– 27 –
FEEDER CART SECTION
1811-006
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
101 KYB-M370B-00 1014A204 CART_FRAME 1
102 KYB-M3704-00 1010E206 PLATE 1
103 KYB-M370F-00 1010E203 PLATE 1
104 KYB-M3701-00 1009EE1M REEL_HOLDER 10
105 KYB-M370S-00 1009EE08 COVER 1
106 KYB-M370T-00 1009EE09 COVER 1
107 KYB-M370U-00 1009EE0A COVER 1
110 KYB-M371A-00 1010E208 PLATE 1
111 KYB-M371S-00 212A2483 GUIDE 1
112 KYL-M86H4-00 226E0069 CASTER 4
113 KYB-M3734-00 226J2295 CASTER 2
114 KYB-M3729-00 1009EE0X GRIP 2
115 KYB-M3732-00 223R0111 CHAIN 1
116 90990-01J126 221E0302 BOLT,HEX.SOCKET HEAD 4
117 KYB-M3728-00 1009EE0N BALL_PLUNGER 1
118 KYB-M370X-00 1009EE2B BOX 1
119 KYB-M370V-00 1009EE13 PLATE 1
120 KYB-M370W-00 1009EE14 PLATE 1
122 KYB-M372B-00 1009EE16 PLATE 1
123 KYB-M372E-00 1010E204 BRACKET 2
124 KYB-M371J-00 1014A20G COVER 1
125 90990-66J012 221DA207 SCREW,TRUSS HEAD 16 TRS M4L6
126 91312-04006 221AA015 BOLT,HEX.SOCKET HEAD 6 M4L6
127 92902-04200 221HA104 WASHER,PLAIN 2 FW4
128 91312-04010 221AA017 BOLT,HEX.SOCKET HEAD 1 M4L10
129 KYB-M65A9-00 221HA302 ROHS_WASHER 1 BW4
130 91312-05008 221AA028 BOLT,HEX.SOCKET HEAD 4 M5L8
131 92902-05200 221HA105 WASHER,PLAIN 2 FW5
132 91312-06008 221AA140 BOLT,HEX.SOCKET HEAD 16 M6L8
133 91312-06010 221AA041 BOLT,HEX.SOCKET HEAD 4 M6L10
134 92902-06200 221HA106 WASHER,PLAIN 16 FW6
135 90189-02J107 221FA016 NUT,HEXAGON 2
136 90990-11J017 221DA062 SCREW,PAN HEAD WW 6 PAN M4L8 SW+FW
137 90990-01J144 221AA100 BOLT,HEX.S/H WW 5 M4L8 SW+FW
138 KYB-M65AW-00 23N30632 WIRING 4
139 KYB-M371M-00 1014A20R PLATE 21
140 KYB-M65AB-00 226J0373 MOUNTING_BASE 2
141 90990-11J016 221DA053 SCREW,PAN HEAD WW 1 PAN M4L6 SW+FW
142 95302-06700 221FA012 NUT,HEXAGON 1
