– 33 – FE EDER C ART SE CT ION 181 1-006 No. Part No. Part Name Qty . Detail Y amaha Hitachi 401 KYB-M3703-00 1010E10K F_BASE 1 402 KYB-M372P-00 21 1G5359 BLOCK 6 403 KYB-M371 1-00 1010E10M PLA TE_GUIDE_L 2 404 KYB-M3712…
– 33 –
FEEDER CART SECTION
1811-006
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
401 KYB-M3703-00 1010E10K F_BASE 1
402 KYB-M372P-00 211G5359 BLOCK 6
403 KYB-M3711-00 1010E10M PLATE_GUIDE_L 2
404 KYB-M3712-00 1010E10N PLATE_GUIDE_S 1
405 91312-05016 221AA031 BOLT,HEX.SOCKET HEAD 12 M5L16
406 92902-05600 221HA205 WASHER,PLAIN 12 FWS5
407 90112-2AJ006 221AA145 BOLT,HEX.SOCKET HEAD 31 M2.5L6
408 91312-03008 221AA006 BOLT,HEX.SOCKET HEAD 14 M3L8
409 92902-03600 221HA203 WASHER,PLAIN 14 FWS3
