– 37 – ELEC TRICA L SECTION 1 181 1-006 No. Part No. Part Name Qty . Detail Y amaha Hitachi 3 KYB-M1 102-00 1010BZ0Q FRAME_CUT 1 4 KYB-M1 103-00 1005BK06 PLA TE_CONNECT 4 5 91312-08020 221AA056 BOL T ,HEX.SOCKET HEAD 12 …

100%1 / 284
– 36 –
D1
1811-006
D1 ELECTRICAL SECTION 1
1 Frame
5
6
7
4
11
12
See Fig. D5-1
8
9
10
3
– 37 –
ELECTRICAL SECTION 1
1811-006
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
3 KYB-M1102-00 1010BZ0Q FRAME_CUT 1
4 KYB-M1103-00 1005BK06 PLATE_CONNECT 4
5 91312-08020 221AA056 BOLT,HEX.SOCKET HEAD 12 M8L50
6 92902-08100 221HA007 WASHER,SPRING 12 SW8
7 92902-08200 221HA107 WASHER,PLAIN 12 FW8
8 90112-12J030 221AA077 BOLT,HEX.SOCKET HEAD 4 M12L30
9 92902-12100 221HA009 WASHER,SPRING 4 SW12
10 92902-12600 221HA209 WASHER,PLAIN 4 FWS12
11 KYB-M1105-00 216A0334 COLLAR 4
12 90990-02J028 221CA010 SCREW,SET 4
– 38 –
D1
1811-006
2 Fixed Screw
C
N
C
3PNC
D4N
C
C
4
N
CB4NC
3
N
C
5NC
A2P
N
C
B2PNC
C2PNC
D
2PNC
A2NC
B2NC
C2NC
D2
NC
3PNC
1
P
N
C
D4N
CC
4
NCB4NC
3
NC
See Fig. D5
See Fig. D3
See Fig. D4
See Fig. D5
See Fig. D4
See Fig. D2
See Fig. D2
See Fig. D1-3
See Fig. D4
104
102
110
114
115
114
115
116
117
112
113
123
119
120
125
112
113
112
113
112
113
112
113
126
113
126
113
103
112
113
103
103
112
113
