– 28 – C1 181 1-006 3 Electrical Box 235 234 232 Key No.401 See Fig C1-5 203 204 205 205 2 11 212 213 214 215 216 217 217 218 218 219 220 221 231 231 231 231 233 236 236

100%1 / 284
– 27 –
FEEDER CART SECTION
1811-006
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
101 KYB-M370B-00 1014A204 CART_FRAME 1
102 KYB-M3704-00 1010E206 PLATE 1
103 KYB-M370F-00 1010E203 PLATE 1
104 KYB-M3701-00 1009EE1M REEL_HOLDER 10
105 KYB-M370S-00 1009EE08 COVER 1
106 KYB-M370T-00 1009EE09 COVER 1
107 KYB-M370U-00 1009EE0A COVER 1
110 KYB-M371A-00 1010E208 PLATE 1
111 KYB-M371S-00 212A2483 GUIDE 1
112 KYL-M86H4-00 226E0069 CASTER 4
113 KYB-M3734-00 226J2295 CASTER 2
114 KYB-M3729-00 1009EE0X GRIP 2
115 KYB-M3732-00 223R0111 CHAIN 1
116 90990-01J126 221E0302 BOLT,HEX.SOCKET HEAD 4
117 KYB-M3728-00 1009EE0N BALL_PLUNGER 1
118 KYB-M370X-00 1009EE2B BOX 1
119 KYB-M370V-00 1009EE13 PLATE 1
120 KYB-M370W-00 1009EE14 PLATE 1
122 KYB-M372B-00 1009EE16 PLATE 1
123 KYB-M372E-00 1010E204 BRACKET 2
124 KYB-M371J-00 1014A20G COVER 1
125 90990-66J012 221DA207 SCREW,TRUSS HEAD 16 TRS M4L6
126 91312-04006 221AA015 BOLT,HEX.SOCKET HEAD 6 M4L6
127 92902-04200 221HA104 WASHER,PLAIN 2 FW4
128 91312-04010 221AA017 BOLT,HEX.SOCKET HEAD 1 M4L10
129 KYB-M65A9-00 221HA302 ROHS_WASHER 1 BW4
130 91312-05008 221AA028 BOLT,HEX.SOCKET HEAD 4 M5L8
131 92902-05200 221HA105 WASHER,PLAIN 2 FW5
132 91312-06008 221AA140 BOLT,HEX.SOCKET HEAD 16 M6L8
133 91312-06010 221AA041 BOLT,HEX.SOCKET HEAD 4 M6L10
134 92902-06200 221HA106 WASHER,PLAIN 16 FW6
135 90189-02J107 221FA016 NUT,HEXAGON 2
136 90990-11J017 221DA062 SCREW,PAN HEAD WW 6 PAN M4L8 SW+FW
137 90990-01J144 221AA100 BOLT,HEX.S/H WW 5 M4L8 SW+FW
138 KYB-M65AW-00 23N30632 WIRING 4
139 KYB-M371M-00 1014A20R PLATE 21
140 KYB-M65AB-00 226J0373 MOUNTING_BASE 2
141 90990-11J016 221DA053 SCREW,PAN HEAD WW 1 PAN M4L6 SW+FW
142 95302-06700 221FA012 NUT,HEXAGON 1
– 28 –
C1
1811-006
3 Electrical Box
235
234
232
Key No.401
See Fig C1-5
203
204
205
205
211
212
213
214
215
216
217
217
218
218
219
220
221
231
231
231
231
233
236
236
– 29 –
FEEDER CART SECTION
1811-006
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
203 91312-04010 221AA017 BOLT,HEX.SOCKET HEAD 3 M4L10
204 92902-04200 221HA104 WASHER,PLAIN 3 FW4
205 91312-05010 221AA029 BOLT,HEX.SOCKET HEAD 4 M5L10
211 KYB-M3702-00 1010E10J BOX_COVER 1
212 KYB-M370E-00 1010E10H EL_BOX 1
213 KYB-M372D-00 1010E10L HINGE 3
214 KYB-M372J-00 1015A110 STEEL-SPACER 1
215 KYB-M371G-00 1014A100 PCB-MOUNT 2
216 KYB-M371H-00 1014A101 PCB-MOUNT 1
217 KYB-M65AW-00 23N30632 WIRING 4
218 KYB-M3724-00 0920E30U ACCESSORY-P-C-B 16
219 KYB-M65AB-00 226J0373 MOUNTING_BASE 1
220 KYB-M3739-00 4W204901 HNS,DRAWER 30
221 KYB-M372X-00 221E0298 BOLT 60
231 90990-66J007 221DA202 SCREW,TRUSS HEAD 32 TRS M3L4
232 90990-66J008 221DA203 SCREW,TRUSS HEAD 12 TRS M3L6
233 90990-66J011 221DA217 SCREW,TRUSS HEAD 4 TRS M4L4
234 90990-11J009 221DA051 SCREW,PAN HEAD WW 1 PAN M3L6
235 90990-11J012 221DA057 SCREW,PAN HEAD WW 5 PAN M3L14
236 98502-04006 221DA021 SCREW,PAN HEAD 5 PAN M4L6
