P-329-006_SIGMA-G5S - 第236页
– 230 – H2 181 1-006 20 Cable Right Unit 102 101 103 6 7 8 9 8 104 105 106 101 121 120 3 4 113 112 111 110 117 116 4 4 4 118 119 101 107 108 109 2 101 114,122 115,123
– 229 –
DUAL CONVEYOR SECTION
1811-006
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
1 KYB-M912G-00 1010CAB2 HNS,CBL-DUAL-POW-L 1
3 KYB-M914H-00 1010CA2K HNS,AELINK-N2 2
4 KYB-M9137-00 0917C00L HNS,AE-LINK 3
5 KYB-M915P-00 1010CABZ HNS,AELINK 1
6 KYB-M657Y-00 1015A10B LAN-CABLE 1
7 KYB-M9165-00 1010CACN HNS,CV-VALVE-L 1
8 KYB-M915V-00 1010CACA HNS,STOPPER-A3 1
9 KYB-M915W-00 1010CACB HNS,STOPPER-B3 1
10 KYB-M9162-00 1010CACG HNS,BU-PIN1 1
11 KYB-M9163-00 1010CACJ HNS,BU-PIN2 1
12 KYB-M9164-00 1010CACL HNS,BU-PIN3 1
13 KYB-M914U-00 1010CAB5 HNS,MOT-L-LA1 1
14 KYB-M914V-00 1010CAB6 HNS,MOT-L-LA2 1
15 KYB-M914W-00 1010CAB7 HNS,MOT-L-LB1 1
16 KYB-M914X-00 1010CAB8 HNS,MOT-L-LB2 1
17 KYB-M914Y-00 1010CAB9 HNS,MOT-A-LA1 1
18 KYB-M9150-00 1010CABA HNS,MOT-A-LA2 1
19 KYB-M9151-00 1010CABB HNS,MOT-A-W1 1
20 KYB-M9152-00 1010CABC HNS,MOT-A-W3 1
21 KYB-M915A-00 1010CABL HNS,MOT-BAL 1
22 KYB-M915B-00 1010CABM HNS,MOT-BAR 1
23 KYB-M915E-00 1010CABQ HNS,BRD-DET-AL 1
24 KYB-M915F-00 1010CABR HNS,BRD-DET-BL 1
25 KYB-M915J-00 1010CABU HNS,FBR-AMP-A 1
26 KYB-M915L-00 1010CABW HNS,CHUTE-ORG1 1
27 KYB-M915M-00 1010CABX HNS,CHUTE-ORG3 1
28 KYB-M915R-00 1010CAC0 HNS,SEN-BU-AL 1
29 KYB-M915S-00 1010CAC1 HNS,SEN-BU-AR 1
30 KYB-M914N-00 1010CAAC HNS,ENCORDER-BAL 1
31 KYB-M914P-00 1010CAAD HNS,ENCORDER-BAR 1
32 KYB-M914T-00 1010CAAG HNS,AELINK-N1 1
33 KYB-M91AK-00 1005CA00 PCB-MOUNT 1
34 KYB-M913W-00 1005BA3K UNIT-DRIVER 2
35 KYB-M91DE-00 4U240489 UNIT-DRIVER 1
– 231 –
DUAL CONVEYOR SECTION
1811-006
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
2 KYB-M914G-00 1010CA2J HNS,AELINK-N1 2
3 KYB-M914H-00 1010CA2K HNS,AELINK-N2 2
4 KYB-M9137-00 0917C00L HNS,AE-LINK 3
6 KYB-M657Y-01 1015A10B LAN-CABLE 1
7 KYB-M91AK-00 1005CA00 PCB-MOUNT 1
8 KYB-M913W-00 1005BA3K UNIT-DRIVER 2
9 KYB-M91DE-00 4U240489 UNIT-DRIVER 1
101 KYB-M912H-00 1010CAB3 HNS,CBL-DUAL-POW-R 1
102 KYB-M9166-00 1010CACP HNS,CV-VALVE-R 1
103 KYB-M915X-00 1010CACC HNS,STOPPER-A1 1
104 KYB-M915Y-00 1010CACD HNS,STOPPER-A2 1
105 KYB-M9160-00 1010CACE HNS,STOPPER-B1 1
106 KYB-M9161-00 1010CACF HNS,STOPPER-B2 1
107 KYB-M9153-00 1010CABD HNS,MOT-A-LB1 1
108 KYB-M9154-00 1010CABE HNS,MOT-A-LB2 1
109 KYB-M9155-00 1010CABF HNS,MOT-A-W2 1
110 KYB-M9156-00 1010CABG HNS,MOT-R-LA1 1
111 KYB-M9157-00 1010CABH HNS,MOT-R-LA2 1
112 KYB-M9158-00. 1010CABJ HNS,MOT-R-LB1 1
113 KYB-M9159-00 1010CABK HNS,MOT-R-LB2 1
114 KYB-M915C-00 1010CABN HNS,MOT-BBL 1
115 KYB-M915D-00 1010CABP HNS,MOT-BBR 1
116 KYB-M915G-00 1010CABS HNS,BRD-DET-AR 1
117 KYB-M915H-00 1010CABT HNS,BRD-DET-BR 1
118 KYB-M915K-00 1010CABV HNS,FBR-AMP-B 1
119 KYB-M915N-00 1010CABY HNS,CHUTE-ORG2 1
120 KYB-M915T-00 1010CAC2 HNS,SEN-BU-BL 1
121 KYB-M915U-00 1010CAC3 HNS,SEN-BU-BR 1
122 KYB-M914R-00 1010CAAE HNS,ENCORDER-BBL 1
123 KYB-M914S-00 1010CAAF HNS,ENCORDER-BBR 1
