– 143 –
PANEL, CENTER FRAME SECTION
1811-006
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
201 KYB-M6508-00 1010FG1N FRAME 1
202 KYB-M652J-00 10105A00 ASSY-SWITCH-PANEL 1
203 KYB-M655H-00 1010FG0D COVER 1
204 KYB-M6520-00 1005FG1Y MONITOR_STOPPER 1
205 KYB-M6575-00 1005FG0T GROMMET 1
206 KYB-M651Y-00 1005FG0D HINGE_MONITOR 1
207 91312-08030 221AA058 BOLT,HEX.SOCKET HEAD 1 M8L30
208 95302-04600 221FA007 NUT,HEXAGON 2 M4
209 91312-04010 221AA017 BOLT,HEX.SOCKET HEAD 4 PAN M4L8
210 90990-66J007 221DA202 SCREW,TRUSS HEAD 3 TRS M3L30
211 92902-08200 221HA107 WASHER,PLAIN 1 FW8
212 KYB-M651V-00 1005BA3R DISPLAY 1
213 91312-06012 221AA042 BOLT,HEX.SOCKET HEAD 2 M6L12
214 92902-04200 221HA104 WASHER,PLAIN 2 FW6
