~ built in up SN A-219
Page 23 / 25 23.11.2021
Pos. Item no. Description Part marking
BOTTOM COMPL.
88 03012194-02 PRESSURE PLATE Y-POWER TRACK
CHAIN COMPL.
89 03012071-02 HOLDER Y-POWER TRACK CHAIN
COMPL.
90 03013069-02 PRESSURE PLATE Y-POWER TRACK
CHAIN TOP
91 03010598-01 INTERMEDIATE PIECE
92 03013620-01 TRAILING CABLE ANALOG 2P G
ELECTR.
03013621-01 TRAILING CABLE 1 2PG: Y-MOTOR
93 00305458-01 BK-MOD421/2 CONNECTOR PLUG
34POLE
*
03013622-01 TRAILING CABLE 2 2PG: Y-MOTOR
03013623-01 TRAILING CABLE 3 2PG: Y-MOTOR
03013624-01 TRAILING CABLE 4 2PG: X-MOTOR
03013625-01 TRAILING CABLE 5 2PG: X-MOTOR
03013626-01 TRAILING CABLE 6 2PG:
S/Z2-MOTOR
03013627-02 TRAILING CABLE 7 2PG:
Z1/DP1-MOTOR
03013628-02 TRAILING CABLE 8 2PG:
DP1/DP2-MOTOR
03013629-01 TRAILING CABLE 9 ANALOG 2PG:
CAMERAS
94 03002305-02 PROFILE QM H 23, ANALOG 2P G
95 03004793-01 7-FOLD TUBE GANTRY 2/4 SIPLACE
X-HS
96 03012067-01 PRESSURE PLATE 7-FOLD TUBE 6/4
97 03013076-01 PROTECTION STRIP EXTERIOR,
ANALOG 2P G
98 03013958-01 PROTECTION STRIP INTERIOR,
ANALOG 2P G
99 03013959-01 PROTECTION STRIP COOLING TUBE,
ANALOG 2P G
100 03005846-01 CLAMPING PLATE 6.0
101 03002241-02 MOUNT X-TRAILING UNIT
102 03002242-02 PRESSURE PLATE X-TRAILING UNIT
103 03006507-01 MOUNT X-TRAILING UNIT TOP
104 03002082-01 PRESSURE PLATE 7-FOLD TUBE 6/4
~ built in up SN A-219
Page 24 / 25 23.11.2021
Pos. Item no. Description Part marking
105 03006509-01 PRESSURE PLATE X-TRAILING UNIT
TOP
106 03020955S01 COOLING HOSE W. MOUNTING CONSUMABLE
107 03016214-01 SUPPORT ROLLER
03005863-01 ADHESIVE TAPE CABLE TRAILING
109 03018027-01 CLAMPING PLATE 2.0
110 03018840-01 COOLING TUBE, DISTRIBUTOR
CLAMPING
111 03018853-01 COOLING TUBE Y-MOTOR ANALOG
2P G
112 03005450-03 Y-TRAILING CABLE MOUNT, LEFT
SIDE
113 03020353-04 MODULE: HEAD INTERFACE HF CPL. SPARE PART
114 03018099-03 BOARD / DC/DC CONVERTER HEAD
INTERFACE
SPARE PART
115 03000901-05 HEAD INTERFACE
116 03003536-04 TQM167 SIPLACE EMBEDDED
MODULE
SPARE PART
117 00363330-06 GANTRY INTERFACE SPARE PART
118 03006531-05 GANTRY INTERFACE GANTRY 2 AND
4
SPARE PART
119 03005501-01 COVER FOR INTERFACE HF COMPL. SPARE PART
120 03010612-03 CABLE INTERFACE GANTRY 1 OR 3
121 03010622-03 CABLE INTERFACE GANTRY 2 OR 4
122 03007121-01 RETAINING ANGLE PORTAL
DISTRIBUTOR
124 03006853-01 PORTAL DISTRIBUTOR SIPLACE X-
HS
SPARE
03006866S01 SPRING X-TRAILING COMPLETE Spare Part
126 03005409-01 DISTRIBUTOR COOLING AIR COMPL.
SIPLACE
03014289-01 SYSTEM/1-WIRE INFRASTRUCTURE
FOR 1 PORTAL
128 03010577-01 PCB / 1-WIRE HUB INTERFACE Spare Part
129 03013143S01 MODULE /SENSORIC HEAD PLATE
CPL.
SPARE PART
130 03014287-02 MODULE /SENSORIC HEAD PLATE
03014286S01 MODULE: GANTRY IDENTIFICATION
W. 1-WIRE
SPARE PART
