– 43 –
CPU BOX SECTION
1811-006
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
1 KYB-M410H-00 1010GD0H CPU-BOX 1
2 KYB-M4105-00 1005GD14 MOTHER BOARD 1
3 KYB-M4104-00 1005GD12 FRAME GRABBER BOARD 1
5 KYB-M410Y-00 23N30719 ACCESS-WIRING 3
7
KYB-M410B-00 10101A3C SSD-COPY 1 OS:win XP
KYB-M410B-01 SSD-COPY 1 OS:win 7
8 KYB-M4106-00 1005GD17 CABLE(SATA) 1
9 KYB-M4107-00 1005GD18 CABLE(SATA-P) 1
10 90990-11J009 221DA051 SCREW,PAN HEAD WW 16 PAN M3L6 SW+FW
12 KYB-M410L-00 0921A024 COIL-TUBE 1
14 KYB-M410T-00 1005GD27 USB-BRACKET 1
15 KYB-M410R-00 1005BC4M CORD-ATX-MAIN 1
16 KYB-M4103-00 1005BC4N CORD-ATX-HD 1
17 KYB-M410S-00 1005BC4P CORD-ATX12V 1
