– 19 –
COVER SECTION
1811-006
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
204 KYA-M131F-00 1005FB0F GUL_COV_AS_A 1
205 1005FB0G GUL COV HOKYO B 1
206 1010FB07 ROCK KEY BRA A 1
207 KYA-M132J-00 1005FB0J LOCK_KEY_BRA_B 1
208 KYA-M1335-00 23H20053 ACCESS_SW_(KEY) 1
210 90990-01J144 221AA100 BOLT,HEX.S/H WW 10 M4L8 SW+FW
211 90990-01J139 221AA092 BOLT,HEX.S/H WW 14 M3L8 SW+FW
212 90990-06J010 221EA100 BOLT,BUTTON HEAD 6 BUTTAN M4L10
213 92902-04100 221HA004 WASHER,SPRING 6 SW4
214 92902-04200 221HA104 WASHER,PLAIN 6 FW4
221 1010FB0X F GUL MIDDLE 1
222 KYA-M131K-00 1005FB1F COVER_F_GUL_MIDDLE 1
223 KYA-M131L-00 1005FB1G COVER 2
224 KYA-M131M-00 1005FB1H COVER 2
225 KYA-M132B-00 211J1659 STAY 1
226 KYA-M131B-00 1005FB06 GUM_CUSHION 2
227 KYA-M131D-00 1005FB08 GUM_CUSHION 1
229 KYA-M132H-00 1005FB0E SET_SCREW 2
230 90990-11J011 221DA059 SCREW,PAN HEAD WW 11 M3L10 SW+FW
231 90990-01J139 221AA092 BOLT,HEX.S/H WW 18 M3L8 SW+FW
232 91312-05012 221AA030 BOLT,HEX.SOCKET HEAD 3 M5L12
234 95302-06600 221FA011 NUT,HEXAGON 2 M6
236 92902-06200 221HA106 WASHER,PLAIN 2 FW6
237 92902-05200 221HA105 WASHER,PLAIN 3 FW5
239 KYA-M132K-00 1005FB1J PLATE 2
