assy
