UNIT-4: UPPER FRAME SECTION
CONTENTS
E1 BEAM SECTION 90
1 Upper Frame Unit 90
2 Y Axis Base 94
3 X Axis Base 98
4 X Beam Unit 100
5 X Axis Driving Section 102
6 Robot Cable 104
E2 CUTTER SECTION 106
1 Cover 106
2 Motor 108
3 Pully, Belt 110
4 Clump Bar 112
5 Cutter 114
6 Cart, Cutter Kit 116
E3 COMPONENT RECOGNITION
SECTION 118
1 Recognition Camera F 118
2 Recognition Camera R 120
E4 POSITIONING UNIT 122
1 Gear 122
2 Sensor 124
3 Frame L 126
4 Frame R 128
5 Air Piping 130
E5 ELECTRICAL SECTION 3 132
1 I/F Connector, PCB 132
2 Breaker, Noise Filter 134
