sATS30NS_KMH_pl - 第6页

20 22 21 29 29 12 3 17 30 28 5 25 14 11 18 27 26 15 26 15 16 4 28 18 11 24 2 4 24 23 23 1 13 9 23 6 32 7 23 1 8 7 23 26 10 31 31 26 32 19 23 Board / Duct 20 22 21 29 29 12 3 17 30 28 5 25 14 11 18 27 26 15 26 15 16 4 28 …

100%1 / 31
17
18
19
10
13
26
23
24
6
27
32
1
7
28
11
6
24
30
25
23
21
22
14
29
26
26
12
31
16
15
31
20
30
27
26
Valve / Contactor
17
18
19
10
13
26
23
24
6
27
32
1
7
28
11
6
24
30
25
23
21
22
14
29
26
26
12
31
16
15
31
20
30
27
26
Base
KMH-1806
1-1
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
$AUKM6-01
JOINT
1
2
$KM-11
MUFFLER
1
3
$PL6-01
JOINT
1
4
$UT6
JOINT
1
5
KGS-M4574-01
INDI CTRL BOARD ASSY
1
6
KHY-M537F-00
SAFETY RELAY
2
7
KLF-M537G-20
CONTACTOR,1
2
8
KLF-M537G-40
CONTACTOR,1
2
9
KLX-M1121-01
STAY,SW.
1
10
KMA-M1120-A0
PRESSURE SW.ASSY.
1
11
KMA-M653S-00
SEN.AIR PRESS.ASSY
1
12
KMH-M1104-00
PLATE,C
1
13
KMH-M1107-00
PLATE,F
1
14
KMH-M1120-00
BRKT.,SAFETY 1
1
15
KMH-M1121-00
BRKT.,SAFETY 2
1
16
KMH-M1125-00
COVER,TOP
1
17
KMH-M11C0-00
CONTACTOR ASSY.
1
18
KMH-M11F0-00
CONTACTOR2 ASSY.
1
19
KMH-M11K0-00
COVER NS ASSY.
1
20
KMH-M5126-B0
SAFETY SW ASSY
1
21
KMH-M5126-C0
SAFETY SW ASSY
1
22
KMH-M653R-00
VALVE ASSY
1
23
KMF-M6523-00
RELAY SOCKET
2
24
KMF-M6521-00
RELAY,RJIS D24
2
25
KV9-M444A-00
RESISTOR 1
3
26
90990-11J003
SCREW, PAN HEAD W/W
9
27
90990-12J001
SCREW, BIN. HEAD W/W
4
28
91312-03006
BOLT HEX,SOCKET HEAD
2
29
91312-04025
BOLT HEX,SOCKET HEAD
2
30
91312-04035
BOLT HEX,SOCKET HEAD
6
31
91312-06012
BOLT HEX,SOCKET HEAD
4
32
98902-03006
SCREW BINDING HEAD
4
20
22
21
29
29
12
17
30
28
5
25
14
11
18
27
26
15
26
15
16
28
18
11
24
2
24
23
23
13
9
23
6
32
7
23
1
7
23
26
10
31
31
26
32
19
23
Board / Duct
20
22
21
29
29
12
17
30
28
5
25
14
11
18
27
26
15
26
15
16
28
18
11
24
2
24
23
23
13
9
23
6
32
7
23
1
7
23
26
10
31
31
26
32
19
23
Base
KMH-1806
1-2
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
$NK-3N
NYLON CLIP
4
2
$US4
JOINT
16
3
$USD6-4
JOINT
1
4
KKX-M6555-00
JUNCTION BOX V
4
5
KLA-M4476-25
FDR.CTRL.BRD.ASSY.
1
6
KLA-M4506-01
HEAD I/O UNIT ASSY
1
7
KLA-M5802-49
HEAD SERVO UNIT ASSY
2
8
KLW-M112A-00
BASE,BOARD
1
9
KLW-M112B-00
COVER,BOARD
1
10
KLW-M112D-00
HOLDER,BOARD
2
11
KMA-M172B-00
TAPE 2,AZ DUCT
1
12
KMH-M1105-00
PLATE,D
1
13
KMH-M1106-00
PLATE,CONV.
1
14
KMH-M1108-00
PLATE,J1
1
15
KMH-M1109-00
STAY,DUCT
2
16
KMH-M1116-00
PLATE,J2
1
17
KMH-M1117-00
CABLE DUCT
1
18
KMH-M1124-00
TAPE 1,AZ DUCT
1
19
KMH-M1129-00
PANEL,A
1
20
KMH-M11D0-00
FE.&SER. BOARD ASSY.
1
21
KMH-M11D0-A0
CONV.CONT.BOX ASSY.
1
22
KMH-M11J0-00
CABLE DUCT ASSY.
1
23
90990-11J003
SCREW, PAN HEAD W/W
18
24
90990-11J007
SCREW, PAN HEAD W/W
8
25
90990-12J004
SCREW, BIN. HEAD W/W
4
26
91312-04006
BOLT HEX,SOCKET HEAD
8
27
91312-04014
BOLT HEX,SOCKET HEAD
2
28
91312-05006
BOLT HEX,SOCKET HEAD
8
29
91312-05010
BOLT HEX,SOCKET HEAD
4
30
97602-03106
SCREW PAN HEAD W/WASHER
7
31
98702-03006
SCREW,FLAT HEAD
4
32
98902-03006
SCREW BINDING HEAD
6
12
30
33
33
33
29
32
33
16
25
33
14
27
33
35
1
29
24
26
16
1
13
11
14
2
31
16
28
3
38
2
31
16
28
10
31
25
31
34
17
18
19
15
37
34
34
21
33
33
37
36
33
21
30
33
22
31
36
33
22
23
20
34
34
Table / Shutter
12
30
33
33
33
29
32
33
16
25
33
14
27
33
35
1
29
24
26
16
1
13
11
14
2
31
16
28
3
38
2
31
16
28
10
31
25
31
34
17
18
19
15
37
34
34
21
33
33
37
36
33
21
30
33
22
31
36
33
22
23
20
34
34
Base
KMH-1806
1-3
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
$SC4-M5A
SPEED CONTROLLER
2
2
KHT-M3617-10
BUSH
2
3
KLV-M13B5-00
JOINT,CYL.
1
4
KLX-M18AS-00
CAM,FOLLOWER
2
5
KMH-M1118-00
PLATE 1,CAM L
1
6
KMH-M1119-00
PLATE 2,CAM L
1
7
KMH-M1122-00
PLATE,CAM R
1
8
KMH-M1126-00
PLATE,EARTH
1
9
KMH-M1127-00
STAY,PANEL
1
10
KMH-M1128-00
STAY,PANEL
1
11
KMH-M11A0-00
BASE SUB ASSY.
1
12
KMH-M11G0-00
SHUTTER ASSY.
1
13
KMH-M11G1-00
BASE,SHUTTER
1
14
KMH-M11G2-00
SHAFT,SHUTTER
2
15
KMH-M11G3-00
PLATE,SHUTTER
1
16
KMH-M11G5-00
DAMPER,SHUTTER
4
17
KMH-M11G6-00
BRKT.,SENSOR
1
18
KMH-M11H0-00
TABLE BASE ASSY.
1
19
KMH-M11H1-00
PLATE,BASE
1
20
KMH-M11H2-00
PLATE,TOP
1
21
KMH-M11H3-00
LIB
2
22
KMH-M11H4-00
STAY,DUCT
2
23
KMH-M11H5-00
COVER,BELT
1
24
KMH-M653J-00
SEN,SHUTTER OP ASSY
1
25
KMH-M5126-A0
SAFETY SW ASSY
1
26
$NK-6N
NYLON CLIP
3
27
90990-11J001
SCREW, PAN HEAD W/W
3
28
90990-12J004
SCREW, BIN. HEAD W/W
4
29
90990-28J003
WASHER,PLAIN
2
30
90990-28J059
WASHER,PLAIN
4
31
91312-04008
BOLT HEX,SOCKET HEAD
12
32
91312-04012
BOLT HEX,SOCKET HEAD
2
33
91312-05010
BOLT HEX,SOCKET HEAD
18
34
91312-05016
BOLT HEX,SOCKET HEAD
16
35
91312-05030
BOLT HEX,SOCKET HEAD
2
36
91312-08016
BOLT HEX,SOCKET HEAD
6
37
99480-04008
PIN,PARALLEL
2
38
99480-06018
PIN,PARALLEL
1
