MODEL FP-G200L 0410-001 72 エレベータ部 ELEV A TOR SECTION Fig. EL-7 マガジン搭載部２ Magagine Mounter 2 See Fig.EL-6 Key No.502 674 673 . 655 . 678 677 . 660 . 680 679 . 663 . 677 676 . 658 . 623 614 601 601 622 614 657 673 675 633 6…
MODEL FP-G200L
1012-004
71
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
502 6301310244 BASE 1 806EL-510-002 210A2248
507 6301291550 ROTOR 1 806EL-510-007 213G0200
508
6301281902 BRACKET 1 806EL-510-008 211F8492
51
1 6301291628 BLOCK 1 806EL-510-011 211G3646
512 6301291635 SHAFT 1 806EL-510-012 213A1090
513
6301281964 SHAFT 1 806EL-510-013 213A1068
514
6301291642 BRACKET 1 806EL-510-014 211F8648
518
6301474878 BRACKET 1 806EL-510-018 211FB070
524
6301620565 COVER 1 806EL-510-324 211AC663
525
6301292267 COVER 1 806EL-510-325 211A8875
531
6301280622 MOTOR,AC-SERVO 1 -M02 806EL-510-201 4M150212
535
6301280660 PULLEY,TIMING 1 806EL-510-205 223Q0575
536
6301280677 PULLEY,TIMING 1 806EL-510-206 223Q0576
537
6301280684 BELT,TIMING 1 806EL-510-207 223L0274
538
6300960808 COUPLING 1 806EL-510-208 223C0165
543
6300690545 SENSOR,PHOTO 1 -B0202 806EL-510-213 23G10056
544
6301282213 BOLT 2 806EL-510-214 221E0305
545
6301129679 BEARING,RADIAL 3 806EL-510-215 222D0380
546
6301501413 MECH PARTS(CABLEVEYOR) 1 806EL-510-216 226J2305
551
6300007503 BOLT,HEX-SCT 2 M3X6 221A0005
552
6300007527 BOLT,HEX-SCT 2 M3X10 221A0007
553
6300007589 BOLT,HEX-SCT 4 M3X30 221A0013
554
6300007619 BOLT,HEX-SCT 1 M4X8 221A0016
555
6300007633 BOLT,HEX-SCT 2 M4X12 221A0018
556
6300007640 BOLT,HEX-SCT 1 M4X14 221A0019
557
6300007657 BOLT,HEX-SCT 6 M4X16 221A0020
558
6300007664 BOLT,HEX-SCT 2 M4X20 221A0021
559
6300007763 BOLT,HEX-SCT 15 M5X16 221A0031
560
6300007770 BOLT,HEX-SCT 4 M5X20 221A0032
561
6300007794 BOLT,HEX-SCT 4 M5X30 221A0034
562
6300007909 BOLT,HEX-SCT 16 M6X25 221A0045
563
4110024307 SCR FLT 5X10 4 M5X10 FLT 221D0226
564 4111410604 NUT HEX 5 4 M5 221F0107
566
4111412806 WASHER SPR 3 8 SW3 221H0281
567
4111415807 WASHER F 3X6X0.5 6 FWS3 221H0338
568
4111413902 WASHER V 3X7X0.5 2 FW3 221H0312
569
4111412905 WASHER SPR 4 12 SW4 221H0284
570
4111414008 WASHER V 4X9X0.8 12 FW4 221H0315
571
4111416705 WASHER SPR 5 19 SW5 221H0287
572
4111414107 WASHER V 5X10X1 19 FW5 221H0318
573
4111413209 WASHER SPR 10 2 SW10 221H0293
574
4111414701 WASHER V 10X21X2 2 FW10 221H0325
EL-6
MODEL FP-G200L
0410-001
72
エレベータ部
ELEVATOR SECTION
Fig. EL-7
マガジン搭載部２
Magagine Mounter 2
See Fig.EL-6
Key No.502
674
673
.
655
.
678
677
.
660
.
680
679
.
663
.
677
676
.
658
.
623
614
601
601
622
614
657
673
675
633
634
652
613
677
676
.
658
.
664
671
672
612
632
640
662
637
656
675
636
661
631
639
603
666
638
673
654
635
678
676
658
621
615
602
628
665
625
625
604
665
605
624
665
605
625
604
625
665
610
628
602
610
614
674
673
.
655
.
629
602
630
626
677
676
.
659
.
602
629
630
627
603
674
673
.
655
.
611
643
674
673
.
654
.
672
671
.
651
.
674
673
.
657
.
609
606
607
608
672
671
.
652
.
674
673
.
666
.
677
676
.
659
.
674
673
.
666
.
472
471
.
451
.
474
473
.
453
.
411
441
See Fig.EL-6
Key No.524
MODEL FP-G200L
1012-003
73
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
601 6301292571 GUIDE,LINEAR 2 806EL-510-401 222L0717
602 6300011401 BEARING,RADIAL 4 806EL-510-402 222D0019
603
6300963717 CAM FOLLOWER 2 806EL-510-403 222H0118
604
6301282497 CYLINDER 2 -B0422,-B0423,-B0424,
-B0425 806EL-510-404 224C0549
605
6301282510 AIR LINE EQPT 4 806EL-510-405 225B0514
606
6301292151 SOLENOID VALVE 1 -Y0532 806EL-510-406 4L810336
607
6300969221 AIR LINE EQPT 2 806EL-510-407 225B0374
608
6301282527 PIPE FITTINGS 1 806EL-510-408 225F0603
609
6300955026 AIR LINE EQPT 2 806EL-510-409 225B0367
610
6300363012 LINK 2 806EL-510-410 214B0010
611
6301165882 SENSOR,PELEC 2 -B0421,-B0512
806EL-510-411 23G00227
612
6300325287 SENSOR,PHOTO 2 -B0426,-B0513
806EL-510-412 23G10029
613
6300018332 SPRING,TENSION 1 2109 806EL-510-413 222N0109
614
6300725803 MACHINE SCREW 24 806EL-510-414 221D0107
615
6300725797 HANDLE 1 806EL-510-415 226C0111
621 6301292274 PLATE 1 806EL-510-301 211D9801
622
6301292311 PLATE 1 806EL-510-302 211D9805
623
6301292328 PLATE 1 806EL-510-303 211D9806
624
6301283302 HINGE 1 806EL-510-304 226F0151
625
6301283296 PIN,HINGE 4 806EL-510-305 216D0465
626
6301283326 LEVER 1 806EL-510-306 216S2678
627
6301283333 LEVER 1 806EL-510-307 216S2679
628
6301283357 LEVER 2 806EL-510-308 216S2680
629
6301283319 HOLDER 2 806EL-510-309 216B1432
630
6301283340 COLLAR 2 806EL-510-310 216A1159
631
6301283500 BLOCK 2 806EL-510-311 211G3588
632 6301283777 BRACKET 1 806EL-510-312 211F8534
633
6301299662 DISK 1 806EL-510-313 213D1172
634
6301302263 SHAFT 1 806EL-510-314 213A1116
635 6301292434 BLOCK 1 806EL-510-315 211G3659
636
6301292687 SHAFT 1 806EL-510-316 213A1094
637
6301292281 PLATE 1 806EL-510-317 211D9802
638
6301283876 GRIP 1 806EL-510-318 226D0110
639
6301283883 COLLAR 1 806EL-510-319 216A1161
640
6301294810 SPRING,COMP 1 806EL-510-320 222M1342
641
6301294759 BRACKET 1 806EL-510-321 211F8702
643
6301294742 BRACKET 1 806EL-510-323 211F8701
651
6300007541 BOLT,HEX-SCT 4 M3X14 221A0009
652
6300007572 BOLT,HEX-SCT 3 M3X25 221A0012
653
6300007602 BOLT,HEX-SCT 2 M4X6 221A0015
654
6300007633 BOLT,HEX-SCT 1 M4X12 221A0018
655
6300007657 BOLT,HEX-SCT 4 M4X16 221A0020
656
6300007671 BOLT,HEX-SCT 1 M4X25 221A0022
657
6300007688 BOLT,HEX-SCT 3 M4X30 221A0023
658
6300007756 BOLT,HEX-SCT 5 M5X12 221A0030
659
6300007763 BOLT,HEX-SCT 4 M5X16 221A0031
660
6300007770 BOLT,HEX-SCT 1 M5X20 221A0032
EL-7
