SIPLACE GEM for S25, HS50 SW Version GEM 502.01
HOST Interface Manual
©Siemens AG, all rights reserved page 149 of 236
multi-block message is removed from the spool
and not transmitted. Despooling continues.
11. H -> E S6F23 W The Host requests that the Equipment continue
de-spooling messages.
12. H <- E S6F24 Equipment indicates that it will start to send
spooled messages with return code RSDA =
0x00. Go to step 10.
13. H <- E S6F11 W Equipment notifies the Host that sending of
spooled messages has been completed by
sending CEID GemSpooling Deactivated.
14. H -> E S6F12 Host acknowledges that the spool has been
cleared and is deactivated.
+RVW3XUJHV6SRRO
Assumption: spool state is "Spool Active"
Step SECS Message Description
1. H -> E S6F23 W Host sends S2F23, requesting that spool be
discarded with RSDC set to one.
2. H <- E S6F24 Equipment deletes spooled data and returns
RSDA code zero.
SIPLACE GEM for S25, HS50 SW Version GEM 502.01
HOST Interface Manual
Page 150 of 236 ©Siemens AG, all rights reserved
9DULDEOHV
All Ids on SIPLACE are 6 or 7-digits long. The last 3 digits are a consecutively increasing
integer. The next two digits distinguish between errors, event and variables (0:Event,
1:ErrorEvent; 2:Variable) and the software component (0:GEM, 1:Realtimesoftware;
2:Stationsoftware). The first 2 represent the „object“ on which the event occurs.
Example:
6 1 2 007 (Transportwidth)
The objects are :
ObjectId Name
1 Software
2 Nozzle Changer
3Axis
4 Fiducials
5 Vision
6 Transport
7 Coplanarity
8 Matrix Tray Changer (MTC)
9 Barcode
10 GEM-Kernel
11 User Interface / Operator
12 CAN-Bus
13 Revolver Head 1
14 Revolver Head 2
15 IC-Head
16 Data Preparation
17 Trolleys
18 Glue Machine
19 CRDL Measurement
20 Miscellaneous
21 Flux
Object: Transport
Realtimesoftware
Variable
Number
SIPLACE GEM for S25, HS50 SW Version GEM 502.01
HOST Interface Manual
©Siemens AG, all rights reserved page 151 of 236
9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ
Fiducials
412002 SV L FIDUCIALDATA
Result from the last fiducial measurement
/
8)LGXFDO1DPH!
,4XDOLW\!>@
8;SRVLWLRQ!>PP@
8<SRVLWLRQ!>PP@
8;GHYLDWLRQ!>PP@
8<GHYLDWLRQ!>PP@
!
In case of an ink spot x-position, y-position, x-
deviation, y-deviation and quality are not valid.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
An empty list indicates an error.
SIPLACE Transport
612001 SV U1 INPUTCONVEYORSTATE
The state of the input conveyor.
0 = Empty
1 = Full
2 = Error
612012 SV U1 FIRSTPROCESSINGCONVEYORSTATE
The state of the first processing conveyor.
0 = Empty
1 = Full
2 = Error
612013 SV U1 INTERMEDIATECONVEYORSTATE
The state of the intermediate conveyor
0 = Empty
1 = Full
2 = Error
612014 SV U1 SECONDPROCESSINGCONVEYORSTATE
The state of the second processing conveyor.
0 = Empty
1 = Full
2 = Error
612003 SV U1 OUTPUTCONVEYORSTATE.
