SIPLACE GEM for S25, HS50 SW Version GEM 502.01
HOST Interface Manual
Page 10 of 236 ©Siemens AG, all rights reserved
operations with a Host Computer. The SIPLACE complies to the following GEM
document:
1. E30-1994
*(0&RPSOLDQFH
This section clarifies which GEM functions are implemented in this Equipment. See
„GEM Compliance Statement“ on page 11.
The SIPLACE never sends S2F25 (Loopback Diagnostic) to the Host. It will send the
appropriate S2F26 in response to an S2F25 from the Host.
The SIPLACE never sends S9F13 (Conversation Timeout) to the Host. The Equipment
can be defined as having an „infinite timeout“ for conversations.
The SIPLACE never sends S10F7 (Multi-Block Not Allowed) to the Host. It will accept
incoming messages consisting of printable characters and a maximum size of 320
characters.
The SIPLACE will accept, but does not require the Inquire/Grant transaction
(S2F39/S2F40, S6F5/S6F6, S7F1/S7F2) for incoming primary multi-block messages.
SIPLACE GEM for S25, HS50 SW Version GEM 502.01
HOST Interface Manual
©Siemens AG, all rights reserved page 11 of 236
1.4 *(0&RPSOLDQFH6WDWHPHQW
GEM COMPLIANCE STATEMENT
FUNDAMENTAL GEM REQUIREMENTS IMPLEMENTED
COMPLIANT
State Models ✓ Yes ✓ Yes
Equipment Processing States ✓ Yes ✓ Yes
S1,F13/F14 Scenario ✓ Yes ✓ Yes
Event Notification ✓ Yes ✓ Yes
On-line Identification ✓ Yes ✓ Yes
Error Messages ✓ Yes ✓ Yes
Control (Operator Initiated) ✓ Yes ✓ Yes
Documentation ✓ Yes ✓ Yes
ADDITIONAL CAPABILITIES IMPLEMENTED COMPLIANT
Establish Communications ✓ Yes ✓ Yes
Dynamic Event Report Configuration ✓ Yes ✓ Yes
Variable Data Collection ✓ Yes ✓ Yes
Trace Data Collection ✓ Yes ✓ Yes
Status Data Collection ✓ Yes ✓ Yes
Alarm Management ✓ Yes ✓ Yes
Remote Control (1) ¨ No ¨ No
Equipment Constants ✓ Yes ✓ Yes
Process Program Management (2) ¨ No ¨ No
Material Movement ✓ Yes ✓ Yes
Equipment Terminal Services ✓ Yes ✓ Yes
Clock ✓ Yes ✓ Yes
Limits Monitoring ✓ Yes ✓ Yes
Spooling ✓ Yes ✓ Yes
Control (Host Initiated) ✓ Yes ✓ Yes
(1) : Remote commands are not available until a later stage.
(2) : Process Program Management is not implemented until a later stage.
7HUPLQRORJ\
The following terms are used throughout the document to refer to the various entities
interfacing with the SIPLACE:
SIPLACE GEM for S25, HS50 SW Version GEM 502.01
HOST Interface Manual
Page 12 of 236 ©Siemens AG, all rights reserved
(TXLSPHQW The SIPLACE S25 or SIPLACE HS50 with GEM/SECS II-Interface
2SHUDWRU The person who physically has access to the equipment’s material port(s)
and control panel. This is the person who is operating the SIPLACE.
+RVW The computer which is connected to the equipment via the SECSII-interface
0DFKLQH$UHDV
0DFKLQH$UHDVRID6,3/$&(+60DFKLQH
The figure below provides a diagrammatic overview of the individual areas of a
SIPLACE HS-50 placement station.
TWIN-Input
conveyor
TWIN-First
Processing
conveyor
TWIN-Output
conveyor
Input
conveyor
First Processing
conveyor
Output
conveyor
Direction of transport
Conveyor 2
(left)
Conveyor 1
(right)
Gantry 3
Revolverhead 3
Gantry 2
Revolverhead 2
Location
3
Location
2
TWIN-Inter-
mediate conveyor
TWIN-Second
Processing
conveyor
Intermediate
conveyor
Second Processing
conveyor
Gantry 4
Revolverhead 4
Location
4
Gantry 1
Revolverhead 1
Location
1
Processing 1
Area
Processing 2
Area
