B,C T able A,D T able A T able B T able C T able D T able 6 13 10 1 1 8 9 13 3 12 4 13 9 1 4 6 13 5 7 7 13 9 1 13 12 5 2 4 4 1 1 8 10 9 6 4 Feeder T op Det.-Op- Feeder Holder KHN-080821 No. Part No. Part Name Q'ty R…

100%1 / 41
A,D Table
A,D Table
S.T.D
B,C Table
F.E.S
B,C Table
A Table
B Table
C Table
D Table
15
15
6
12
9
13
11
15
10
16
17
3
3
4
5
14
11
1
10
11
17
16
12
11
8
4
5
16
17
15
15
6
14
11
10
12
11
3
12
15
6
15
4
17
16
14
2
11
10
5
9
11
13
2
7
16
16
1
14
6
15
4
5
3
5
4
Feeder Floating Det.-Op-
Feeder Holder
KHN-080821
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 KHN-M3901-10X BRACKET SENSOR 2 for Left setting
2 KHN-M3901-20X BRACKET SENSOR 2 for Right setting
3 KG2-M3903-10X SEAL,LASER 4
4 KHN-M3906-00X BRACKET 6 4
5 KHN-M3910-00X BRACKET SENSOR 1 4
6 KGS-M3911-00X SQUARE WASHER 4
7 KGS-M3941-00X BRACKET 4-1,SENSOR R 1 for Right setting
8 KGS-M3942-00X BRACKET 4-2,SENSOR R 1 for Left setting
9 KGS-M3790-00X SENSOR BRACKET 2 for F.E.S
10 KHN-M3951-00X PLATE SENSOR 4
11
KHN-M653E-10X SENSOR,LSR-24 A-R 1 A-Table 24 R>L
KHN-M653E-20X SENSOR,LSR-8 A-R 1 A-Table 8 R>L
KHN-M653E-30X SENSOR,LSR-24 B-R 1 B-Table 24 R>L
KHN-M653E-40X SENSOR,LSR-8 B-R 1 B-Table 8 R>L
KHN-M653E-50X SENSOR,LSR-24 C-R 1 C-Table 24 R>L
KHN-M653E-60X SENSOR,LSR-8 C-R 1 C-Table 8 R>L
KHN-M653E-70X SENSOR,LSR-24 D-R 1 D-Table 24 R>L
KHN-M653E-80X SENSOR,LSR-8 D-R 1 D-Table 8 R>L
KHN-M653E-90X SENSOR,LSR-24 A-L 1 A-Table 24 L>R
KHN-M653E-A0X SENSOR,LSR-8 A-L 1 A-Table 8 L>R
KHN-M653E-B0X SENSOR,LSR-24 B-L 1 B-Table 24 L>R
KHN-M653E-C0X SENSOR,LSR-8 B-L 1 B-Table 8 L>R
KHN-M653E-D0X SENSOR,LSR-24 C-L 1 C-Table 24 L>R
KHN-M653E-E0X SENSOR,LSR-8 C-L 1 C-Table 8 L>R
KHN-M653E-F0X SENSOR,LSR-24 D-L 1 D-Table 24 L>R
KHN-M653E-G0X SENSOR,LSR-8 D-L 1 D-Table 8 L>R
12 90115-02J005 BOLT HEX.SOCKET HEAD 8
13 90115-02J006 BOLT HEX.SOCKET HEAD 4 for F.E.S
14 91317-03012 BOLT HEX.SOCKET HEAD 8 M3X12
15 91317-04010 BOLT HEX.SOCKET HEAD 16 M4X10
16 91317-04012 BOLT HEX.SOCKET HEAD 16 M4X12
17 92907-04200 WASHER,PLAIN 8
B,C Table
A,D Table
A Table
B Table
C Table
D Table
6
13
10
11
8
9
13
3
12
4
13
9
1
4
6
13
5
7
7
13
9
1
13
12
5
2
4
4
11
8
10
9
6
4
Feeder Top Det.-Op-
Feeder Holder
KHN-080821
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 KHN-M39A1-00X PLATE,SENSOR 2
2 KHN-M39A2-10X BRACKET,SENSOR 1 1 for A,D Table
3 KHN-M39A2-20X BRACKET,SENSOR 1 1 for B,C Table
4 KHN-M39A3-00X PLATE,NUT 4
5 KHN-M39A4-00X BRACKET,SENSOR 2 2
6 KHN-M39A5-00X BRACKET,RECEIVER 2
7 KHN-M39A6-00X SQUARE WASHER 2
8 KHN-M39A7-00X COVER,SENSOR 2
9
KHN-M653E-10X SENSOR,LSR-24 A-R 1 A-Table 24 R>L
KHN-M653E-20X SENSOR,LSR-8 A-R 1 A-Table 8 R>L
KHN-M653E-30X SENSOR,LSR-24 B-R 1 B-Table 24 R>L
KHN-M653E-40X SENSOR,LSR-8 B-R 1 B-Table 8 R>L
KHN-M653E-50X SENSOR,LSR-24 C-R 1 C-Table 24 R>L
KHN-M653E-60X SENSOR,LSR-8 C-R 1 C-Table 8 R>L
KHN-M653E-70X SENSOR,LSR-24 D-R 1 D-Table 24 R>L
KHN-M653E-80X SENSOR,LSR-8 D-R 1 D-Table 8 R>L
KHN-M653E-90X SENSOR,LSR-24 A-L 1 A-Table 24 L>R
KHN-M653E-A0X SENSOR,LSR-8 A-L 1 A-Table 8 L>R
KHN-M653E-B0X SENSOR,LSR-24 B-L 1 B-Table 24 L>R
KHN-M653E-C0X SENSOR,LSR-8 B-L 1 B-Table 8 L>R
KHN-M653E-D0X SENSOR,LSR-24 C-L 1 C-Table 24 L>R
KHN-M653E-E0X SENSOR,LSR-8 C-L 1 C-Table 8 L>R
KHN-M653E-F0X SENSOR,LSR-24 D-L 1 D-Table 24 L>R
KHN-M653E-G0X SENSOR,LSR-8 D-L 1 D-Table 8 L>R
10 90115-02J005 BOLT HEX.SOCKET HEAD 4
11 91317-03005 BOLT HEX.SOCKET HEAD 4 M3X5
12 91317-03014 BOLT HEX.SOCKET HEAD 4 M3X14
13 91317-04012 BOLT HEX.SOCKET HEAD 16 M4X12
1
5
Normal Head
Head
KHN-1002
25
40
28
28
39
30
32
33
36
24
27
32
26
23
23
38
6
5
29
17
16
15
34
9
8
22
35
1
4
7
13
19
20
18
3
37
12
14
20
19
18
4
50
49
7
13
19
20
18
3
37
12
14
20
19
18
36
34
10
2
11
21
38
29
17
16
15
34
10
8
22
35
34
9
11
21
42
43
31
31
OLD
41
29
46
47
42
44
45
44
45
48
bit type
non bit type
BLACK
GRAY
51
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 KHN-M7112-00X HOUSING,SHAFT 1
2 KHN-M7117-00X SCRN,HEAD STD 1
3 KGS-M7145-00X PLATE,STOPPER 8
4 KHN-M7141-00X SPLINE SHAFT 8
5 KHN-M7142-00X BLOCK,SPLINE R 4
6 KHN-M7143-00X BLOCK,SPLINE L 4
7 KHN-M7144-00X COLLAR, BRG 8
8 KHN-M7145-00X NUT,SPLINE 8
9 KHN-M7146-00X PULLY 8
10 KHN-M7147-00X COLLAR PULLY 8
11 KHN-M714B-00X PLATE BEARING 8
12 KHN-M714G-00X SHAFT,NOZZLE 8
13 KM1-M7106-90X SPG. NOZZLE 8
14 90990-19J008 NEEDLE PIN 8
15 90933-02J695 BEARING 8
16 95602-05100 NUT U 8
17 90990-22J009 PACKING 8
18 KG7-M7137-A0X LEAF SPRING 16
19 KG7-M7169-00X SCREW 16
20 90990-28J002 WASHER PLAIN 16
21 KV8-M7536-00X BOLT HEX.SOCK.H.M3L4 8
21-1 91317-03004 BOLT HEX.SOCKET HEAD 8 (2007/10/29) MD00030 OK
21-2 KHN-M714C-00X PLUG 8 (2008/1/11) ME10017 OK
22 KM0-M3416-00X GASKET 8
23 KHW-M7171-00X EJECTOR,RESIN 1 non bit type
23-1 KHW-M71G1-00X EJECTOR,RESIN 1 bit type (2008/5/23) ME30096 NG
24 KHN-M7172-00X MANIFOLD 1
25 KHL-M4592-00X VAC SENSOR BOARD 1
26 KGB-M7183-00X PLATE,EJECTOR 1
27 90990-22J001 PACKING 8
28 $TL10-01 JOINT 2
29 $TSH4-M5M JOINT 16
30 $PFS-M3 PLUG 8
31 $UEF4BU-M3 JOINT 8
31-1 $BF4BU-M3 JOINT 8 (2008/5/23) ME30096 NG
32 90990-20J001 PIN DOWEL 2
33 98702-03006 SCREW FLAT HEAD 3
34 92A08-03303 SET SCREW M3X3 16
35 90115-2AJ008 BOLT HEX.SOCKET HEAD 24
36 91317-03006 BOLT HEX.SOCKET HEAD 12
37 91317-03008 BOLT HEX.SOCKET HEAD 16
38 91317-03010 BOLT HEX.SOCKET HEAD 24
39 91317-03055 BOLT HEX.SOCKET HEAD 4
40 91317-04018 BOLT HEX.SOCKET HEAD 4
41 KM5-M7174-C1X EJECTOR BASE 8
42 KGS-M7171-A0X EJECTOR 8 Spare (non bit type)
42-1 KHW-M71G2-00X EJECTOR 8 Spare (bit type) (2008/1/29) MDY0141 NG
43 KHW-M7171-G0X FILTER CAP 8
44 KM1-M7163-20X VALVE 1
45 KM1-M7163-30X VALVE 1
46 90990-17J010 O-RING 8
47 K46-M8527-C0X FILTER 8
48 KHW-M71G4-00X BIT 1
49 KHN-M714S-A0X STD.SHAFT 1,SPARE 1 Spare (For Head 1.3.5.7)
50 KHN-M714S-B0X STD.SHAFT 2,SPARE 1 Spare (For Head 2.4.6.8)
51 KHW-M71G2-10X EJECTOR SPARE 1 bit type (2009/12/22) MFY0099
