– 171 –
SINGLE CONVEYOR SECTION
1811-006
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
102 KYB-M916F-00 10122308 ASSY-CHUTE-ORG 1
103 KYB-M91DB-00 23G00312 BRACKET 2
104 97602-03312 221DA047 SCREW,PAN HEAD WW 2 PAN M3L12 SW+FW
105 91312-03006 221AA005 BOLT,HEX.SOCKET HEAD 4 M3L6
111 KYB-M911J-00 1012C09H BASE 1
112 KYB-M9169-00 10122302 ASSY-CV-VALVE 1
113 KYB-M913A-00 0921A059 AIR_LINE_EQPT 8
114 KYB-M9132-00 1012C09G BASE_BRACKET 1
115 KYB-M917W-00 1012C073 BASE_L_BRACKET 2
116 KYB-M91BW-00 1012C09F AIR_BRACKET 2
117 KYB-M912R-00 1012C05D BASE_BRACKET_L 1
118 KYB-M9185-00 1012C088 CABLE_VEYOR 2
119 KYB-M91D4-00 226J2510 CABLE_VEYOR 4
121 90990-66J012 221DA207 SCREW,TRUSS HEAD 18 TRS M4L6
122 91312-04035 221AA024 BOLT,HEX.SOCKET HEAD 4 M4L35
123 91312-04006 221AA015 BOLT,HEX.SOCKET HEAD 4 M4L6
124 90990-66J008 221DA203 SCREW,TRUSS HEAD 4 TRS M3L6
129 90990-11J016 221DA053 SCREW,PAN HEAD WW 13 PAN M4L6 SW+FW
130 KYB-M65AW-00 23N30632 WIRING 13
131 KYB-M9187-00 1012C091 GUIDE_LINEAR 2
132 91312-04016 221AA020 BOLT,HEX.SOCKET HEAD 18 M4L16
