MODEL FP-G200 R 1012-003 30 Key No. P AR T No. P AR T NAME Q’ty REMARKS New Code NOTE 660 6300007770 BOL T ,HEX-SCT 1 M5X20 221A0032 661 6300007800 BOL T ,HEX-SCT 4 M5X35 221A0035 662 6300007817 BOL T ,HEX-SCT 2 M5X40 22…
MODEL FP-G200R
1012-003
29
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
601 6301292571 GUIDE,LINEAR 2 806ER-510-401 222L0717
602 6300011401 BEARING,RADIAL 4 806ER-510-402 222D0019
603
6300963717 CAM FOLLOWER 2 806ER-510-403 222H0118
604
6301282497 CYLINDER 2 -B0422,-B0423,-B0424,
-B0425 806ER-510-404 224C0549
605
6301282510 AIR LINE EQPT 4 806ER-510-405 225B0514
606
6301292151 SOLENOID VALVE 1 -Y0532 806ER-510-406 4L810336
607
6300969221 AIR LINE EQPT 2 806ER-510-407 225B0374
608
6301282527 PIPE FITTINGS 1 806ER-510-408 225F0603
609
6300955026 AIR LINE EQPT 2 806ER-510-409 225B0367
610
6300363012 LINK 2 806ER-510-410 214B0010
611
6301165882 SENSOR,PELEC 2 -B0421,-B0512
806ER-510-411 23G00227
612
6300325287 SENSOR,PHOTO 2 -B0426,-B0513
806ER-510-412 23G10029
613
6300018332 SPRING,TENSION 1 806ER-510-413 222N0109
614
6300725803 MACHINE SCREW 24 806ER-510-414 221D0107
615
6300725797 HANDLE 1 806ER-510-415 226C0111
621 6301292274 PLATE 1 806ER-510-301 211D9801
622
6301292311 PLATE 1 806ER-510-302 211D9805
623
6301292328 PLATE 1 806ER-510-303 211D9806
624
6301283302 HINGE 1 806ER-510-304 226F0151
625
6301283296 PIN,HINGE 4 806ER-510-305 216D0465
626
6301283326 LEVER 1 806ER-510-306 216S2678
627
6301283333 LEVER 1 806ER-510-307 216S2679
628
6301283357 LEVER 2 806ER-510-308 216S2680
629
6301283319 HOLDER 2 806ER-510-309 216B1432
630
6301283340 COLLAR 2 806ER-510-310 216A1159
631
6301283500 BLOCK 2 806ER-510-311 211G3588
632 6301283777 BRACKET 1 806ER-510-312 211F8534
633
6301299662 DISK 1 806ER-510-313 213D1172
634
6301302263 SHAFT 1 806ER-510-314 213A1116
635 6301292434 BLOCK 1 806ER-510-315 211G3659
636
6301292687 SHAFT 1 806ER-510-316 213A1094
637
6301292281 PLATE 1 806ER-510-317 211D9802
638
6301283876 GRIP 1 806ER-510-318 226D0110
639
6301283883 COLLAR 1 806ER-510-319 216A1161
640
6301294810 SPRING,COMP 1 806ER-510-320 222M1342
641
6301294728 BRACKET 1 806ER-510-321 211F8699
642
6301294735 BRACKET 1 806ER-510-322 211F8700
643
6301294742 BRACKET 1 806ER-510-323 211F8701
651
6300007541 BOLT,HEX-SCT 4 M3X14 221A0009
652
6300007572 BOLT,HEX-SCT 3 M3X25 221A0012
653
6300007602 BOLT,HEX-SCT 2 M4X6 221A0015
654
6300007633 BOLT,HEX-SCT 3 M4X12 221A0018
655
6300007657 BOLT,HEX-SCT 4 M4X16 221A0020
656
6300007671 BOLT,HEX-SCT 1 M4X25 221A0022
657
6300007688 BOLT,HEX-SCT 3 M4X30 221A0023
658
6300007756 BOLT,HEX-SCT 5 M5X12 221A0030
659
6300007763 BOLT,HEX-SCT 4 M5X16 221A0031
ER-7
MODEL FP-G200R
1012-003
30
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
660 6300007770 BOLT,HEX-SCT 1 M5X20 221A0032
661 6300007800 BOLT,HEX-SCT 4 M5X35 221A0035
662
6300007817 BOLT,HEX-SCT 2 M5X40 221A0036
663
6300858310 BOLT,HEX-SCT 8 M6X14 221A0240
664
4110420703 SCR PAN 3X8 4 M3X8 PAN 221E0499
665
4111409905 NUT HEX 3 8 M3 221F0079
666
4111410406 NUT HEX 4 3 M4 221F0104
671
4111412806 WASHER SPR 3 10 SW3 221H0281
672
4111413902 WASHER V 3X7X0.5 10 FW3 221H0312
673
4111412905 WASHER SPR 4 12 SW4 221H0284
674
4111414008 WASHER V 4X9X0.8 10 FW4 221H0315
675
6300010213 WASHER 2 BW4 221H0004
676
4111416705 WASHER SPR 5 10 SW5 221H0287
677
4111414107 WASHER V 5X10X1 9 FW5 221H0318
678
6300010220 WASHER 1 BW5 221H0005
679
4111413001 WASHER SPR 6 8 SW6 221H0289
680
4111414305 WASHER V 6X12.5X1.6 8 FW6 221H0320
ER-7
