G -S014-02 1012-004 201 Key No. P AR T No. P AR T NAME Q’ty REMARKS New Code NOTE 1 6301295961 COVER 1 803G-A210040-A001 21 1A8924 2 6301299594 COVER 1 803G-A210040-A002 21 1A8973 3 6301500676 COVER 1→0 829G--010-103 21 …
G -S014-02
0909-003
200
51
10
51
51
51
1
51
51
13
See Fig.B-1
Key No.1
51
51
24
25
26
See Fig.TR-1
Key No.38
See Fig.ER-8
Key No.721
2
3
18
10
EXCHANGE
EXCHANGE
ADD
EXCHANGE
61
62
63
41
51
51
51
40
37
39
38
FP-G200R
取付
Main Machine(GXH-1J,1JS) Modification
本体
(GXH-1J,1JS)
対応（左前）
(Left-Front) For Attaching FP-G200R
G -S014-02 G -S014-02
Fig. G-1
カバー部 - 下カバー
Cover Section-Lower Cover
G -S014-02
1012-004
201
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
1 6301295961 COVER 1
803G-A210040-A001
211A8924
2 6301299594 COVER 1
803G-A210040-A002
211A8973
3 6301500676 COVER 1→0 829G--010-103 211AB199
10
6301570136 COVER 2→1 829G--010-110 211AB984
13 6301299570 PLATE 1
803G-A210040-A003
211D9888
18 6301489872 PLATE 2→1 829G--010-118 211DB986
24 6301312279 COVER 1
803G-A210040-A004
211A9188
25 6301312552 BRACKET 1
803G-A210040-A005
211F8937
26 6301312286 BRACKET 1
803G-A210040-A006
211F8934
37 6301389622 COVER 1
803G-A210040-A007
211AA011
38 6301389653 COVER 1
803G-A210040-A008
211AA014
39 6301312187 COVER 1
803G-A210040-A009
211A9186
40 6301389660 COVER 1
803G-A210040-A010
211AA015
41 6301381480 PLATE 2
803G-A210040-A011
211DA701
61 6300008005 BOLT,HEX-SCT 4 M8X16 221A0055
62
4111413100 WASHER SPR 8 4 SW8 221H0291
63
4111414503 WASHER V 8X17X1.6 4 FW8 221H0323
G-1
G -S014-02
0909-003
202
166
166
111
166
A
B
E
F
DELETE
111
See Fig.B-1
Key No.1
A
B
E
F
FP-G200R
取付
Main Machine(GXH-1J,1JS) Modification
本体
(GXH-1J,1JS)
対応（左前）
(Left-Front) For Attaching FP-G200R
G -S014-02 G -S014-02
Fig. G-2
カバー部 - 中カバー
Cover Section-Middle Cover
