– 53 – ELEC TRICA L SECTION 2 181 1-006 No. Part No. Part Name Qty . Detail Y amaha Hitachi 302 KYB-M650J-00 1010BA2R P ANEL SIDE-M 1 305 KYB-M65BL-00 4S210127 EM-CONT ACTOR 3 309 KYB-M657F-00 1010BA33 RESISTOR-SPECIAL 2…
– 53 –
ELECTRICAL SECTION 2
1811-006
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
302 KYB-M650J-00 1010BA2R PANEL SIDE-M 1
305 KYB-M65BL-00 4S210127 EM-CONTACTOR 3
309 KYB-M657F-00 1010BA33 RESISTOR-SPECIAL 2
310 KYB-M656T-00 1005BA2N BREAKER 1
313 KYB-M65AX-00 23N30651 ACCESS-WIRING 1
314 KYB-M65BM-00 4S250321 CIRCUIT-PROTECTOR 1
323 KYB-M658L-00 4F400028 COMP-CR 2
324 KYB-M658S-00 4S210132 EM-CONTACTOR 2
325 KYB-M65BD-00 4J320241 TERMINAL 2
326 KYB-M65BC-00 4J320187 TERMINAL 2
327 KYB-M65AV-00 23N30612 ACCESS-WIRING 1
328 KYB-M65AU-00 23N30524 ACCESS-WIRING 8
334 KYB-M658F-00 23N30542 RAIL-WIRING 2
337 KYB-M6587-00 23N10027 TERMINAL 4
340 90990-11J016 221DA053 SCREW,PAN HEAD WW 19 PAN M4L6 SW+FW
341 90990-11J019 221DA063 SCREW,PAN HEAD WW 4 PAN M4L12 SW+FW
343 KYB-M65AB-00 226J0373 MOUNTING_BASE 10
344 KYB-M65AW-00 23N30632 WIRING 3
345 90990-11J021 221DA064 SCREW,PAN HEAD WW 4 PAN M5L8 SW+FW
