SIPLACE GEM for S25, HS50 SW Version GEM 502.01
HOST Interface Manual
©Siemens AG, all rights reserved page 181 of 236
9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ
2312005 SV L NOZZLECONF3
Nozzle configuration on revolver head 3. Only valid
after reference run.
/
/
812==/(B7<3(!
,5($/B12==/(B/(1*7+!>PP@
!
!
The nozzle length is measured during the reference
run. It depends on the HEIGHTREVOLVER3 value. So
REAL_NOZZLE_LENGTH is not a absolute but a
relative value.
It is calculated by subtracting the measured distance
between the nozzle and the upper edge of the
transport conveyor from the HEIGHTREVOLVER3
value.
An empty list indicates an error.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2312006 SV L VACUUMDATAREV3
Vacuum measurements from the last reference run on
revolver head 3. Valid only after reference run.
/
/
,RSHQBQR]]OH!>PEDU@
,FORVHGBQR]]OH!>PEDU@
,FXELFBQR]]OH!>PEDU@
,QRWBFXELFBQR]]OH!>PEDU@
,WROBGLUW\BQR]]OH!>PEDU@
,WROBOHDN\BQR]]OH!>PEDU@
!
!
The first element in this list refers to segment 1, the
second to segment 2, and so on.
Tol_dirty_nozzle and tol_leaky_nozzle are currently not
used.
An empty list indicates an error.
SIPLACE GEM for S25, HS50 SW Version GEM 502.01
HOST Interface Manual
Page 182 of 236 ©Siemens AG, all rights reserved
9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2312007 SV L SEGMENTINFOREV3
Summation of information per segment
/
/
,&RPS3LFNHG8S!
,3LFN8S(UURUV!
,&RPS3ODFHG!
,3ODFH(UURUV!
!
!
The first element in this list refers to segment 1, the
second to segment 2, and so on.
The variable can be linked e.g. to event PCBReady. It
is reseted when a PCB reaches the center conveyor.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2312008 SV L PLACEINFOREV3SUB1
Subset of PLACEINFOREVx variable. Detailed
description see there.
/
/
8;SRVLWLRQ!>PP@
8<SRVLWLRQ!>PP@
)$QJOH!>GHJUHHV@
8)RUFH,QGH[!
$5HIHUHQFH'HVLJQDWRU!
$&RPSRQHQW1DPH!
83DFNDJH)RUP1XPEHU!
83ODFHPHQW5HVXOW!
,3ODFHPHQW9DFXXP!>PEDU@
8'DWD9DOLG!
,;GHYLDWLRQ!>PP@
,<GHYLDWLRQ!>PP@
)$QJOH!>GHJUHHV@
)0D[/HDG'HY!
SIPLACE GEM for S25, HS50 SW Version GEM 502.01
HOST Interface Manual
©Siemens AG, all rights reserved page 183 of 236
9,' &ODVV )RUPDW 1DPHDQG'HVFULSWLRQ
)0D[%DOO'HY!
!
IRUHDFKVHJPHQW
!
The first element in this list refers to segment 1, the
second to segment 2 and so on. If a segment was not
in use in the last placement cycle the list for that
segment is left empty.
SIPLACE Revolver Head 4
2412001 SV I4 HEIGHTREV4
Height of revolver head 4. Only valid after reference
run. Units are 1/1000 mm
During the reference run the SIPLACE measures the
distance between the upper edge of the conveyor belt
and the nozzle on segment 1. The
HEIGHTREVOLVER4 is then calculated by subtracting
the length of the nozzle on segment 1 from the
measured value. The nozzle length is defined in the
machine data. So HEIGHTREVOLOR4 is a relative
not an absolute value.
A value of 0 indicates an error
2412002 SV L GANTRYINFOREV4
Gantry information for revolver head 4. The data is
automatically reseted when a PCB reaches the center
conveyor.
/
,&RPS3LFNHG8S!
,&RPS3ODFHG!
,&RPS/HIW3ODFH!
!
CompPickedUp Number of components which
were picked up successfully since
the last PCB reached the center
conveyor
CompPlaced Number of components which
were placed since the last PCB
reached the center conveyor
CompLeft2Place Number of components which
were not placed on the actual
PCB
An empty list indicates an error.
