SIPLACE GEM for S25, HS50 SW Version GEM 502.01
HOST Interface Manual
©Siemens AG, all rights reserved page 165 of 236
9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ
is left empty.
If the component was picked up from a feeder /HYHO
will contain -1.
In the case that the component was picked up from a
tray in the matrix tray changer 7UDFN1XPEHUwill
contain the WRZHU of the MTC1,2). In this way
PICKINFOREVx has the same format as in previous
versions.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
An empty list indicates an error.
1312005 SV L NOZZLECONF1
Nozzle configuration on revolver head 1. Only valid
after reference run.
/
/
812==/(B7<3(!
,5($/B12==/(B/(1*7+!>PP@
!
!
The nozzle length is measured during the reference
run. It depends on the HEIGHTREVOLVER1 value. So
REAL_NOZZLE_LENGTH is not a absolute but a
relative value.
It is calculated by subtracting the measured distance
between the nozzle and the upper edge of the
transport conveyor from the HEIGHTREVOLVER1
value.
An empty list indicates an error.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
1312006 SV L VACUUMDATAREV1
Vacuum measurements from the last reference run on
revolver head 1. Valid only after reference run.
/
/
,RSHQBQR]]OH!>PEDU@
,FORVHGBQR]]OH!>PEDU@
,FXELFBQR]]OH!>PEDU@
,QRWBFXELFBQR]]OH!>PEDU@
SIPLACE GEM for S25, HS50 SW Version GEM 502.01
HOST Interface Manual
Page 166 of 236 ©Siemens AG, all rights reserved
9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ
,WROBGLUW\BQR]]OH!>PEDU@
,WROBOHDN\BQR]]OH!>PEDU@
!
!
The first element in this list refers to segment 1, the
second to segment 2, and so on.
tol_dirty_nozzle and tol_leaky_nozzle are currently not
used.
An empty list indicates an error.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
1312007 SV L SEGMENTINFOREV1
Summation of information per segment.
/
/
,&RPS3LFNHG8S!
,3LFN8S(UURUV!
,&RPS3ODFHG!
,3ODFH(UURUV!
!
!
The first element in this list refers to segment 1, the
second to segment 2, and so on.
The variable can be linked e.g. to event PCBReady. It
is reseted when a PCB reaches the center conveyor.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
1312008 SV L PLACEINFOREV1SUB1
Subset of PLACEINFOREVx variable. Detailed
description see there.
/
/
8;SRVLWLRQ!>PP@
8<SRVLWLRQ!>PP@
)$QJOH!>GHJUHHV@
8)RUFH,QGH[!
SIPLACE GEM for S25, HS50 SW Version GEM 502.01
HOST Interface Manual
©Siemens AG, all rights reserved page 167 of 236
9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ
$5HIHUHQFH'HVLJQDWRU!
$&RPSRQHQW1DPH!
83DFNDJH)RUP1XPEHU!
83ODFHPHQW5HVXOW!
,3ODFHPHQW9DFXXP!>PEDU@
8'DWD9DOLG!
,;GHYLDWLRQ!>PP@
,<GHYLDWLRQ!>PP@
)$QJOH!>GHJUHHV@
)0D[/HDG'HY!
)0D[%DOO'HY!
!
IRUHDFKVHJPHQW
!
The first element in this list refers to segment 1, the
second to segment 2 and so on. If a segment was not
in use in the last placement cycle the list for that
segment is left empty.
Revolver Head 2 (SIPLACE 80 S 20 only)
1412001 SV I4 HEIGHTREV2
Height of revolver head 2. Only valid after reference
run. Units are 1/1000 mm. Only valid for SIPLACE
80S. On a SIPLACE 80F this variable will contain 0
During the reference run the SIPLACE measures the
distance between the upper edge of the conveyor belt
and the nozzle on segment 1. The
HEIGHTREVOLVER2 is then calculated by subtracting
the length of the nozzle on segment 1 form the
measured value. The nozzle length is defined in the
machine data. So HEIGHTREVOLOR2 is a relative
not an absolute value.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
A value of 0 indicates an error.
1412002 SV L GANTRYINFOREV2
Gantry information for revolver head 2. The data is
automatically reseted when a PCB reaches the center
conveyor.
