– 7 –
MODEL
1811-006
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
12 KYB-M131F-00 0920E111 SPRING_CATCHES 4
13 98702-03004 221DA105 SCREW,FLAT HEAD 8 FLT M3L4
15 90990-66J011 221DA217 SCREW,TRUSS HEAD 8 TRS M4L4
16 KYB-M1317-00 1010FG1Y COVER 2
17 KYB-M1318-00 1010FG1Z COVER 2
18 91312-05008 221AA028 BOLT,HEX.SOCKET HEAD 20 M5L8
20 KYB-M6513-00 09294023 ASSY-DOOR-SW 1
21 KYB-M6514-00 09294024 ASSY-DOOR-SW 1
22 KYB-M131A-00 1010FG2K INNER_BKT_L 2
23 KYB-M1319-00 1010FG2J INNER_BKT_R 2
24 KYB-M130D-00 1010FG0B COVER_BKT_L 2
25 KYB-M130E-00 1010FG0C COVER_BKT_R 2
27 91312-04012 221AA018 BOLT,HEX.SOCKET HEAD 4 M4L12
28 KYB-M131W-00 1010FG2H BRACKET 4
45 91312-06025 221AA045 BOLT,HEX.SOCKET HEAD 2 M6L25
46 92902-06200 221HA106 WASHER,PLAIN 2 FW6
48 91312-08025 221AA057 BOLT,HEX.SOCKET HEAD 8 M8L25
57 91312-05020 221AA032 BOLT,HEX.SOCKET HEAD 4 M4L12
58 KYB-M657X-00 1012C09A MARK_BLOCK2 2
59 KYB-M657W-00 1012C03V MARK_BLOCK 2
60 KYB-M655U-00 1012C03X MARK_PIN 4
76 KYB-M130F-00 1010FG0P GUL_STOPPER_BRA 2
77 KYB-M1104-00 1010FB0F PLATE 2
78 91312-08025 221AA057 BOLT,HEX.SOCKET HEAD 8 M8L25
79 91312-08020 221AA056 BOLT,HEX.SOCKET HEAD 2 M8L20
80 91312-06020 221AA044 BOLT,HEX.SOCKET HEAD 10 M6L20
81 91312-06014 221AA240 BOLT,HEX.SOCKET HEAD 4 M6L14
82 91312-05016 221AA031 BOLT,HEX.SOCKET HEAD 16 M5L16
83 91312-05014 221AA120 BOLT,HEX.SOCKET HEAD 8 M5L14
84 91312-05008 221AA028 BOLT,HEX.SOCKET HEAD 4 M5L8
85 92902-05100 221HA005 WASHER,SPRING 16 SW5
86 92902-08200 221HA107 WASHER,PLAIN 8 FW8
87 92902-05200 221HA105 WASHER,PLAIN 16 FW5
89 KYB-M65AW-00 23N30632 WIRING 3
90 90990-66J015 221DA212 SCREW,TRUSS HEAD 3 TRS M5L6
