– 199 –
DUAL CONVEYOR SECTION
1811-006
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
1 KYB-M912F-00 0992C40Q BLOCK(KL) 1
2 KYB-M912E-00 0992C40E BLOCK(KR) 1
3 KYB-M913N-00 0948C41L BLOCK(KLT) 1
4 KYB-M913P-00 0948C41M BLOCK(KRT) 1
5 KYB-M91BH-00 1012C07X BRACKET_LRI 1
6 KYB-M916X-00 1012x3B8 ASSY-PCB-SEN-MB 1 L-R
7 KYB-M916X-10 ASSY-PCB-SEN-MB-FL 1 R-L
8 KYB-M917E-00 1012x3BQ ASSY-STOPPER-RB 1 L-R
9 KYB-M917E-10 ASSY-STOPPER-RB-FL 1 R-L
10 KYB-M91CD-00 211G5843 BLOCK 1
11 KYB-M91CB-00 211FE532 BRACKET 1
12 $M-3ALU-3 225F0240 PIPE_FITTINGS 2
13 KYB-M91CC-00 211FE801 BRACKET 1
14 KYB-M918K-00 1012CA0M MOTOR_STEPPING 1
15 KYB-M91CW-00 223Q0749 PULLEY_TIMING 1
16 KYB-M91CX-00 223Q0755 PULLEY_TIMING 1
17 KYB-M919E-00 223L0383 BELT_TIMING 1
18 KYB-M91C2-00 1012CA10 PULLEY_FLAT 1
19 90933-03J693 222D0016 BEARING_RADIAL 2
20 KYB-M91C7-00 211FD663 BRACKET 1
21 KYB-M91AD-00 0992C40G BLOCK 2
22 KYB-M919S-00 0917C41F BRACKET 1
23 91312-05020 221AA032 BOLT,HEX.SOCKET HEAD 4
24 91312-05016 221AA031 BOLT,HEX.SOCKET HEAD 4
25 91312-05012 221AA030 BOLT,HEX.SOCKET HEAD 2
26 91312-05010 221AA029 BOLT,HEX.SOCKET HEAD 2
27 91312-04008 221AA016 BOLT,HEX.SOCKET HEAD 2
28 91312-03008 221AA006 BOLT HEX,SOCKET HEAD 4
29 91312-04012 221AA018 BOLT,HEX.SOCKET HEAD 2
30 91312-03006 221AA005 BOLT,HEX.SOCKET HEAD 2
31 91312-06030 221AA046 BOLT,HEX.SOCKET HEAD 4
32 90990-01J138 221AA099 BOLT,HEX.S/H WW 1
33 90990-07J007 221B1015 BOLT,HEXAGON 1
34 90990-06J008 221A0229 BOLT,BUTTON HEAD 2
35 90990-02J024 221CA005 SCREW,SET 2
36 95302-03600 221FA005 NUT, HEXAGON 1
37 95302-04600 221FA007 NUT, HEXAGON 1
38 95302-05600 221FA009 NUT, HEXAGON 1
39 92902-03100 221HA003 WASHER,SPRING 1
40 92902-05100 221HA005 WASHER,SPRING 3
41 92902-03600 221HA203 WASHER, PLAIN 1
42 92902-05200 221HA105 WASHER, PLAIN 5
– 200 –
H2
1811-006
5 LR F Fixed Chutes
7
21
4
4
3
3
11
16
15
15
14
17
19
16
10
18
5
25
22
23
8
6
6
16
16
12
14
17
9
2
23
13
18
19
25
24
5
20
7
21
4
4
1
20
24
22
– 201 –
DUAL CONVEYOR SECTION
1811-006
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
1 KYB-M9122-00 0948C108 CHUTE2KL 1
2 KYB-M9123-00 0948C109 CHUTE2KR 1
3 KYB-M918K-00 1012CA0M MOTOR_STEPPING 2
4 KYB-M91CV-00 223Q0663 PULLEY_TIMING 4
5 KYB-M91CW-00 223Q0749 PULLEY_TIMING 2
6 KYB-M91C2-00 1012CA10 PULLEY_FLAT 4
7 KYB-M919F-00 223L0384 BELT_TIMING 2
8 KYB-M913G-00 0948C417 MBRACKET(2L) 1
9 KYB-M919U-00 0917C41H BRACKET_R1 1
10 KYB-M919T-00 0917C41G BRACKET_L1 1
11 KYB-M916V-00 1012x3B6 ASSY-PCB-SEN-LB 1
12 KYB-M9170-00 1012x3BA ASSY-PCB-SEN-RB 1
13 KYB-M913H-00 0948C418 MBRACKET(2R) 1
14 KYB-M919P-00 0917C41A BRACKET_LR 2
15 KYB-M919R-00 0917C41B BRACKET 2
16 90990-01J138 221AA099 BOLT,HEX.S/H WW 6
17 90990-01J139 221AA092 BOLT,HEX.S/H WW 4
18 91312-03008 221AA006 BOLT HEX,SOCKET HEAD 4
19 91312-04010 221AA017 BOLT HEX,SOCKET HEAD 4
20 91312-05025 221AA033 BOLT HEX,SOCKET HEAD 2
21 91312-05030 221AA034 BOLT HEX,SOCKET HEAD 2
22 90990-66J012 221DA207 SCREW,TRUSS HEAD 2
23 90990-02J024 221CA005 SCREW,SET 4
24 95302-05600 221FA009 NUT, HEXAGON 4
25 92902-05200 221HA105 WASHER, PLAIN 2
