1811-006
CONTENTS
SIGMA-G5S SINGLE TRANSFER 1
A1 MODEL .....................................................................................................2
UNIT-1: COVER SECTION 11
B1 COVER SECTION ..................................................................................12
UNIT-2: CART SECTION 23
C1 FEEDER CART SECTION ......................................................................24
UNIT-3: LOWER FRAME SECTION 35
D1 ELECTRICAL SECTION 1 ......................................................................36
D2 CPU BOX SECTION ...............................................................................42
D3 ELECTRICAL SECTION 2 ......................................................................46
D4 DC POWER SUPPLY SECTION ............................................................74
D5 AIR SUPPLY SECTION ..........................................................................80
UNIT-4: UPPER FRAME SECTION 89
E1 BEAM SECTION .....................................................................................90
E2 CUTTER SECTION ..............................................................................106
E3 COMPONENT RECOGNITION SECTION ...........................................118
E4 POSITIONING UNIT .............................................................................122
E5 ELECTRICAL SECTION 3 ....................................................................132
UNIT-5: PANEL, CENTER FRAME SECTION 137
F1 PANEL, CENTER FRAME SECTION ...................................................138
UNIT-6: HIGH SPEED HEAD, NOZZLE STOCKER SECTION
145
G1 HIGH SPEED HEAD SECTION ............................................................146
G2 HIGH SPPED NOZZLE STOCKER SECTION .....................................158
UNIT-7: CONVEYOR SECTION 167
H1 SINGLE CONVEYOR SECTION ..........................................................168
H2 DUAL CONVEYOR SECTION ..............................................................192
H3 SINGLE CONVEYOR SECTION ( KYX ) ..............................................234
UNIT-8: STANDARD ACCESSORIES 265
I1 STANDARD ACCESSORIES ................................................................266
UNIT-9: BACK-UP BASE UNIT (SELECTION) 269
J1 BACK-UP BASE UNIT (SELECTION) ..................................................270
