– 217 –
DUAL CONVEYOR SECTION
1811-006
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
1 KYB-M9106-00 0992C408 BLOCK(1L) 1
2 KYB-M911L-00 1012CA0G BLOCK_1R 1
3 KYB-M913U-00 0992C40F BALL_SCREW 2
4 KYB-M91CM-00 216B1798 HOLDER 2
5 KYB-M91ER-00 222D0423 BEARING_ANGULAR 4
6 KYB-M91CT-00 223L0327 BELT_TIMING 1
7 KYB-M91AE-00 0992C40P BRACKET 1
8 KYB-M91D1-00 223Q0767 PULLEY_TIMING 2
9 KYB-M91CY-00 223G0758 PULLEY_TIMING 1
10 KYB-M91CG-00 213A1581 SHAFT 4
11 KYB-M91A2-00 0948C40X TENSIONSHAFT 1
12 KYB-M917X-00 1012C074 MOTOR_STEPPING 1
13 KYB-M91AB-00 0992C40B SUPPORT_BS_LOWER 2
14 KYB-M91AC-00 0992C40C SUPPORT_BS_UPPER 2
15 KYB-M91A3-00 0948C40Y TENSIONBRACKET 1
16 KYB-M913K-00 0948C41F HOLDER(2R) 1
17 KYB-M9126-00 0948C40M HOLDER(3R) 1
18 90933-03J624 222D0017 BEARING_RADIAL 10
19 90990-07J006 221BA004 BOLT,HEXAGON 1
20 90990-07J009 221BA009 BOLT,HEXAGON 1
21 91312-03006 221AA005 BOLT,HEX.SOCKET HEAD 2
22 91312-03010 221AA007 BOLT HEX,SOCKET HEAD 8
23 91312-04012 221AA018 BOLT,HEX.SOCKET HEAD 2
24 91312-04010 221AA017 BOLT HEX,SOCKET HEAD 8
25 91312-05016 221AA031 BOLT,HEX.SOCKET HEAD 2
26 91312-05025 221AA033 BOLT,HEX.SOCKET HEAD 4
27 91312-06020 221AA044 BOLT,HEX.SOCKET HEAD 4
28 91312-06030 221AA046 BOLT,HEX.SOCKET HEAD 4
29 90990-02J024 221CA005 SCREW,SET 6
30 95302-03600 221FA005 NUT, HEXAGON 1
31 95302-04600 221FA007 NUT, HEXAGON 2
32 95302-05600 221FA009 NUT, HEXAGON 1
33 92902-04100 221HA004 WASHER,SPRING 1
34 92902-05100 221HA005 WASHER,SPRING 6
35 92902-06100 221HA006 WASHER,SPRING 4
36 92902-04200 221HA104 WASHER, PLAIN 1
37 92902-04600 221HA204 WASHER,PLAIN 5
38 92902-05200 221HA105 WASHER, PLAIN 6
39 92902-06200 221HA106 WASHER, PLAIN 4
