1 1 1 Servo Controller KHN-080903 No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati. 1 KHL-M41 10-00X BOX ASSY .SER VO C/R 1 2 KHL-M4510-00X MOTHER BOARD ASSY 1 3 KHL-M5880-00X D.POWER BOARD ASS…
1
10
Side View Camera
Side View Camera
KHN-080903
17
26
26
14
13
19
24
21
22
25
20
28
16
15
15
16
17
18
31
32
34
19
24
27
23
18
12
4
6
30
6
9
7
6
9
29
2
11
8
3
10
1
33
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 KHN-M7910-00X BASE,S.VIEW CAMERA 1
2 KHN-M7911-00X STAY 1,S.VIEW CAMERA 1
3 KHN-M7912-00X STAY 2,S.VIEW CAMERA 1
4 KHN-M7915-00X COVER,S.VIEW CAMERA 1
5 90115-02J008 BOLT HEX.SOCKET HEAD 4
6 91317-04010 BOLT HEX.SOCKET HEAD 9 M4X10
7 91317-04016 BOLT HEX.SOCKET HEAD 4 M4X16
8 91317-05012 BOLT HEX.SOCKET HEAD 4 M5X12
9 92907-04200 WASHER PLAIN 8
10 99480-04008 PIN,PARALLEL:4X8 2
11 $NK-4N NYLON CLIP 1
12 KV7-M7165-00X SEAL DON'T TOUCH 1
13 KHN-M71G1-00X BLOCK,SV R 1
14 KHN-M71G2-00X BLOCK,SV L 1
15 KHN-M71G3-00X BLACKET,SV 2
16 KHN-M71G5-00X PLUNGER 2
17 KHN-M71G6-00X STRIPPER BOLT 2
17-1 90990-31J025 BOLT,SHOULDER 2 (2008/6/24) ME10118 OK
18 KHN-M71G7-00X FASTENER 2
19 KHN-M71G8-00X FASTENER SPRING 2
20 KHN-M7902-00X PLATE,S.VIEW LIGHT 1
21 KHN-M7903-00X DIFFUSER,SV LIGHT 1
22 KHL-M7905-01X S.V.LIGHT BRD. ASSY 1
22-1 KHL-M7905-02X S.V.LIGHT BRD. ASSY 1 (2007/10/16) MD00039 OK
23 90563-0AJ040 SPACER,BOLT 3
24 91317-03010 BOLT HEX.SOCKET HEAD 4 M3X10
25 91317-04008 BOLT HEX.SOCKET HEAD 4 M4X8
26 91317-04012 BOLT HEX.SOCKET HEAD 4 M4X12
27 90166-02JA04 SCREW,PAN HEAD 3
28 90K41-000240 SEAL DON'T TOUCH 1
29
KHN-M7210-00X CCD CAMERA 1
29-1
KHN-M7210-01X CCD CAMERA 1 (2007/10/10) MD90031 OK
30 KGS-M7914-00X LENS,S,VIEW 1
31 90440-10J050 CIRCLIP 2
32 99480-03008 PIN,PARALLEL 8
33 KHN-M7900-00X S.VIEW CAMERA ASSY 4
34 KHN-M71G0-00X S.V.LIGHT UNIT 4
1
11
Servo
Controller
KHN-080903
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 KHL-M4110-00X BOX ASSY.SERVO C/R 1
2 KHL-M4510-00X MOTHER BOARD ASSY 1
3 KHL-M5880-00X D.POWER BOARD ASSY 1
4 KHN-M5840-10X SERVO BOARD ASSY 2
5 KHN-M5840-20X SERVO BOARD ASSY 1
6 KHN-M5840-30X SERVO BOARD ASSY 1
7 KHN-M64B1-00X BRACKET SRV TRG 2
8 KGA-M4185-10X FAN MOTOR ASSY 2
9 KHL-M5303-00X SW POWER DC5V 75W 1
10 KHL-M5303-10X SW POWER DC12V 75W 1
11 KHL-M53A9-00X FILTER 1
12 KHL-M53E6-00X FILTER 1
13 KHL-M53E7-00X FILTER 1
14 KHL-M53E8-00X FILTER 1
15 KHL-M53E9-00X TAPE 1
16 KHL-M53F7-00X TAPE 1
17 KHL-M53F8-00X TAPE 1
18 KHL-M53F9-00X TAPE 1
19
20 KHL-M11B0-00X LABEL CONTROLLER 1
21 KR8-M459L-00X SEAL NAME,5 1
22 90K41-000710 SEAL,WARNING 1
23 90563-03J100 SPACER BOLT 14
24 97702-50510 SCREW,PAN HEAD TAPPI 8
25 $NK-3N NYLON CLIP 4
26 97602-04308 SCREW,PAN HEAD W/W 16
27 97602-03306 SCREW,BIND HEAD W/W 20
28
29 KHL-M4128-00X PLATE FAN 1
30 KHL-M4130-00X SCREW 2
31 90166-12JA06 SCREW,PAN HEAD W/W 4
8
2
23
27
17
14
12
16
18
31
31
7
29
15
11
13
1
20
20
7
5
6
21
27
24
25
22
27
25
4
9
10
4
3
26
30
30
+3.
3V
+5
V
AC
IN
EMG
I/O
I/O A
I/O B
I/O C
I/O D
I/O A
I/O B
I/O C
I/O D
SD
SC
SB
SA
GOO
SD
SC
SB
SA
GOO
I/O
I/O
TRG1 TRG2
PWR
RUN
TRG1 TRG2
PWR
RUN
CAM1 (HALF) CAM2 (FULL) CAM3 (HALF) CAM4 (FULL)
CAM1 (HALF) CAM2 (FULL) CAM3 (HALF) CAM4 (FULL)
VISION
VISION
LAN
USBUSBUSBUSB
LINK/ACK 100M
SYSTEM
POWER
V
G
A
A
L
M
MOUSE
KEY
VGA SERIAL1
SERIAL2
+3.
3V
AC
IN
POWER
LAN
US US US USB
LINK/ACK 100M
SYSTEM
V
G
A
A
L
M
MOUSE
KEY
VGA SERIAL1
SERIAL2
EMG
I/O
I/O D
I/O C
I/O B
I/O A
EMG
SD
SC
SB
SA
I/F
GO
11.42
11.42
TRG1 TRG2
TRG2
TRG1
PWR
RUN
PWR
RUN
CAM1 (HALF) CAM2 (FULL) CAM3 (HALF) CAM4 (FULL)
CAM4 (FULL)
CAM3 (HALF)
CAM2 (FULL)
CAM1 (HALF)
VISION
VISION
15
4
5
7
11
10
3
12
14
13
20
22
2
18
8
1
19
21
16
17
17
9
6
2
11
System
Controller
KHN-080909
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 KHL-M4260-00X BOX ASSY.SYSTEM C/R 1
2 KHL-M4250-00X BACKPLANE BOARD ASSY 1
3 KHL-M4209-10X SYSTEM UNIT ASSY 1
3-1
KHL-M4209-10X SYSTEM UNIT ASSY 1 STD
KHL-M4209-30X SYSTEM UNIT ASSY 1 for IT Option (2008/3/27) ME30008 NG
4 KHL-M5304-00X SYSTEM POWER UNIT 1
5 KHN-M4530-20X REMOTE IF BOARD ASSY 1
5-1 KHN-M4530-21X REMOTE IF BOARD ASSY 1 (2008/3/19) ME30147 OK
6 KHN-M4530-30X REMOTE IF BOARD ASSY 2
6-1 KHN-M4530-31X REMOTE IF BOARD ASSY 2 (2008/3/19) ME30147 OK
7 KHL-M441H-00X VISION BOARD ASSY 2
7-1 KHL-M441H-02X VISION BOARD ASSY 2 (2008/3/26) ME30250 OK
8 KHL-M4454-00X RAS BOARD ASSY 1
9 KHL-M4456-00X RAS DISP BOARD ASSY 1
10 KHL-M4188-00X PANEL RAS DISP 1
11 KHL-M4279-00X PANEL BLANK 2
12 KHL-M4255-00X FLASH DISK 1
13 KGK-M42D0-00X XP EMBEDDED 1
14 KHL-M42D1-00X RTX 7.0 1
15 KHL-M11B0-10X LABEL CONTROLLER 1
16 90562-03J100 SPACER 4
17 97602-03306 SCREW,BIND HEAD W/W 8
18 90166-12JA06 SCREW,PAN HEAD W/W 12
19 97602-03308 SCREW,PAN HEAD W/W 2
20 KHL-M427G-00X MEDIA FILTER 1
21 KHL-M660J-00X HNS.RAS.TEMP 1
22 KHL-M5184-20X SEAL, ITEM LABEL SYS 1
