SIPLACE GEM for S25, HS50 SW Version GEM 502.01
HOST Interface Manual
©Siemens AG, all rights reserved page 153 of 236
9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ
by line computer
Matrix Tray Changer (MTC)
812002 SV L MTCINFO
/
807&BQXPEHU!valid for all MTC Events
,WRZHU!
,FDUULHUBPRGXO!
,OHYHO!
,GLYLVLRQ!
,)LOOLQJBOHYHO!
!
If you have several MTCs you can identify a MTC by
MTC_number. A MTC has 2 towers (1,2) and on every
tower there are several carrier modules. A carrier
module contains several tray carriers. Each tray carrier
can be identified by a level number. A tray carrier
consists of many divisions, wich can be identified by
the division number.
Filling_level is only valid with the Event
MTCfillLevelChanged.
In case of the Event MTCfillLevelChanged
carrier_modul will be -1.
Barcode
912002 SV A BCININPUTCONVEYOR
Barcode read from PCB in input conveyor. If no
barcode reader is installed in SIPLACE this variable
will contain an empty text
An empty text indicates an error.
912003 DV A COMPONENTBARCODE
Component barcode is read by the GUI.
An empty text indicates an error.
921004 DV U2 WAYOFINPUTCOMPONENTBARCODE
Way of reading the component barcode:
1: with keyboard
2: with barcode reader
3: no barcode read
921005 SV U2 PCBSIDEININPUTCONVEYOR
Side of the PCB showing the barcode (only valid in
case of two barcode reader per conveyor)
1: above
2: down
SIPLACE GEM for S25, HS50 SW Version GEM 502.01
HOST Interface Manual
Page 154 of 236 ©Siemens AG, all rights reserved
9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ
3: barcode reader manufctured by LEUTZE in use RU
the barcode could not be read
921006 SV U2 PCBSIDEINCENTERCONVEYOR
Side of the PCB showing the barcode (only valid in
case of two barcode reader per conveyor)
1: above
2: down
3: barcode reader manufctured by LEUTZE in use RU
the barcode could not be read
912012 SV A BCINTWININPUTCONVEYOR
Barcode read from PCB in twin input conveyor. If no
barcode reader is installed in SIPLACE this variable
will contain an empty text.
An empty text indicates an error.
921015 SV U2 PCBSIDEINTWININPUTCONVEYOR
Side of the PCB showing the barcode (only valid in
case of two barcode reader per conveyor)
1: above
2: down
3: barcode reader manufctured by LEUTZE in use RU
the barcode could not be read
912017 EC U1 BCREADEREXIST
Unables/Enables the event messages of the BCread
and BCTwinRead events.
0: No BCread and BCTwinRead events send
1: BCread and BCTwinRead events send (default)
GEM-Kernel
1002001 DV A GEMEVENTTEXT.
The equipment will set this string to contain a
description of the most recent event. The Host can
include this variable in any event report it defines.
Communication Model
1002002 EC U1 INITCOMMSTATE.
Initial (power-up) Communications State.
0 = Disabled
1 = Enabled
1002003 EC U2 ESTABLISHCOMMUNICATIONSTIMER.
Time in seconds of how long the equipment will pause
after an unsuccessful Connect Request before
sending another. Valid values are 0-32000.s
1002004 EC U1 CONFIGCONNECT.
An EC which controls which SECS message this
SIPLACE GEM for S25, HS50 SW Version GEM 502.01
HOST Interface Manual
©Siemens AG, all rights reserved page 155 of 236
9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ
Equipment will use for Connect Request.
0 = S1F1
1 = S1F65
2 = S1F13
Control State Model
1002005 EC U1 INITCONTROLSTATE.
Initial (power-up) control superstate.
1 = Off-Line
2 = On-Line
1002006 SV U1 CONTROLSTATE.
The current Control State.
1 = Off-Line/Equipment Off-Line
2 = Off-Line/Attempt On-Line
3 = Off-Line/Host Off-Line
4 = On-Line/Local
5 = On-Line/Remote
1002007 SV U1 PREVIOUSCONTROLSTATE.
The Control State in effect before the most recent
transition to the current Control State.
1 = Off-Line/Equipment Off-Line
2 = Off-Line/Attempt On-Line
3 = Off-Line/Host Off-Line
4 = On-Line/Local
5 = On-Line/Remote
1002008 EC U1 ONLINEFAILED.
The default Control State transition when Attempt On-
Line fails.
1 = Equipment Off-Line
3 = Host Off-Line
1002009 EC U1 ONLINESUBSTATE.
The default (power-up) online substate of the Control
State Model.
4 = Local
5 = Remote
1002010 EC U1 OFFLINESUBSTATE.
The default (power-up) offline substate of the Control
State Model.
1 = Equipment Off-Line
2 = Attempt On-Line
3 = Host Off-Line
