– 123 –
POSITIONING UNIT
1811-006
No.
Part No.
Part Name
Qty.
Detail
Yamaha Hitachi Front Rear
6 KYB-M3J1T-00 223E0496 GEAR 1 1
7 KYB-M3J1U-00 223E0497 GEAR 1 1
8 KYB-M3J18-00 211DE692 PLATE 2 2
9 KYB-M3J19-00 211DE693 PLATE 2 2
10 KYB-M3J2G-00 222D0087 BEARING_RADIAL 2 2
11 KYB-M3J14-00 1010BJ12 SHAFT_BASE 2 2
12 91312-05012 221AA030 BOLT,HEX.SOCKET HEAD 2 2 M5L12
13 91312-04006 221AA015 BOLT,HEX.SOCKET HEAD 4 4 M4L6
14 91312-08016 221AA055 BOLT,HEX.SOCKET HEAD 4 4 M8L16
15 91312-04012 221AA018 BOLT,HEX.SOCKET HEAD 8 8 M4L12
16 90990-66J012 221DA207 SCREW,TRUSS HEAD 6 6 TRS M4L6
21 KYB-M3J1A-00 213A1569 SHAFT 1 1
22 KYB-M3J1V-00 223E0498 GEAR 2 2
23 90990-02J025 221CA044 SCREW,SET 2 2 SET M4L10
24 91609-40036 221J0029 PIN,SPRING 2 2
– 124 –
E4
1811-006
2 Sensor
See Fig E4-3
Key No.201
See Fig E4-4
Key No.302
10
11
12
110
11
112
1
1
1
106
107
107
10
11
12
10
11
12
103
104
103
105
104
101
106
110
111
112
110
11
112
107
107
108
108
110
111
112
10
11
12
107
103
102
106
10
11
12
108
108
105
10
1
12
107
104
10
11
12
108
108
105
1
1
1
1
10
11
12
1
1
1
1
1
1
1
1
1
1
1
1
1
1
11
1
1
1
1
– 125 –
POSITIONING UNIT
1811-006
No.
Part No.
Part Name
Qty.
Detail
Yamaha Hitachi Front Rear
101 KYB-M3J0M-00 0929E02A FIBER_BKT_L 2 2
102 KYB-M3J0N-00 0929E02B FIBER_BKT_R 1 1
103 KYB-M3J1D-00 0929E026 HOLDER_BKT_R 3 3
104 KYB-M3J1E-00 0929E027 HOLDER_BKT_L 3 3
105 KYB-M3J1F-00 0929E028 HOLDER_R 3 3
106 KYB-M3J1G-00 0929E029 HOLDER_L 3 3
107 90990-02J022 221CA002 SCREW,SET 6 6
108 KYB-M3J1N-00 1015A112 AMP-FIBER 3 3
110 91312-03008 221AA006 BOLT,HEX.SOCKET HEAD 24 24
111 92902-03100 221HA003 WASHER,SPRING 24 24
112 92902-03200 221HA103 WASHER,PLAIN 24 24
