– 145 – U NI T - 6 : HIGH S P EE D HEAD , NO Z ZL E S T O C KE R S E C TIO N CONTENTS G1 HIGH SPEED HEAD SECTION 146 1 Electrical Section 146 2 Base Section 148 3 Nozzle Leveller ,and selecter 150 4 Nozzle Shaft, V accum…
– 144 –
– 145 –
UNIT-6: HIGH SPEED HEAD, NOZZLE STOCKER SECTION
CONTENTS
G1 HIGH SPEED HEAD SECTION 146
1 Electrical Section 146
2 Base Section 148
3
Nozzle Leveller,and selecter 150
4 Nozzle Shaft, Vaccum Filter 152
5 DD Motor 154
G2 HIGH SPPED NOZZLE STOCKER
SECTION 158
1 Base Section 158
2 Nozzle Stocker Driving Section 160
3 Nozzle Stocker Changing Section 162
4 Air Piping 164
