– 16 – B1 181 1-006 2 Feeder Cover 101 112 121 123 135 134 104 102 104 103 109 105 110 110 108 112 111 112 115 114 115 112 113 111 106 107 106 122 131 133 132 134 135

100%1 / 284
– 15 –
COVER SECTION
1811-006
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
1 KYB-M130K-00 1010FG23 COVER_CORNER_LF 1
2 KYB-M130G-00 1010FG20 COVER_CORNER_RF 1
3 KYB-M130H-00 1010FG21 COVER_CORNER_LB 1
4 KYB-M130J-00 1010FG22 COVER_CORNER_RB 1
5 KYB-M1306-00 1010FG31 COVER_SIDE_1:SECC 2
6 KYB-M1307-00 1010FG32 COVER_SIDE_2:SECC 2
7 KYB-M1316-00 1010FG1S BRACKET 8
8 KYB-M131B-00 1010FG3B COVER_INNER-1 1
9 KYB-M131C-00 1010FG3C COVER_INNER-2 2
10 KYB-M1309-00 1010FG3L COVER_LOWER 1
11 KYB-M1308-00 1010FG3K COVER_LOWER 1
12 KYB-M1315-00 1010FG1G COVER 2
13 91312-05012 221AA030 BOLT,HEX.SOCKET HEAD 16 M5L12
14 90990-66J017 221DA221 SCREW,TRUSS HEAD 96 TRS M5L8
15 KYB-M131D-00 1010FG3D COVER_INNER-FR 1
16 KYB-M1314-00 1010FG0N BRACKET_COVER 2
17
KYB-M131V-00
1010FG0Q
BRACKET_COVER
2
21
91312-04008
221AA016
BOLT,HEX.SOCKET HEAD
8 M4L8
– 16 –
B1
1811-006
2 Feeder Cover
101
112
121
123
135
134
104
102
104
103
109
105
110
110
108
112
111
112
115
114
115
112
113
111
106
107
106
122
131
133
132
134
135
– 17 –
COVER SECTION
1811-006
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
101 KYB-M1305-00 1010FG00 COVER_FEEDER 1
102 KYB-M131M-00 1005FG1M BRACKET 1
103 KYB-M131N-00 1005FG1N BRACKET 1
104 KYB-M131P-00 1005FG1R PLATE 2
105 KYB-M131E-00 211AD673 COVER 1
106 KYB-M131F-00 0920E111 SPRING_CATCHES 2
107 KYB-M130N-00 0929E00K DOORSW_ACTUATOR 1
108 KYB-M3700-00 09200008 ASSY_NAMEPLATE 1
109 KYB-M131T-00 1010FG03 EDGING 1
110 KYB-M131U-00 1010FG04 EDGING 2
111 98702-03004 221DA105 SCREW,FLAT HEAD 4 FLT M3L4
112 91312-04006 221AA015 BOLT,HEX.SOCKET HEAD 8 M4L6
113 91312-04008 221AA016 BOLT,HEX.SOCKET HEAD 2 M4L8
114 90990-66J012 221DA207 SCREW,TRUSS HEAD 4 TRS M4L6
115 92902-04200 221HA104 WASHER,PLAIN 4 FW4
121 KYB-M1311-00 1010FB0G BRACKET 1
122 KYB-M130V-00 10105A09 ASSY-S132-SAFETY-SW 1
123 91312-04035 221AA024 BOLT,HEX.SOCKET HEAD 3 M4L35
131 KYB-M1311-00 1010FB0G BRACKET 1
132 KYB-M652K-00 10105A08 ASSY-S131-SAFETY-SW 1
133 91312-04035 221AA024 BOLT,HEX.SOCKET HEAD 3 M4L35
134 92902-04600 221HA204 WASHER,PLAIN 6
135 92902-04100 221HA004 WASHER,SPRING 6
