P-329-006_SIGMA-G5S - 第110页
– 104 – E1 181 1-006 6 Robot Cable 520 521 520 521 520 521
– 103 –
BEAM SECTION
1811-006
No.
Part No.
Part Name
Qty.
Detail
Yamaha Hitachi Rear Front
405 KYB-M220G-00 1010DC37 BALL_SCREW_L25 1 1
406 KYB-M221D-00 222F0026 BEARING_UNIT 1 1
407 KYB-M220E-00 1010DC2K BEARING 1 1
408 KYB-M220S-00 1010DC4M HOLDER 1 1
409 KYB-M221E-00 222G0015 BEARING_LOCKNUT 1 1
410 KYB-M220H-00 1010DC4K BLOCK 1 1
417 KYB-M220B-00 1010DC6J COVER_Y 2 2
451 91312-04010 221AA017 BOLT,HEX.SOCKET HEAD 4 4 M4L10
452 92902-04200 221HA104 WASHER,PLAIN 8 8 FW4
453 91312-04016 221AA020 BOLT,HEX.SOCKET HEAD 4 4 M4L16
454 91312-05016 221AA031 BOLT,HEX.SOCKET HEAD 10 10 M5L16
455 92902-05200 221HA105 WASHER,PLAIN 4 4 FW5
471 90990-01J144 221AA100 BOLT,HEX.S/H WW 8 8 M4L8+SW;FW
474 91312-05012 221AA030 BOLT,HEX.SOCKET HEAD 2 2 M5L12
– 105 –
BEAM SECTION
1811-006
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
520 KYB-M2605-00 1010DA0B HNS,XYROBOT1 A98 2
521 KYB-M2606-00 1010DA0C HNS,XYROBOT2 A98 2
