G -S014-01 1012-004 185 Key No. P AR T No. P AR T NAME Q’ty REMARKS New Code NOTE G-1 1 6301295978 COVER 1 803G-A210030-A001 21 1A8925 2 6301299587 COVER 1 803G-A210030-A002 21 1A8972 4 6301500683 COVER 1→0 829G--010-104…
G -S014-01
0909-003
184
51
10
13
51
51
51
1
51
51
See Fig.B-1
Key No.1
2
51
51
51
24
26
25
See Fig.TL-1
Key No.38
See Fig.EL-8
Key No.722
10
17
4
ADD
EXCHANGE
EXCHANGE
EXCHANGE
61
62
63
41
51
38
51
51
37
40
39
FP-G200L
取付
Main Machine(GXH-1J,1JS) Modification
本体
(GXH-1J,1JS)
対応（左奥）
(Left-Rear) For Attaching FP-G200L
G -S014-01 G -S014-01
Fig. G-1
カバー部 - 下カバー
Cover Section-Lower Cover
G -S014-01
1012-004
185
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
G-1
1 6301295978 COVER 1
803G-A210030-A001
211A8925
2 6301299587 COVER 1
803G-A210030-A002
211A8972
4 6301500683 COVER 1→0 829G--010-104 211AB200
10
6301570136 COVER 2→1 829G--010-110 211AB984
13 6301295954 PLATE 1
803G-A210030-A003
211D9842
17 6301489841 PLATE 1→0 829G--010-117 211DB985
24 6301313610 COVER 1
803G-A210030-A004
211A9201
25 6301313634 BRACKET 1
803G-A210030-A005
211F8959
26 6301313641 BRACKET 1
803G-A210030-A006
211F8960
37 6301389622 COVER 1
803G-A210030-A007
211AA011
38 6301389639 COVER 1
803G-A210030-A008
211AA012
39 6301313740 COVER 1
803G-A210030-A009
211A9202
40 6301389646 COVER 1
803G-A210030-A010
211AA013
41 6301381480 PLATE 2
803G-A210030-A011
211DA701
61 6300008005 BOLT,HEX-SCT 4 M8X16 221A0055
62
4111413100 WASHER SPR 8 4 SW8 221H0291
63
4111414503 WASHER V 8X17X1.6 4 FW8 221H0323
G -S014-01
0909-003
186
166
166
111
166
A
B
E
F
DELETE
111
See Fig.B-1
Key No.1
A
B
E
F
FP-G200L
取付
Main Machine(GXH-1J,1JS) Modification
本体
(GXH-1J,1JS)
対応（左奥）
(Left-Rear) For Attaching FP-G200L
G -S014-01 G -S014-01
Fig. G-2
カバー部 - 中カバー
Cover Section-Middle Cover
