KHN_YG300_PL - 第3页
1 2 3 41 43 43 42 46 7 52 50 50 52 30 30 52 32 31 34 34 16 17 60 25 56 56 46 40 8 8 41 39 5 5 6 38 38 37 52 52 57 53 57 53 57 53 19 52 48 48 59 59 49 49 62 61 44 44 45 58 54 58 54 22 18 15 24 27 28 21 20 29 60 23 26 34 3…
Contents
6 Nozzle Section
Nozzle Selection ...................................................6-1
Nozzle Changer (A,D TABLE) ..............................6-2
Nozzle Changer (B,C TABLE) ..............................6-3
7 Camera Section
Multi Camera & Light ............................................7-1
8 Conveyor Unit Section
Push Up ................................................................8-1
Clamp Assy ..........................................................8-2
UL Conveyor .........................................................8-3
UR Conveyor ........................................................8-4
Moving Conveyor A,D-1 .......................................8-5
Moving Conveyor A,D-2 .......................................8-6
Moving Conveyor B,C-1 .......................................8-7
Moving Conveyor B,C-2 .......................................8-8
9 Blow Station Section
Blow Station ..........................................................9-1
10
Side View Camera
Side View Camera ..............................................10-1
11
Controller Section
Servo ..................................................................11-1
System ................................................................11-2
12
Exterior,etc Section
Exterior,etc ..........................................................12-1
1 Base Section
Base .....................................................................1-1
2 Cover Section
Top Cover .............................................................2-1
Base Cover ...........................................................2-2
3 Moving-axis Section
X-axis (A,D TABLE) ..............................................3-1
X-axis (C,B TABLE) ..............................................3-2
Y-axis (Drive 1) .....................................................3-3
Y-axis (Drive 2) .....................................................3-4
Y-axis (Frame) ......................................................3-5
U-axis Assy ...........................................................3-6
UL/R-axis Assy .....................................................3-7
Transfer (Drive) .....................................................3-8
Transfer (Guide) ...................................................3-9
Transfer (Claw)
..................................................3-10
4 Feeder Holder Section
Feeder Holder 24 (STD/IND) ................................4-1
Feeder Holder 24 (CLI/IND) .................................4-2
Feeder Holder 8 (STD/IND) ..................................4-3
Feeder Holder 8 (CLI/IND) ...................................4-4
Feeder Floating Det.-Op-......................................4-5
Feeder Top Det.-Op- ............................................4-6
5 Head Section
Normal Head ........................................................5-1
Head Combination ................................................5-2
R-Assy ..................................................................5-3
1
2
3
41
43
43
42
46
7
52
50
50
52
30
30
52
32
31
34
34
16
17
60
25
56
56
46
40
8
8
41
39
5
5
6
38
38
37
52
52
57
53
57
53
57
53
19
52
48
48
59
59
49
49
62
61
44
44
45
58
54
58
54
22
18
15
24
27
28
21
20
29
60
23
26
34
33
33
35
36
35
36
31
52
56
39
55
39
39
39
42
4
39
53
57
55
53
57
55
52
52
52
30
33
33
30
52
35
36
34
34
32
34
31
31
35
36
52
52
52
13
14
51
12
52
52
52
47
10
11
51
56
40
52
44
45
44
52
52
9
53
57
55
53
57
55
53
57
55
53
57
55
53
57
53
55
57
52
52
63
64
1
1
Base
Base
KHN-080805
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 KGA-M1180-00X LEVELING BOLT ASSY 8
2 KHN-M1101-00X BASE 1
2-1 KHN-M1101-01X BASE 1 (2007/9/11) MD80126 OK
3 KHN-M1118-00X PLATE 8 1
4 KHN-M1112-00X PLATE 2 1
5 KHN-M1111-00X PLATE 1 2
6 KHN-M1115-00X PLATE 5 1
7 KHN-M1120-00X PLATE,SW BOARD 1
8 KHN-M1114-00X BRACKET,NOISE FILTER 2
9 KHN-M1121-00X BRACKET,PW SUPPLY 1
9-1 KHN-M1121-01X BRACKET,PW SUPPLY 1 (2007/9/5) MD80100 OK
10 KHN-M1116-00X BRACKET 1,48V 1
10-1 KHN-M1116-01X BRACKET 1,48V 1 (2007/9/13) MD80109 OK
11 KHN-M1117-00X BRACKET 2,48V 1
11-1 KHN-M1117-01X BRACKET 2,48V 1 (2007/9/13) MD80109 OK
12 KHN-M1119-00X BRACKET,10V 1
13 KHN-M111A-00X COVER,10V 1
14 KHN-M111B-00X COVER 2 1
15 KHN-M1113-00X PLATE 3 1
16 KHN-M8583-00X VALVE ASSY. 1
17 KHN-M8501-00X FILTER UNIT 1
18 KH1-M8501-00X EXHAUST VALVE 1
19 $KM-23 MUFFLER 1
20 KG2-M8512-00X JOINT 1
20-1 90990-42J004 JOINT 1 (2008/6/17) ME30112 OK
21 KG2-M8513-00X JOINT 1
21-1 90990-42J036 JOINT 1 (2008/6/17) ME30112 OK
22 $SL12-04 JOINT 3
22-1 $SL12-04 JOINT 2 (2008/3/31) ME20030 OK
23 92903-06200 WASHER PLAIN 2
24 91317-03025 BOLT HEX.SOCKET HEAD 2 M3X25
25 91317-04010 BOLT HEX.SOCKET HEAD 4 M4X10
26 91312-06014 BOLT HEX.SOCKET HEAD 2 M6X14
27 KHW-M8582-40X VALVE 1 Spare
28 KHN-M8501-10X ELEMENT 1 Spare
29 KHN-M8501-20X MANTLE 1 Spare
30 KHN-M1325-00X BRACKET 5 4
31 KGK-M1141-00X MANUFOLD 4
32 K40-M8598-00X PLUG 1 2
33 $TSS4-01 JOINT 12
34 $TSH8-01 JOINT 6
35 92903-04200 WASHER PLAIN 12
36 91312-04008 BOLT HEX.SOCKET HEAD 12 M4X8
37 KHN-M11T1-00X PLATE,TRANS(S) 1
38 KHN-M11T2-00X PLATE 11(TRANS) 2
39 KGS-M1317-00X COVER 17 8
40 KGS-M111D-00X PLATE,GATE IN/OUT 2
41 KHN-M1338-01X BRACKET,MAIN SW 2
42 KHN-M1337-00X BRACKET,LEFT 4
43 KHN-M1339-00X BRACKET,CENTER 2
43-1 KHN-M1339-01X BRACKET,CENTER 2 (2008/4/1) ME30294 OK
44 KHN-M1151-00X PLATE,SIDE 1 4
45 KHN-M1152-00X PLATE,SIDE 2 2
46 KHN-M111D-00X PLATE,GATE IN/OUT 2
47 KHN-M1125-00X SCREW,PLUG 8
48 KHN-M1126-00X BRACKET,TANK 2
49 KM5-M8531-00X ACCUMLATAOR 4
50 KHN-M1127-00X BRKT.IND.BD. 2
51 90990-12J001 SCREW BIN.HEAD W/W 9
52 90990-12J004 SCREW BIN.HEAD W/W 92
53 92903-05200 WASHER PLAIN 38
54 92907-06200 WASHER PLAIN 8
55 92990-05400 WASHER EXTL.TOOTHED 32
55-1 90172-00J050 WASHER,EXTL.TOOTHED 32 (2008/4/15) ME40115 OK
56 91312-05008 BOLT HEX.SOCKET HEAD 16 M5X8
57 91312-05010 BOLT HEX.SOCKET HEAD 38 M5X10
58 91317-06006 BOLT HEX.SOCKET HEAD 9 M6X6
59 91312-08012 BOLT HEX.SOCKET HEAD 8 M8X12
60
$TL12-04 JOINT 1
(2008/3/31) ME20031 OK
61
$TS12-04 JOINT 4
62
$TL12-04 JOINT 4
63 KHN-M8501-30X BOWL (M4000-W-F1) 2 (2011/12/20) MH00013
64 KHN-M8501-40X BOWL GUARD (F4000-W) 2 (2011/12/20) MH00013
29
58
53
28
28
28
55
57
57
56
47
59
43
44
44
45
61
59
61
42
56
2
38
29
29
27
35
26
29
9
29
12
24
24
40
40
63
65
64
29
66
7
8
29
56
48
52
52
51
59
55
47
56
59
60
54
50
50
4
35
27
29
29
35
27
29
29
7
16
29
23
28
22
28
20
20
21
29
23
28
21
29
29
28
30
30
28
15
25
29
1
3
39
29
30
29
29
29
11
10
35
35
27
29
26
29
27
26
8
18
19
17
5
29
8
6
29
26
29
18
19
17
9
27
35
12
26
35
27
29
8
29
26
62
62
49
49
59
46
29
16
15
29
28
28
22
59
41
37
34
32
37
37
34
34
32
32
28
28
14
14
13
36
36
36
36
33
33
33
33
31
31
32
32
34
34
37
37
32
34
37
31
31
33
31
36
36
33
33
31
31
26
29
24
24
36
36
33
31
1
2
Top Cover
Cover
KHN-080807
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 KHN-M1301-00X COVER-1F 1
1-1 KHN-M1301-01X COVER-1F 1 (2008/5/17) ME50009 NG
2 KHN-M1302-00X COVER 2F 1
2-1 KHN-M1302-01X COVER 2F 1 (2008/5/17) ME50009 NG
3 KHN-M1303-00X COVER-3F 1
3-1 KHN-M1303-01X COVER-3F 1 (2008/4/1) ME30294 NG
3-2 KHN-M1303-02X COVER-3F 1 (2008/5/17) ME50009 NG
4 KHN-M1301-50X COVER-1R 1
4-1 KHN-M1301-51X COVER-1R 1 (2008/5/17) ME50009 NG
5 KHN-M1302-50X COVER 2R 1
5-1 KHN-M1302-51X COVER 2R 1 (2008/5/17) ME50009 NG
6 KHN-M1303-50X COVER-3R 1
6-1 KHN-M1303-51X COVER-3R 1 (2008/4/1) ME30294 NG
6-2 KHN-M1303-52X COVER-3R 1 (2008/5/17) ME50009 NG
7 KHN-M1302-10X COVER 2C 2
8 KHN-M1301-10X COVER, MOTOR 1 4
8-1 KHN-M1301-11X COVER,MOTOR 1 4 (2008/5/17) ME50009 NG
9 KHN-M1303-20X COVER, MOTOR 2 2
9-1 KHN-M1303-21X COVER,MOTOR 2 2 (2008/5/17) ME50009 NG
10 KHN-M1303-10X BOX,USB 1
11 KHN-M1305-00X DOOR,USB 1
12 KGA-M1318-00X COVER 18 2
12-1 KGA-M1318-00X COVER 18 4 (2008/4/1) ME30294 OK
13 KHN-M1306-00X COVER 6 1
14 KHN-M1306-10X COVER 6-1 2
15 KHN-M1307-00X COVER-7 2
16 KHN-M1307-10X COVER 7-1 2
17 KHN-M1352-00X PLATE,JOINT 1 2
18 KHN-M1351-00X PLATE,JOINT 2 2
19 KHN-M1353-00X PLATE,JOINT 3 2
20 KHN-M1335-00X BRACKET,GATE COVER 1 4
21 KHN-M1319-00X COVER 19 2
22 KHN-M1320-00X COVER 20 2
23 KHN-M1321-00X COVER 21 2
24 KV7-M1391-10X PLUG 4
25 KGA-M1392-00X PLUG(30) 1
26 KW8-M1386-00X BRACKET,MAGNET 8
27 KJ9-M1354-10X MG.CATCH 8 TL272-2
27-1 KHN-M1354-00X STOPPER,DOOR 8 (2007/9/12) MD80127 OK
28 K16-90103-00X BOLT 3 TP-M4X8
28-1 90990-46J006 BOLT,THIN HEAD 3 (2008/6/16) ME50123 OK
29 90990-12J001 SCREW BIN.HEAD W/W 216
30 90990-12J004 SCREW BIN.HEAD W/W 62
31 92990-04400 WASHER EXTL.TOOTHED 16
31-1 90172-00J040 WASHER,EXTL.TOOTHED 16 (2008/4/15) ME40115 OK
32 92990-05400 WASHER EXTL.TOOTHED 20
32-1 90172-00J050 WASHER,EXTL.TOOTHED 20 (2008/4/15) ME40115 OK
33 92990-04200 WASHER PLAIN 16
34 92990-05200 WASHER PLAIN 28
35 91312-03006 BOLT HEX.SOCKET HEAD 16 M3X6
36 91312-04010 BOLT HEX.SOCKET HEAD 16 M4X10
37 91312-05010 BOLT HEX.SOCKET HEAD 28 M5X10
38 KHN-M13D6-00X SEAL 1(YG300) 1
39 KW7-M13D7-01X SEAL 2(YAMAHA) 1
40 KW3-M1349-00X MINI LATCH 1
41 KHN-M130A-00X COVER-9 1
41-1 KHN-M130A-01X COVER-9 1 (2008/4/2) ME30232 NG
42 KHN-M1340-00X BRACKET 1,COVER-9 1
42-1 KHN-M1340-01X BRACKET 1,COVER-9 1 (2008/4/2) ME30232 NG
43 KHN-M1341-00X BRACKET 2,COVER-9 1
43-1 KHN-M1341-01X BRACKET 2,C0VER-9 1 (2008/4/2) ME30232 NG
44 KHN-M1342-00X BRACKET 3,COVER-9 2
45 KHN-M1343-00X BRACKET 4,COVER-9 1
46 KHN-M1344-00X BRACKET 5,COVER-9 1
46-1 KHN-M1344-01X BRACKET 5,COVER 9 1 (2008/4/2) ME30232 NG
47 KHN-M1345-00X BRACKET,DAMPER 2
48 KHN-M1347-00X BRACKET,KEY 1
48-1 KHN-M1347-01X BRACKET,KEY 1 (2007/9/12) MD80127 OK
49 KHN-M1349-00X HINGE 2
50 KHN-M130C-00X BRACKET,HINGE 2
51 KL0-M1374-00X PLATE 1,SCHMESAL 1
52 KGS-M1360-00X BOLT 4
53 KH2-M1324-00X GRIP 1
54 KHN-M1346-00X STOPPER BLOCK 1
55 KHN-M1348-00X GAS,SPRING 2
56 KM0-M1346-00X SHOULDER,BOLT 4
56-1 90990-31J006 BOLT,SHOULDER 4 (2008/6/24) ME10118 OK
57 95307-06700 NUT HEXAGON 2
58 91317-04012 BOLT HEX.SOCKET HEAD 3 M4X12
59 91317-04008 BOLT HEX.SOCKET HEAD 16 M4X8
60 91317-05010 BOLT HEX.SOCKET HEAD 2 M5X10
61 91317-05008 BOLT HEX.SOCKET HEAD 4 M5X8
62 90990-12J002 SCREW BIN.HEAD W/W 6
63 KHN-M13A1-00X COVER 1,FEEDER SIDE 4
64 KHN-M13A2-00X COVER 2,FEEDER SIDE 4
65 KHN-M13A3-00X COVER 3,MULTI CAMERA 4
66 KHN-M1309-A0X COVER 9 ASSY. 4
