– 190 – H1 181 1-006 12 Cable B41 B42 B13 B12 B11 B10 B01 B16 B15 B14 B09 B17 B18 B02 B01 B04 B05 B06 B03 B08 B07 B32 B31 B33 B34
– 189 –
SINGLE CONVEYOR SECTION
1811-006
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
A01 KYB-M919L-00 0917C304 TUBE_D32 1
A02 KYB-M919J-00 0917C302 TUBE_D6 1
A03 KYB-M91AH-00 1005AB03 PIPE_FITTINGS 1
A04 KYB-M919M-00 0917C305 TUBE_D4.1 1
A05 KYB-M919V-00 0919I00K TUBE D4 4 Fiber protection
– 191 –
SINGLE CONVEYOR SECTION
1811-006
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
B01 KYB-M9140-00 1010CA20 HNS,CONV-POW 1
B02 KYB-M9147-00 1010CA28 HNS,CONV-VALVE 1
B03 KYB-M9145-00 1010CA26 HNS,FIBER-AMP 1
B04 KYB-M9148-00 1010CA29 HNS,STOPPER-L 1
B05 KYB-M9149-00 1010CA2A HNS,STOPPER-R 1
B06 KYB-M914L-00 1010CA2N HNS,STOPPER 1
B07 KYB-M914A-00 1010CA2B HNS,BU-PIN-R 1
B08 KYB-M914B-00 1010CA2C HNS,BU-PIN-T 1
B10 KYB-M9141-00 1010CA21 HNS,CONV-MOT-L 1
B11 KYB-M9142-00 1010CA22 HNS,CONV-MOT-M 1
B12 KYB-M9143-00 1010CA23 HNS,CONV-MOT-R 1
B13 KYB-M9144-00 1010CA24 HNS,WIDTH-MOT 1
B14 KYB-M914J-00 1010CA2L HNS,BOARD-DET 1
B15 KYB-M914K-00 1010CA2M HNS,BOARD-DET 1
B16 KYB-M9146-00 1010CA27 HNS,CHUTE-ORG 1
B17 KYB-M914G-00 1010CA2J HNS,AELINK-N1 1
B18 KYB-M914H-00 1010CA2K HNS,AELINK-N2 1
B31 KYB-M914C-00 1010CA2E HNS,BU-MOT-L 1
B32 KYB-M914D-00 1010CA2F HNS,BU-MOT-R 1
B33 KYB-M914E-00 1010CA2G HNS,SEN-BU-MOT 1
B34 KYB-M914F-00 1010CA2H HNS,SEN-BU-MOT 1
B41 KYB-M91AK-00 1005CA00 PCB-MOUNT 1
B42 KYB-M913W-00 1005BA3K UNIT-DRIVER 1
