SIPLACE GEM for S25, HS50 SW Version GEM 502.01
HOST Interface Manual
Page 216 of 236 ©Siemens AG, all rights reserved
%DUFRGH
CEID Name Description
RPT
920001 Bcread The barcode reader transmits a
barcode <BCININPUTCONVEYOR>
24
920002 ComponentBCread A component barcode is read via GUI. 27
920011 BCTwinRead The barcode reader transmits a
barcode
<BCINTWININPUTCONVEYOR> from
the twin conveyor.
30
921006 FM_GK_LR_DURCHTRANSP Caution: PCB transported through by
line computer
*(0.HUQHO
&(,' 1DPH 'HVFULSWLRQ
1000001 EqConstChange Equipment constant
changed at the machine
0
1000002 S10Ack 1
Communication Model
Control State Model
1000003 GemControlStateLOCAL SIPLACE goes to local
mode
0
1000004 GemControlStateREMOTE SIPLCAE goes to remote
mode
0
1000005 GemEquipmentOFFLINE SIPLACE goes OFFLINE 0
1000018 ControlModeChanged <CONTROLMODE> state
changed (LCU, GEM-Host,
Stand-alone)
0
1000019 OperatorCommand The operator issued a „host
- available“ command while
the SIPLACE is in Remote
mode.
1
Spooling
1000007 GemSpoolingActivated Spooling is activated. This
event is never reported
directly to the host, but
instead is directed as the
first message to the spool
file
0
1000008 GemSpoolingDeactivated The spool area has been
completely emptied.
0
1000009 GemSpoolTransmitFailure Communication error during
transmitting spooled
messages to host. This
0
SIPLACE GEM for S25, HS50 SW Version GEM 502.01
HOST Interface Manual
©Siemens AG, all rights reserved page 217 of 236
&(,' 1DPH 'HVFULSWLRQ
event is never reported
directly to the host, but
instead it is directed to the
end of the spool file
Process State Model
1000010 Init2Process The Siplace change its
processing state from
„Machine Initialization“ to
„Processing“
1
1000011 Process2Init The Siplace change its
processing state from
„Processing“ to „Machine
Initialization“
1
1000012 Process2SingleFunction The Siplace change its
processing state from
„Processing“ to „Single
Function“
1
1000013 SingleFunction2Process The Siplace change its
processing state from
„Single Function“ to
„Processing“
1
1000014 Init2SingleFunction The Siplace change its
processing state from
„Machine Initialization“ to
„Single Function“
1
1000015 SingleFunction2Init The Siplace change its
processing state from
„Single Function“ to
„Machine Initialization“
1
1000020 Proc1PPChangeEvent Board with a new
processing program enters
Processing 1 Area
1
1000021 Proc2PPChangeEvent Board with a new
processing program enters
Processing 2 Area
1
Process Program Management
1000017 GemBadDownloadEvent Error in downloaded
program
1
1001018 FM_GEM_INIT GEM: Error upon
initialization of GEM
interface to host*
1001019 FM_GEM_INIT_MC GEM: Error upon
initialization of interface to
MC*
1001020 FM_GEM_INIT_GUI GEM: Error upon
initialization of interface to
user interface*
1001021 FM_GEM_SIPLACE GEM: Error in SIPLACE
GEM software*
SIPLACE GEM for S25, HS50 SW Version GEM 502.01
HOST Interface Manual
Page 218 of 236 ©Siemens AG, all rights reserved
&(,' 1DPH 'HVFULSWLRQ
1001022 FM_GEM_OP_MELDUNG GEM: Most recent operator
message could not be sent
to the host*
1001023 FM_GEM_VERB_GUI GEM: Faulty connection
between GEM interface and
user interface*
1001024 FM_GENERAL General Error Event
Error messages can be
reported either with specific
error events (an Error Event
with a CEID for each
individual error) or with the
General Error Event that
reports all errors.
The General Error Event
has an error code
<LASTERRORCODE>,
which contains the CEID of
the specific Error Event.
The SV <LASTFMTEXT>
which contains the error
text of the specific Error
Event is also available.
44
* Depending on the collection event, some of the status variables <ERRORTYPE>,
<GANTRYONERROR>, <SEGMENTONERROR>, <TRACKONERROR>,
<ERRORINFO1> and <ERRORINFO2> will be updated at each of these GEM-
kernel collection events.
2SHUDWRU
&(,' 1DPH 'HVFULSWLRQ
1120001 EmergencyStop Emergency stop pressed or Cover
opened
1
1120002 StopButton Stop button pressed 1
1120003 StartButton Start button pressed 1
1120007 GUIStart Message from GUI: Start. 1
1120008 GUISTOP Message from GUI: Stop. 1
1120009 GUIContinue Message from GUI: Continue. 1
1120010 GUIAbort Message from GUI: Abort. 1
1120096 ToGUINewSetUp Message to GUI: NewSetUp 1
1120097 ToGUIPPname Message to GUI: Placement
Program Name
1
1120098 ToGUIActionText Message to GUI: Send
<GUIACTIONTEXT>
1
1120100 ToGUIStateText Message to GUI: Send
<GUISTATETEXT>
1
