– 132 –

1811-006

E5 ELECTRICAL SECTION 3

1 I/F Connector, PCB

1-01

1-02

1-03

1-05

1-06

1-07

1-08

1-09

1-04

1-10

1-01

1-02

1-03

1-06

1-07

1-08

1-05

1-10

1-09

1-04

– 133 –

ELECTRICAL SECTION 3

1811-006

No.

Part No.

Part Name Qty. Detail

Yamaha Hitachi

KYB-M6526-00

10101A23 ASSY-X30CONN 2

1-01 KYB-M6530-00 1010BA1E BRACKET LUMP-CON 1

1-02 KYB-M657D-00 1010BA1F BRACKET 1

1-03 KYB-M658Y-00 9W210506 HNS,BANANA-JACK 1

1-04 KYB-M650M-00 1010BC4Y HNS,FEED-BUNDLE 1

1-05 90990-11J016 221DA053 SCREW,PAN HEAD WW 1 PAN M4L16 SW+FW

1-06 91312-05012 221AA030 BOLT,HEX.SOCKET HEAD 2 M5L12

1-07 92902-05100 221HA005 WASHER,SPRING 2 SW5

1-08 KYB-M65AA-00 221HA303 ROHS_WASHER 2 BW5

1-09 90990-11J012 221DA057 SCREW,PAN HEAD WW 4 PAN M3L14 SW+FW

1-10 KYB-M6524-00 10101A1Q ASSY-S111 1

3 91312-05012 221AA030 BOLT,HEX.SOCKET HEAD 10 M5L12

4 92902-05100 221HA005 WASHER,SPRING 10 SW5

5 KYB-M65AA-00 221HA303 ROHS_WASHER 10 BW5

6 KYB-M6532-00 1010BA2K MOTOR-DRIVER 2

7 KYB-M657E-00 1010BA2M DRIVER_BRACKET 2

8 90990-11J017 221DA062 SCREW,PAN HEAD WW 4 PAN M3L8 SW+FW
