– 85 –
AIR SUPPLY SECTION
1811-006
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
101 KYB-M850F-00 225B0593 AIR_LINE_EQPT 1
102 KYB-M8520-00 225F0073 PIPE_FITTINGS 1
103 $KK130P-02MS 1005BB17 AIR_COUPLER_PLUG 1
104 KYB-M8512-00 1005AB09 PIPE_FITTINGS 1
111 KYB-M851Y-00 225D0089 VACUUM_PARTS 1
112 KYB-M850G-00 225B0594 AIR_LINE_EQPT 1
113 KYB-M8505-00 09141A08 ASSY_SWITCH 1 S141
114 KYB-M851W-00 225B0501 AIR_LINE_EQPT 1
115 KYB-M850B-00 1010BB0H PLATE_AIR-SUP 1
116 KYB-M850H-00 0914B10N REGULATOR 1
119 KYB-M850W-00 1005AB04 PIPE_FITTINGS 2
120 KYB-M8510-00 1005AB07 PIPE_FITTINGS 1
121 KYB-M711J-00 225F0550 PIPE_FITTINGS 1
122 KYB-M8524-00 225F0439 PIPE_FITTINGS 1
123 KYB-M8526-00 225F0559 PIPE_FITTINGS 2
124 KYB-M851L-00 225F0708 PIPE_FITTINGS 2
125 KYA-M850M-00 1005BB0T TUBE_D6 1
126 KYA-M850N-00 1005BB0U TUBE_D8 1
127 90990-11J022 221DA055 SCREW,PAN HEAD WW 4
131 KYB-M852C-00 23K20117 CASE-CONN 1
132 KYB-M852D-00 23K20118 CASE-CONN 1
133 KYB-M852F-00 4J100919 CONNECTOR 1
135 98502-03008 221DA011 SCREW,PAN HEAD 4 PAN M3L8 SW+FW
141 KYB-M8518-00 1005BB1A VACUUM_PUMP 1 MM90038
142 $MBA1403 225F0107 PIPE_FITTINGS 1
143 KYB-M8521-00 225F0106 PIPE_FITTINGS 3
144 $MPG14 225F0108 PIPE_FITTINGS 1
145 KYA-M850J-00 225F0692 PIPE_FITTINGS 1
146 KYA-M850K-00 225B0551 AIR_LINE_EQPT 1
147 KYB-M850M-00 0914B206 TUBE_D10_BU 1
148 KYB-M851D-00 1010BB01 INSULATOR_GUM 1
149 KYB-M850A-00 1010BA0U PLATE VP 1
151 KYB-M850C-00 1010BC3D HNS,VP-1 1
152 91312-05006 221AA027 BOLT,HEX.SOCKET HEAD 8 M5L6
153 91312-06010 221AA041 BOLT,HEX.SOCKET HEAD 4 M6L10
154 92902-05200 221HA105 WASHER,PLAIN 8 FW5
155 92902-06200 221HA106 WASHER,PLAIN 4 FW6
